Level
Child
P/N
Seq
Specification UIT Supply Type UOM Qty Circuit Number
Child P/N
5 1 9LE 011131031617 C/M Multi. 0.01uF 16V X7R K 0402 G Assembly Pull EA 2 C2,C3
5 *R* 9LE 011231031617 C/M Multi. 0.01uF 16V X7R K 0402 G Assembly Pull EA 2
5 *R* 9LE 011551031617 C/M Multi. 0.01uF 16V X7R 0402 (CL05B103KO5NNN) G Assembly Pull EA 2
5 1 9LE 011231051656 C/M MULTI 1.0uF 16V X5R 0603 G Assembly Pull EA 1 C1
5 *R* 9LE 011551051656 C/M MULTI 1.0uF 16V X5R 0603 G Assembly Pull EA 1
5 *R* 9LE 011131051656 C/M MULTI 1.0uF 16V X5R 0603 G Assembly Pull EA 1
5 1 9LE 013000001654 RES. CF 0ohm 1/16W J 0402 G Assembly Pull EA 3 R15,R16,R22
5 1 9LE 013010011654 RES. CF 1Kohm 1/16W J 0402 G Assembly Pull EA 2 R18,R20
5 1 9LE 013120011614 RES. MF 2Kohm 1/16W F 0402 G Assembly Pull EA 6 R10,R19,R2,R21,R3,R9
5 1 9LE 013124011614 RES. MF 2.4Kohm 1/16W F 0402 G Assembly Pull EA 1 R7
5 1 9LE 017117712870 PCB Display BD FR4 109*14*1.6t*2L (JVC EM55T)(1:10) G Assembly Pull EA 1
2 1 9LE 366500120189 IR BD ASS'Y SHARP (LC-65LE643U_NS6738S) M Assembly Pull EA 1
3 1 9LE 366500120189M IR BD ASS'Y SHARP (LC-65LE643U_NS6738S) MI P Phantom EA 1
4 1 9LE 045112500406 WAFER 1.25mm 4P 180' DIP KINK (M24014) L-F G Assembly Pull EA 1 JR2
4 *R* 9LE 045112500403 WAFER 1.25mm 4P 180' KINK (A1251WV0-4P) L-F G Assembly Pull EA 1
4 1 9LE 194717102020 AL tape 16*26*0.2mm Aluminum-foil with back Mylar for ESD G Assembly Pull EA 1
4 1 9LE 366500120189T IR BD ASS'Y SHARP (LC-65LE643U_NS6738S) TOP P Phantom EA 1
5 1 9LE 011131015117 C/M Multi. 100PF 50V X7R K 0402 G Assembly Pull EA 1 CR7
5 *R* 9LE 011231015117 C/M Multi. 100PF 50V X7R K 0402 G Assembly Pull EA 1
5 1 9LE 011131041617 C/M Multi. 0.1uF 16V X7R 0402 G Assembly Pull EA 2 CR5,CR6
5 *R* 9LE 011231041617 C/M Multi. 0.1uF 16V X7R 0402 G Assembly Pull EA 2
5 *R* 9LE 011551041617 C/M Multi. 0.1uF 16V X7R K 0402 (CL05B104KO5NNNC) G Assembly Pull EA 2
5 1 9LE 011231061155 C/M Multi. 10uF 10V X5R 0805 L-F G Assembly Pull EA 1 CR1
5 *R* 9LE 011551061155 C/M Multi. 10uF 10V X5R 0805 G Assembly Pull EA 1
5 1 9LE 013018001654 RES. CF 180ohm 1/16W J 0402 G Assembly Pull EA 1 RR1
5 1 9LE 013047091858 RES. CF 47ohm 1/8W J 0805 G Assembly Pull EA 1 LR1
5 11 9LE 017116711211 PCB IR BD FR4 54*8*1.6t 2L (LC-48LE653U)(1:20) G Assembly Pull EA 1
5 21 9LE 039050035293 DUAL SURFACE DIODES BAV99-7-F SOT-23 HF G Assembly Pull EA 2 DR1,DR2
5 1 9LE 044040000206 LED White TOP VIEW (LTW-C191UC5) 1.6*0.8*0.55mm SMD HF G Assembly Pull EA 1 LED1
5 1 9LE 098002006051 IR RECEIVER 38KHz 4pin 5.2x4x2.8mm SMD(NS6738S) LF G Assembly Pull EA 1 UR1
5 *R* 9LE 098002006060 IR RECEIVER 38KHz 4pin 5x4x2.5mm SMD(IRM-H938T-TR2/LX) LF G EA 1
5 *R* 9LE 098002006031 IR RECEIVER 38KHz 4pin SMD 5.2x4x2.8mm R1.0(FM-A438FN-5CN)LF G Assembly Pull EA 1
2 1 9LE 366501720304 LCM ASS'Y LC-65LE654U (AUO T650HVN05.502) P Phantom EA 1
3 1 9LE 021506500977 Open cell ASS'Y T650HVN05.502(AUT) G Assembly Pull EA 1
3 1 9LE 046010020221 A2001-2/A2001-2 10368#26 150mm(B) G/Y HF G Assembly Pull EA 4
3 1 9LE 046011080201 A2512-8/PK242151P2*4 10368#26 600/400/500/700(A) HF G Assembly Pull EA 1
3 1 9LE 098102657706 55.65T10.C05 T-CON ASS'Y for T650HVN05.502(AUT) G Assembly Pull EA 1
3 1 9LE 170114000950 SNAP BUSHING(SILICON/BLK))(LC-65LE643U) G Assembly Pull EA 5
3 1 9LE 170115003890 MOUNTING BUTTON(MB-32PC5V0) G Assembly Pull EA 36
3 1 9LE 170115004120 SPACER SUPPORT(MCFA-2511) G Assembly Pull EA 11
3 1 9LE 171201027900 PANEL SUPPORT BKT_INNER(SGCC 1.6t)(LC-65LE643U) G Assembly Pull EA 2
3 1 9LE 171303011040 BOTTOM COVER(SECC 0.8t)(LC-65LE654U) G Assembly Pull EA 1
3 1 9LE 172050030450 MAC. SCREW-MI M3.0*4.0L, BLK-Ni G Assembly Pull EA 12
3 1 9LE 180119821011 GUIDE PANEL_T(PC+GF10 FR/T52013)(EM65FTR)ASS'Y G Assembly Pull EA 1
4 1 9LE 170119821000 GUIDE PANEL_T(EM65FTR) G Supplier EA 1
4 1 9LE 170119821010 GUIDE PANEL_T(PC+GF10 FR/T52013)(EM65FTR) G Supplier EA 1
4 1 9LE 194715009650 FOAM PAD(1265.0*3.0*0.4t)(BLK) G Supplier EA 1
4 1 9LE 194720003131 RUBBER PAD(SILICON 94V-0 10u/1285*3*1.0t)(DEEP GRAY) G Supplier EA 1
3 1 9LE 180119822012 GUIDE PANEL_B(PC+GF10 FR/T52013)(EM65FTR)ASS'Y G Assembly Pull EA 1
4 1 9LE 170119822000 GUIDE PANEL_B(EM65FTR) G Supplier EA 1
4 1 9LE 170119822011 GUIDE PANEL_B(PC+GF10 FR/T52013)(EM65FTR) G Supplier EA 1
4 1 9LE 194715009650 FOAM PAD(1265.0*3.0*0.4t)(BLK) G Supplier EA 1
Confidential-do not copy
Page 14-4
File No. SG-0000351
