LC-60LE822E/LC-60LE822ERU

LC-60LE822E

Service Manual

OUTLINE

MAJOR SERVICE PARTS

PWB UNIT

NOTE: (*1) Replace MAIN Unit (DKEYDF455FM07) in case of IC8401 or IC3302 failure.

(*2) TOUCH SENSOR Key Unit (RUNTKA761WJQZ) reuse will be impossible, once it is stuck on front cabinet and

exfoliates.

Therefore, please exchange of a TOUCH SENSOR Key Unit in the case of front cabinet exchange.

OTHER UNIT

IC FOR EXCLUSIVE USE OF THE SERVICE

SERVICE JIGS

Ref No. Parts Code Description

N DKEYDF455FM07 MAIN Unit (*1)

N DUNTKF494FM02 R/C, LED Unit

N DUNTKF493FM03 ICON Unit

N DUNTKF493FM04 LOGO Unit

N RUNTKA761WJQZ TOUCH SENSOR Key Unit(*2)

N RUNTKA729WJQZ POWER/LED CONTROL Unit

N RUNTK4512TPZA LCD CONTROL Unit

Ref No. Parts Code Description

N R1LK600D3LW20Z 60" LCD Panel Module Unit

Ref No. Parts Code Description Q’ty

IC501 RH-iXD108WJQZS IC 24LC21AT-I/SN 1

IC2002 RH-iXC786WJNJQ IC R5F364A6NFB 1

Ref No. Parts Code Description Q’ty

N QCNW-G616WJQZ Main Unit to LCD Control Unit (LW) 1

N QCNW-G625WJQZ Main Unit to Power Unit (PL) 1

N QCNW-H184WJQZ Main Unit to Power Unit (PD) 1

N QCNW-H185WJQZ Main Unit to Power (LED Drive) Unit (LB) 1

N QCNW-K594WJQZ Main Unit to R/C, LED Unit (RA) 1

N QCNW-K595WJQZ Main Unit to Speaker (SP) 1

N QCNW-K596WJQZ Main Unit to Icon Unit (RL) 1

N QCNW-K597WJQZ Main Unit to Woofer (SB) 1
