Sharp LC-65LE654U User Manual

Level
Child
P/N
Seq
Specification UIT Supply Type UOM Qty Circuit Number
Child P/N
3 1 9LE 170107002680 IR LENS(PC/GRAY)(LC-65LE643U) G Supplier EA 1
3 1 9LE 170107002690 LED LENS(PC/TRANSPARENT)(LC-65LE643U) G Supplier EA 1
3 1 9LE 193616006760 ENERGY GUIDE LBL(100# PP)Sharp LC-65LE654U G Supplier EA 1
3 11 9LE 193616006800 TECH LBL(100# PP)(non E-Star)(Dolby Plus/WIFI/HDMI)Sharp G Supplier EA 1
3 61 9LE 194715011080 FOAM PAD ASS'Y(PE1432*4.0*0.8t/BLK+AL1432*8.5*0.15t) G Supplier EA 2
3 71 9LE 194715011090 FOAM PAD ASS'Y(PE810*4.0*0.8t/BLK+AL810*8.5*0.15t) G Supplier EA 2
3 1 9LE 194717001250 Conductive Fabric tape (L15*W34mm) G Supplier EA 1
3 51 9LE 194717001820 Conductive Tape 20*5mm (L type) for Panel ESD G Supplier EA 4
2 1 9LE 180102538100 REAR COVER(HIPS FR/T52013)(LC-65LE654U)ASS'Y G Assembly Pull EA 1
3 1 9LE 170102538000 REAR COVER(EM65FTR) G Supplier EA 1
3 1 9LE 170102538080 REAR COVER(HIPS FR/T52013)(LC-65LE654U) G Supplier EA 1
3 41 9LE 194715004250 CR SPONGE (120.0L*10.0W*0.6t) G Supplier EA 2
3 31 9LE 194715005860 CR SPONGE (40.0L*15.0W*0.6t)(BLK) G Supplier EA 6
3 1 9LE 194715007810 CR SPONGE(Φ25.0*Φ12.0*1.0t)(BLK) G Supplier EA 4
3 21 9LE 194715008270 PU SPONGE(60.0L*40.0W*7.0t)(BLK) G Supplier EA 2
3 51 9LE 194715009780 PU SPONGE(SONY G4000/120.0L*12.0W*4t)(BLK) G Supplier EA 2
3 1 9LE 194724001560 MYLAR(FRPP/350*355*0.6t)(BLK)(LC-65LE643U) G Supplier EA 1
2 1 9LE 180104280030 DISPLAY KEY(HIPS FR/T52013)(LC-65LE643U)ASS'Y G Assembly Pull EA 1
3 1 9LE 170104280000 DISPLAY KEY(EM55FTR) G Supplier EA 1
3 1 9LE 170104280030 DISPLAY KEY(HIPS FR/T52013)(LC-65LE643U) G Supplier EA 1
3 1 9LE 170119805010 DISPLAY KEY COVER(HIPS FR/T52013)(EM55FTR) G Supplier EA 1
3 21 9LE 194715009900 FOAM PAD(20.0*5.0*0.3t)(BLK) G Supplier EA 4
2 1 9LE 181201028670 STAND SUPPORT BKT(SGCC 2.0t)(LC-65LE654U)ASS'Y G Assembly Pull EA 2
3 1 9LE 171201028630 STAND SUPPORT BKT(SGCC 2.0t)(LC-55LE653U) G Supplier EA 1
3 1 9LE 171201028660 STAND HOLDER BKT(SGCC 2.0t)(LC-65LE654U) G Supplier EA 1
3 1 9LE 172500040650 MAC SCREW-MB M4.0*6.0L,BLK_Ni, NYLOK G Supplier EA 4
2 1 9LE 194712000311 ACETATE CLOTH TAPE 27*75mm G Assembly Pull EA 8
2 1 9LE 194712000401 ACETATE CLOTH TAPE 20*45mm G Assembly Pull EA 10
2 1 9LE 194712009240 ACETATE CLOTH TAPE(130*20*0.25t)(BLK) G Assembly Pull EA 1
2 1 9LE 194715006620 CR SPONGE(20.0L*8.0W*3.0t) G Assembly Pull EA 2
2 1 9LE 194715009750 CR SPONGE(20.0L*20.0W*1.5t)(BLK) G Assembly Pull EA 2
2 1 9LE 194715009780 PU SPONGE(SONY G4000/120.0L*12.0W*4t)(BLK) G Assembly Pull EA 1
2 1 9LE 194715009840 CR SPONGE(20.0L*10.0W*6.0t)(BLK) G Assembly Pull EA 1
2 1 9LE 194715010940 CR SPONGE(20.0L*20.0W*5.5t)(BLK)(LC-65LE654U) G Assembly Pull EA 4
2 1 9LE 194717001210 Conductive Tape 5*45mm G Assembly Pull EA 6
2 1 9LE 194717001250 Conductive Fabric tape (L15*W34mm) G Assembly Pull EA 1
2 1 9LE 194717001270 Conductive Tape 60*40 (L type) for ESD G Assembly Pull EA 1
2 1 9LE 194717001360 Conductive Tape 25*70mm G Assembly Pull EA 1
2 1 9LE 194717001370 Conductive Tape 25*150mm G Assembly Pull EA 1
2 1 9LE 194719000870 THERMAL PAD(13*13*7.5t) G Assembly Pull EA 2
2 1 9LE 194719000900 THERMAL PAD(50*12*1.2t)(INSULATOR TAPE) G Assembly Pull EA 12
2 1 9LE 194720003240 RUBBER PAD(SILICON/15*10*1.5t)(BLK)(LC-39LE551U) G Assembly Pull EA 4
2 1 9LE 194720003260 RUBBER PAD(SILICON/20*14*2.7t)(DEEP GRAY) G Assembly Pull EA 8
2 1 9LE 194724001710 MYLAR(PC/50*5*0.4t)(BLK)(LC-65LE643U) G Assembly Pull EA 2
2 1 9LE 194724002150 MYLAR(FRPP/383.0*320.0*0.6t)(BLK)(LC-65LE654U) G Assembly Pull EA 1
2 1 9LE 194799001000 ADHESIVE SONY SC608Z2 (180ml) G Assembly Pull GR .3
2 1 9LE 365500720156 DISPLAY BD ASS'Y LC-55LE643U (Screw V1,V2) M Assembly Pull EA 1
3 1 9LE 365500720156M DISPLAY BD ASS'Y LC-55LE643U (Screw V1,V2) MI P Phantom EA 1
4 1 9LE 022070203265 SW TACT 4.5*4.5mm 180' 160g DIP SFKHRAA2220P L-F G Assembly Pull EA 7 SW1,SW2,SW3,SW4,SW5,SW6,SW7
4 1 9LE 045112500466 WAFER 1.25mm 4P 90' DIP KINK (M24014R) L-F G Assembly Pull EA 1 J1
4 *R* 9LE 045112500463 WAFER 1.25mm 4P 90' KINK (A1251WR0-4P) L-F G Assembly Pull EA 1
4 1 9LE 365500720156T DISPLAY BD ASS'Y LC-55LE643U (Screw V1,V2) TOP P Phantom EA 1
