Sharp LC-65LE654U User Manual

Level
Child
P/N
Seq
Specification UIT Supply Type UOM Qty Circuit Number
Child P/N
4 1 9LE 045120001066 WAFER 2.0mm 10P 90' DIP KINK (M242610R) HF G Assembly Pull EA 1 JP1
4 *R* 9LE 045120031063 WAFER 2.00mm 10P 90' KINK (A2001WR2-10P) L-F G Assembly Pull EA 1
4 1 9LE 045125000446 WAFER 2.5mm 4P 90' DIP KINK (M241854R) L-F G Assembly Pull EA 1 JA1
4 *R* 9LE 045125000443 WAFER 2.50mm 4P 90' KINK (A2501WR2-4P) L-F G Assembly Pull EA 1
4 *R* 9LE 045125000449 WAFER 2.50mm 4P 90' KINK (A2501WR-04P1) L-F G Assembly Pull EA 1
4 1 9LE 098001060340 Tuner silicon can DTVS20CVH055A Horizontal 1input (SEMCO)LF G Assembly Pull EA 1 UT3
4 1 9LE 194719000840 CERAMICS HEAT SINK(SIC/20.0*20.0*2.0t)(GREEN) G Assembly Pull EA 1
4 1 9LE 194719000850 CERAMICS HEAT SINK(SIC/30.0*30.0*5.0t)(GREEN) G Assembly Pull EA 1
4 1 9LE 194719001000 CERAMICS HEAT SINK(SIC/30.0*30.0*10.0t)(GREEN) G Assembly Pull EA 1
4 1 9LE - 366502720150A MAIN BD ASS'Y LC-65LE654U_AUO_T650HVN05.502_RTD2986ID AI P Phantom EA 1
5 1 9LE 010152211310 E/C TL 220uF 25V 105'C NF 8*11.5mm L-F G Assembly Pull EA 6 CAE11,CAE12,CAE13,CPE1,CPE7,CPE9
5 *R* 9LE 010362211310 E/C HF 220uF 25V 105'C NF-T (8*11.5mm) G Assembly Pull EA 6
5 1 9LE 010312211210 E/C VZ 220uF 16V 105'C NF-T (6.3*11mm) L-F G Assembly Pull EA 5 CAE1,CAE5,CHE1,CPE12,CUE5
5 *R* 9LE 010202211210 E/C TK 220uF 16V 105'C NF (6.3*11mm) L-F G Assembly Pull EA 5
5 1 9LE 366502720150T MAIN BD ASS'Y LC-65LE654U_AUO_T650HVN05.502_RTD2986ID TOP P Phantom EA 1
6 1 9LE 011131005107 C/M Multi. 10PF 50V NPO J 0402 G Assembly Pull EA 6 CA39,CA66,CI12,CI9,CT20,CT21
6 *R* 9LE 011231005107 C/M Multi. 10PF 50V NPO 0402 G Assembly Pull EA 6
6 *R* 9LE 011551005107 C/M Multi. 10PF 50V NPO J 0402 G Assembly Pull EA 6
6 1 9LE 011131015107 C/M Multi. 100PF 50V NPO J 0402 G Assembly Pull EA 2 CI14,CP62
6 *R* 9LE 011551015107 C/M Multi. 100PF 50V NPO 0402 (CL05C101JB5NNN) G Assembly Pull EA 2
6 *R* 9LE 011231015107 C/M Multi. 100PF 50V NPO J 0402 G Assembly Pull EA 2
6 1 9LE 011131025117 C/M MULTI 1000PF 50V X7R 0402 G Assembly Pull EA 1 CP8
6 *R* 9LE 011551025117 C/M Multi. 1000PF 50V X7R 0402 (CL05B102KB5NNN) G Assembly Pull EA 1
6 *R* 9LE 011231025117 C/M Multi. 1000PF 50V X7R 0402 G Assembly Pull EA 1
