Sharp LC-65LE654U User Manual

Level
Child
P/N
Seq
Specification UIT Supply Type UOM Qty Circuit Number
Child P/N
4 1 9LE 194720003131 RUBBER PAD(SILICON 94V-0 10u/1285*3*1.0t)(DEEP GRAY) G Supplier EA 1
3 1 9LE 180119823012 GUIDE PANEL_L(PC+GF10 FR/T52013)(EM65FTR)ASS'Y G Assembly Pull EA 1
4 1 9LE 170119823000 GUIDE PANEL_L(EM65FTR) G Supplier EA 1
4 1 9LE 170119823010 GUIDE PANEL_L(PC+GF10 FR/T52013)(EM65FTR) G Supplier EA 1
4 1 9LE 194715009660 FOAM PAD(80.0*3.0*0.4t)(BLK) G Supplier EA 2
4 1 9LE 194715009670 FOAM PAD(815.0*3.0*0.4t)(BLK) G Supplier EA 1
4 1 9LE 194715009730 FOAM PAD(36*6.0*0.3t)(BLK) G Supplier EA 6
4 1 9LE 194720003121 RUBBER PAD(SILICON 94V-0 10u/815*3*1.0t)(DEEP GRAY) G Supplier EA 1
4 1 9LE 194720003141 RUBBER PAD(SILICON 94V-0 10u/72*3*1.0t)(DEEP GRAY) G Supplier EA 2
4 1 9LE 194724001720 MYLAR(PC/35*5*0.4t)(BLK)(LC-65LE643U) G Supplier EA 2
3 1 9LE 180119824012 GUIDE PANEL_R(PC+GF10 FR/T52013)(EM65FTR)ASS'Y G Assembly Pull EA 1
4 1 9LE 170119824000 GUIDE PANEL_R(EM65FTR) G Supplier EA 1
4 1 9LE 170119824010 GUIDE PANEL_R(PC+GF10 FR/T52013)(EM65FTR) G Supplier EA 1
4 1 9LE 194715009660 FOAM PAD(80.0*3.0*0.4t)(BLK) G Supplier EA 2
4 1 9LE 194715009670 FOAM PAD(815.0*3.0*0.4t)(BLK) G Supplier EA 1
4 1 9LE 194715009730 FOAM PAD(36*6.0*0.3t)(BLK) G Supplier EA 6
4 1 9LE 194720003121 RUBBER PAD(SILICON 94V-0 10u/815*3*1.0t)(DEEP GRAY) G Supplier EA 1
4 1 9LE 194720003141 RUBBER PAD(SILICON 94V-0 10u/72*3*1.0t)(DEEP GRAY) G Supplier EA 2
4 1 9LE 194724001720 MYLAR(PC/35*5*0.4t)(BLK)(LC-65LE643U) G Supplier EA 2
3 1 9LE 194712000401 ACETATE CLOTH TAPE 20*45mm G Assembly Pull EA 21
3 1 9LE 194712009300 PET TAPE(3M SUPER10/30*25*0.06t)(TRANSPARENT)(LC-65LE643U) G Assembly Pull EA 5
3 1 9LE 194717001270 Conductive Tape 60*40 (L type) for ESD G Assembly Pull EA 1
3 1 9LE 194724001610 MYLAR(PC/27.0*12.0*0.125t)(BLACK) G Assembly Pull EA 16
3 1 9LE 36650192030C BACKLIGHT ASS'Y LC-65LE654U (AUO T650HVN05.502) P Phantom EA 1
4 1 9LE 0981010221CR 65 inch L/B module 8PCS- A(3043_AUO_ T650HVN05.502) G Assembly Pull EA 8
4 1 9LE 0981010221CS 65 inch L/B module 8PCS- B(3043_AUO_ T650HVN05.502) G Assembly Pull EA 4
4 1 9LE 0981010221CY 65 inch L/B module 8PCS- C(3043_AUO_ T650HVN05.502) G Assembly Pull EA 4
