Sharp LC-60LE822E User Manual

LC-60LE822E/LC-60LE822ERU
7 – 6
No sound from external input devices (4)
Does not the sound of the audio signal input to HDMI1/2/3/4 go out?
Please Refer to “[External input HDMI-1/2/3/4] No picture on the display (10)”.
No sound from external output device (1)
No audio signal output to EXT1 terminal.
Is there a audio input signal to pins (10/AUDIO_OUT_L) and (12/
AUDIO_OUT_R) of EXT1 (SC505)?
YES Check the setting of an external input device that connects with
EXT1.
NO
Is SC1-MUTE [118pins of IC3302 (Digital AV decode & Main
CPU)] or MUTE_A_ALL [21pin of IC2002 (UCOM)] at “H”?
YES Check the peripheral circuits of IC3302 and SC1-MUTE.
(Q502, D529 etc.)
NO
Is there a audio output signal to pins (M30/TUNER_OUT_L) and
(M29/TUNER_OUT_R) of IC3302?
YES Check the line between IC3302 and SC505.
NO
Check IC3302 and its peripheral circuits.
No sound from external output device (2)
No sound from HEAD PHONE_OUTPUT/ AUDIO_OUTPUT terminal.
Does not the sound of the audio signal output to Headphone
mode go out?
Does not the sound of the audio signal output to Audio out
mode go out?
Check whether it is selected “Headphone” by Headphone/Audio
out select under Menu-Setup-Option- Input terminal setting.
Check whether it is selected “Audio out” by Headphone/Audio out
select under Menu-Setup-Option-Input terminal setting.
YES YES
Is there a audio output signal to pins (2/HP/MONI_L) and (3/HP/MONI_R) of J504 (HEAD PHONE_OUTPUT/ AUDIO_OUTPUT terminal)?
NO
YES
Check the setting of an external input device that connects with
J504.
Is the HP_PLUG signal input to [91/HP_PLUG] of IC4405 from
pin (6) of J504?
NO Check the line between J504 and IC4405.
YES
Is HP/MONI_MUTE [AJ11 of IC3302 (Digital AV decode & Main
CPU)] or MUTE_A_ALL [21pin of IC2002 (UCOM)] at “H”?
YES Check the peripheral circuits of IC3302 and HP-MUTE_LINE.
(D527, Q506, etc.)
NO
Is audio signal (HP_L/R) input to pins (M28/HP/MONI_L, M27/
HP/MONI_R) of IC3302?
YES Check the line between IC3302 and J504.
NO
Check IC3302 and its peripheral circuits.

Sharp LC-60LE822E Specifications

General

Power supply type	AC
Power consumption (standby)	0.20 W
Power consumption (typical)	100 W
Child lock	No
Plug and Play	Yes
Audio formats supported	AAC
Video formats supported	H.264, MPEG4
Display diagonal	60 \
Display technology	LCD
Native aspect ratio	16:9
Native refresh rate	100 Hz
Viewing angle, horizontal	176 °
Internal memory	8000 MB
Audio (L/R) in	0
HDMI ports quantity	4
SCART ports quantity	1
Product color	Black
LED indicators	Stand-by
Panel mounting interface	400 x 400 mm
Remote control type	GA841WJSA
RMS rated power	20 W
Number of speakers	2
Tuner type	Analog & digital
Analog signal format system	NTSC, PAL, SECAM

Weight and Dimensions

Depth (with stand)	368 mm
Width (with stand)	1439 mm
Height (with stand)	975 mm
Weight (with stand)	51000 g
Depth (without stand)	40 mm
Height (without stand)	913 mm