6 1 9LE 011131031617 C/M Multi. 0.01uF 16V X7R K 0402 G Assembly Pull EA 2 CP63,CP67
6 *R* 9LE 011231031617 C/M Multi. 0.01uF 16V X7R K 0402 G Assembly Pull EA 2
6 *R* 9LE 011551031617 C/M Multi. 0.01uF 16V X7R 0402 (CL05B103KO5NNN) G Assembly Pull EA 2
6 1 9LE 011131032517 C/M Multi. 0.01uF 25V X7R K 0402 G Assembly Pull EA 2 CP47,CT41
6 *R* 9LE 011551032517 C/M Multi. 0.01uF 25V X7R K 0402 (CL05B103KA5NNNC) G Assembly Pull EA 2
6 *R* 9LE 011231032517 C/M Multi. 0.01uF 25V X7R K 0402 G Assembly Pull EA 2
6 1 9LE 011131035116 C/M MULTI 0.01UF 50V X7R 0603 G Assembly Pull EA 4 CA57,CA63,CA91,CA96
6 *R* 9LE 011231035116 C/M Multi. 0.01uF 50V X7R 0603 G Assembly Pull EA 4
6 *R* 9LE 011551035116 C/M Multi. 0.01uF 50V X7R 0603 Samsung G Assembly Pull EA 4
6 1 9LE 011131041616 C/M Multi. 0.1uF 16V X7R 0603 G Assembly Pull EA 1 CA97
6 *R* 9LE 011231041616 C/M Multi. 0.1uF 16V X7R 0603 L-F G Assembly Pull EA 1
6 *R* 9LE 011551041616 C/M Multi. 0.1uF 16V X7R 0603 Samsung G Assembly Pull EA 1
6 1 9LE 011131041617 C/M Multi. 0.1uF 16V X7R 0402 G Assembly Pull EA 51
C190,C435,C436,C441,C452,C459,C477,CA38,CA47,CA53,CA58,CA76,CI10,CI11,CI13,CI6,CL1,
CL2,CM30,CMP1,CMP10,CMP11,CMP13,CMP15,CMP18,CMP19,CMP23,CMP27,CMP4,CMP8,C
MP9,CP20,CP22,CP23,CP25,CP26,CP27,CP3,CP30,CP31,CP32,CP35,CP54,CP55,CP60,CP66,
CT22,CT33,CT42,CU16,CU23
6 *R* 9LE 011231041617 C/M Multi. 0.1uF 16V X7R 0402 G Assembly Pull EA 51
6 *R* 9LE 011551041617 C/M Multi. 0.1uF 16V X7R K 0402 (CL05B104KO5NNNC) G Assembly Pull EA 51
6 1 9LE 011131042516 C/M Multi. 0.1uF 25V X7R 0603 G Assembly Pull EA 3 CP1,CP45,CP52
6 *R* 9LE 011231042516 C/M Multi. 0.1uF 25V X7R 0603 G Assembly Pull EA 3
6 *R* 9LE 011551042516 C/M Multi. 0.1uF 25V X7R 0603 G Assembly Pull EA 3
6 1 9LE 011131205107 C/M Multi. 12PF 50V NPO J 0402 G Assembly Pull EA 1 CP46
6 *R* 9LE 011231205107 C/M Multi. 12PF 50V NPO J 0402 G Assembly Pull EA 1
6 *R* 9LE 011551205107 C/M Multi. 12PF 50V NPO J 0402 G Assembly Pull EA 1
6 1 9LE 011132005107 C/M MULTI 20PF 50V NPO 0402 G Assembly Pull EA 2 CT24,CT26
6 1 9LE 011132215107 C/M MULTI 220PF 50V NPO 0402 G Assembly Pull EA 1 CP53
6 *R* 9LE 011232215107 C/M MULTI 220pF 50V NPO 0402 G Assembly Pull EA 1
6 *R* 9LE 011552215107 C/M MULTI 220PF 50V NPO 0402 G Assembly Pull EA 1
Confidential-do not copy
Page 14-6
File No. SG-0000351
