LC-60LE822E/LC-60LE822ERU
4 – 2
2. Removing of Speaker-L/R.
1. Remove the 2 lock screws and detach the Stand Cover .
2. Disconnect SP wire.
3. Detach the Speaker-L , Speaker-R .
4. Detach the Insulation Sheet (AC)
MAIN Unit
2 Stand Cover
1
[SP]
[SP]
4Speaker-R
3 Speaker-L
5
Insulation
Sheet (AC)
