LC-60LE822E/LC-60LE822ERU
5 – 1
LC-60LE822E
Service Manual
CHAPTER 5. TOUCH SENSOR UNIT POSITIONING FIGURE
[1] TOUCH SENSOR UNIT POSITIONING FIGURE
TOUCH SENSOR KEY Unit
