Sharp LC-60LE822E - Service Jigs (Use for Servicing)

LC-60LE822E/LC-60LE822ERU
7
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[5] PACKING PARTS (NOT REPLACEMENT ITEM)
S1 SPAKCF901WJZZ - N - Packing Case (Top)
S2 SPAKCF498WJZZ - N - Packing Case (Bottom)
S3 SPAKAA639WJZZ - N - Rear Pad
S4 SPAKPB550WJZZ - N - Wrapping Paper
S5 SPAKPB551WJZZ - N - Wrapping Paper (Stand)
S6 SPAKXC923WJZZ - N - Packing Add. (Top)
S7 SPAKXC928WJZZ - N - Packing Add. (Bottom)
S8 SSAKAA009WJZZ - - Polyethylene Bag
S9 SSAKAA111WJZZ - - Polyethylene BagÇP, x2
[6] SERVICE JIGS (USE FOR SERVICING)
N QCNW-G616WJQZ N J Main Unit to LCD Control Unit (LW)
N QCNW-G625WJQZ N J Main Unit to Power Unit (PL)
N QCNW-H184WJQZ N J Main Unit to Power Unit (PD)
N QCNW-H185WJQZ N J Main Unit to Power (LED Drive) Unit (LB)
N QCNW-K594WJQZ N J Main Unit to R/C, LED Unit (RA)
N QCNW-K595WJQZ N J Main Unit to Speaker (SP)
N QCNW-K596WJQZ N J Main Unit to Icon Unit (RL)
N QCNW-K597WJQZ N J Main Unit to Woofer (SB)