4 1 9LE 170109004100 DIFFUSER PLATE(EMS-55K3/PS 2t)(LC-65LE643U) G Assembly Pull EA 1
4 1 9LE 170109004340 PRISM HORIZONTAL MIDDLECELL2(HF54U3/PET 0.275t)(LC-65LE643U) G Assembly Pull EA 1
4 1 9LE 170109004350 PRISM VERTICAL DOWN-CELL3(HF64U0V/PET 0.29t)(LC-65LE643U) G Assembly Pull EA 1
4 1 9LE 170109004980 DIFFUSER SHEET UP-CELL1(CDX179HV/PET 0.28t)(LC-65LE654U) G Assembly Pull EA 1
4 1 9LE 170109005010 REFLECTOR(225-RA/PET 0.225t)(LC-65LE654U) G Assembly Pull EA 1
2 1 9LE 366502720150 MAIN BD ASS'Y LC-65LE654U_AUO_T650HVN05.502_RTD2986ID (HDCP
)
M Assembly Pull EA 1
3 1 9LE 366502720150M MAIN BD ASS'Y LC-65LE654U_AUO_T650HVN05.502_RTD2986ID MI P Phantom EA 1
4 1 9LE 028027000213 X'TAL 27MHZ HC-49S 30PPM 20PF 18ohm + W/O PAD -20~85'C HF G Assembly Pull EA 2 Y1,YM2
4 1 9LE 030062000130 USB CONN. A TYPE 90' (3AL04S-305-ZC) L-F G Assembly Pull EA 1 PU3
4 *R* 9LE 030062000051 USB CONN. A TYPE 90' (UB1112C-4K5-4F) L-F G Assembly Pull EA 1
4 *R* 9LE 030062000200 USB CONN. A TYPE 90' (184-0420112-AT) LF G Assembly Pull EA 1
4 1 9LE 030064000070 OPTO CONN. Transmitter (JST1221) L-F G Assembly Pull EA 1 PA1
4 *R* 9LE 030064000140 OPTO CONN. 90' Transmitter 16MB (GQ48T-01) LF G Assembly Pull EA 1
4 1 9LE 030290200270 RCA JACK 1ROW 2I/O 90' (W-R) (WT-04066V2B-06H) L-F G Assembly Pull EA 1 PA2
4 *R* 9LE 030290200039 RCA JACK 1ROW 2I/O 90' (W-R) (RCA215D-01) LF G Assembly Pull EA 1
4 1 9LE 030290500071 RCA JACK 1R 5IO 90'(GBRWR)(WTJ-032-55V2B-01A) LF G Assembly Pull EA 1 PV1
4 *R* 9LE 030290500049 RCA JACK 1ROW 5IO 90'(GBRWR)(RCA546D-01) LF G Assembly Pull EA 1
4 1 9LE 030480000240 RJ45 CONN. 90' Without/LED (5450-025-1G3-A9) LF G Assembly Pull EA 1 JN1
4 1 9LE 045120000406 WAFER 2.0mm 4P 180' DIP KINK (M24264) HF G Assembly Pull EA 2 J1,JI3
4 *R* 9LE 045120030403 WAFER 2.00mm 4P 180' KINK (A2001WV2-4P) L-F G Assembly Pull EA 2
4 1 9LE 045120000506 WAFER 2.0mm 5P 180' DIP KINK (M24265) HF G Assembly Pull EA 1 JU4
4 *R* 9LE 045120030503 WAFER 2.00mm 5P 180' KINK (A2001WV2-5P) L-F G Assembly Pull EA 1
4 1 9LE 045120000606 WAFER 2.0mm 6P 180' DIP KINK (M24266) HF G Assembly Pull EA 1 J13
4 *R* 9LE 045120030603 WAFER 2.00mm 6P 180' KINK (A2001WV2-6P) L-F G Assembly Pull EA 1
Confidential-do not copy
Page 14-5
File No. SG-0000351
