Sharp LC-46LE925E User Manual

LC-46/60LE925E
1 – 1
LC-46LE925E
Service Manual
CHAPTER 1. SPECIFICATIONS
[1] SPECIFICATIONS
Item
LCD COLOUR TV (46 "/117 cm),
LC-46LE925E
LCD COLOUR TV (60 "/152 cm),
LC-60LE925E
LCD panel
117 cm (46 ") X-Gen panel
152 cm (60 ") X-Gen panel
Resolution 1,920 1,080 4 dots
Video colour system PAL/SECAM/NTSC 3.58/NTSC 4.43/PAL 60
TV function TV-standard Analogue CCIR (B/G, I, D/K, L/L’)
Digital DVB-T (2K/8K OFDM), DVB-C, DVB-S/S2
Receiving
channel
VHF/UHF
IR A ch-E69 ch (Digital), E2-E69 ch, F2-F10 ch, I21-I69 ch, IR A-IR J ch
CATV
Hyper-band, S1-S41 ch
Satellite
950-2150 MHz*
3
TV-tuning system Auto Preset 999 ch (non-Nordic [DTV]), Auto Preset 9999 ch (Nordic [DTV]),
Auto Preset 99 ch (ATV), Auto Label, Auto Sort, Auto Preset 9999 ch (SAT)
STEREO/BILINGUAL NICAM/A2
Audio amplifier 10 W 2/15 W 1
Speaker (234 mm 22 mm) 2/Ø 120 mm
Terminals Antenna
UHF/VHF 75 Din type (analogue & digital), Satellite 75 F type (DVB-S/S2)
RS-232C D-Sub 9 pin male connector
EXT 1 SCART (AV input, Y/C input, RGB input, TV output)
EXT 2 RCA pin (AV input/AUDIO L/R)
EXT 3 15 pin mini D-sub
HDMI 1 (EXT 4) HDMI (ARC)
HDMI 2 (EXT 5) HDMI
HDMI 3 (EXT 6) HDMI
HDMI 4 (EXT 7) HDMI
USB USB
ETHERNET (10/100) Network connector
HDMI 2/EXT 3 AUDIO (L/R) Ø 3.5 mm jack*
1
DIGITAL AUDIO OUTPUT Optical S/PDIF digital audio output
C. I. (Common Interface) EN50221, R206001, CI Plus specification
OUTPUT/Headphones RCA pin (AUDIO R/L)/Ø 3.5 mm jack (audio output)
OSD language Czech, Danish, Dutch, English, Estonian, Finnish, French, German, Greek,
Hungarian, Italian, Latvian, Lithuanian, Norwegian, Polish, Portuguese, Russian,
Slovak, Slovene, Spanish, Swedish, Turkish, Ukrainian
Power requirement
AC 220-240 V, 50 Hz
Power consumption (method IEC62087) 183 W (0.2 W standby* )
2
234 W (0.2 W standby* )
2
Weight 27.5 kg (without stand),
33.0 kg (with stand)
45.0 kg (without stand),
55.5kg(withstand)
Operating temperature
0°Cto+40°C
*1 The HDMI 2 and EXT 3 terminals can both use the same audio input terminal.
*2 Standby power consumption applies when the TV is set to not receive EPG data.
*3 The satellite channel’s frequency may vary according to satellites and antennas.
• As a part of our policy of continuous improvement, SHARP reserves the right to make design and specification changes for product
improvement without prior notice. The performance specification figures indicated are nominal values of production units. There may be
some deviations from these values in individual units.

Sharp LC-46LE925E Specifications

General

Screen shape	Flat
Response time	- ms
Display diagonal	46 \
Display brightness	- cd/m²
Native aspect ratio	16:9
Native refresh rate	100 Hz
LED backlighting type	Edge-LED
Viewing angle, horizontal	176 °
RMS rated power	20 W
Number of speakers	2
PC in (D-Sub)	-
HDMI ports quantity	4
DVI-D ports quantity	0
Common interface (CI)	No
USB 2.0 ports quantity	1
Common interface Plus (CI+)	Yes
Consumer Electronics Control (CEC)	Aquos Link
Product color	Black
Panel mounting interface	400 x 400 mm
Power consumption (standby)	0.2 W
Power consumption (typical)	95.1 W
Tuner type	Analog & digital
Analog signal format system	NTSC, PAL, SECAM
Digital signal format system	DVB-C, DVB-S, DVB-S2, DVB-T

Weight and Dimensions

Depth (with stand)	340 mm
Height (with stand)	785 mm
Weight (with stand)	45000 g
Depth (without stand)	39 mm
Width (without stand)	1127 mm
Height (without stand)	734 mm
