Sharp LC-65LE654U User Manual

Level
Child
P/N
Seq
Specification UIT Supply Type UOM Qty Circuit Number
Child P/N
6 1 9LE 011132705107 C/M MULTI 27PF 50V NPO 0402 G Assembly Pull EA 3 C125,CA80,CA81
6 *R* 9LE 011232705107 C/M Multi. 27PF 50V NPO 5% 0402 G Assembly Pull EA 3
6 *R* 9LE 011552705107 C/M MULTI 27PF 50V NPO 0402 G Assembly Pull EA 3
6 1 9LE 011132715107 C/M Multi. 270PF 50V NPO J 0402 G Assembly Pull EA 2 CA86,CA87
6 *R* 9LE 011232715107 C/M Multi. 270PF 50V NPO 0402 G Assembly Pull EA 2
6 *R* 9LE 011552715107 C/M Multi. 270PF 50V NPO J 0402 G Assembly Pull EA 2
6 1 9LE 011133305107 C/M Multi. 33PF 50V NPO 0402 G Assembly Pull EA 4 C113,CM32,CM33,CMP16
6 *R* 9LE 011553305107 C/M Multi. 33PF 50V NPO 0402 G Assembly Pull EA 4
6 *R* 9LE 011233305107 C/M Multi. 33PF 50V NPO 0402 L-F G Assembly Pull EA 4
6 1 9LE 011133315107 C/M Multi. 330PF 50V NPO 0402 G Assembly Pull EA 3 CMP29,CP28,CP29
6 *R* 9LE 011233315107 C/M Multi. 330PF 50V NPO J 0402 G Assembly Pull EA 3
6 *R* 9LE 011553315107 C/M Multi. 330PF 50V NPO J 0402 G Assembly Pull EA 3
6 1 9LE 011133335116 C/M MULTI 0.033uF 50V X7R 0603 G Assembly Pull EA 4 CA50,CA59,CA92,CA95
6 *R* 9LE 011553335116 C/M MULTI 0.033uF 50V X7R 0603 G Assembly Pull EA 4
6 *R* 9LE 011233335116 C/M MULTI 0.033uF 50V X7R 0603 G Assembly Pull EA 4
6 1 9LE 011133395107 C/M Multi. 3.3PF 50V NPO 0402 G Assembly Pull EA 4 CM25,CM26,CM29,CM31
6 *R* 9LE 011233395107 C/M Multi. 3.3PF 50V NPO 0402 G Assembly Pull EA 4
6 1 9LE 011134715107 C/M Multi. 470pF 50V NPO J 0402 G Assembly Pull EA 4 CA88,CA89,CA98,CA99
6 *R* 9LE 011234715107 C/M Multi. 470pF 50V NPO J 0402 G Assembly Pull EA 4
6 *R* 9LE 011554715107 C/M Multi. 470pF 50V NPO J 0402 G Assembly Pull EA 4
6 1 9LE 011134725116 C/M MULTI. 4700PF 50V X7R 0603 G Assembly Pull EA 2 CA41,CA44
6 *R* 9LE 011234725116 C/M Multi. 4700PF 50V X7R 0603 G Assembly Pull EA 2
6 1 9LE 011134725117 C/M Multi. 4700PF 50V X7R K 0402 G Assembly Pull EA 1 CP61
6 *R* 9LE 011234725117 C/M Multi. 4700PF 50V X7R K 0402 L-F G Assembly Pull EA 1
6 1 9LE 011134731617 C/M Multi. 0.047uF 16V X7R K 0402 G Assembly Pull EA 5 C405,C407,C408,C409,C410
6 *R* 9LE 011234731617 C/M Multi. 0.047uF 16V X7R K 0402 G Assembly Pull EA 5
6 *R* 9LE 011554731617 C/M Multi. 0.047uF 16V X7R K 0402 G Assembly Pull EA 5
6 1 9LE 011134732516 C/M MULTI 0.047uF 25V X7R 0603 G Assembly Pull EA 2 CA42,CA43
6 *R* 9LE 011234732516 C/M Multi. 0.047uF 25V X7R 0603 L-F G Assembly Pull EA 2
6 1 9LE 011135095107 C/M Multi. 5PF 50V NPO 0402 G Assembly Pull EA 3 CV1,CV2,CV3
6 *R* 9LE 011555095107 C/M Multi. 5PF 50V NPO 0402 G Assembly Pull EA 3
6 *R* 9LE 011235095107 C/M Multi. 5PF 50V COG 0402 L-F G Assembly Pull EA 3
6 1 9LE 011136815106 C/M MULTI 680PF 50V NPO 0603 G Assembly Pull EA 4 CA5,CA6,CA7,CA8
6 *R* 9LE 011236815106 C/M Multi. 680PF 50V NPO 0603 G Assembly Pull EA 4
6 *R* 9LE 011556815106 C/M MULTI 680PF 50V NPO 0603 G Assembly Pull EA 4
6 1 9LE 011231051157 C/M Multi. 1.0uF 10V X5R 0402 G Assembly Pull EA 6 CA78,CH18,CH19,CP19,CT23,CT27
6 *R* 9LE 011551051157 C/M Multi. 1.0uF 10V X5R 0402 G Assembly Pull EA 6
6 *R* 9LE 011131051157 C/M Multi. 1.0uF 10V X5R 0402 G Assembly Pull EA 6
6 1 9LE 011231051616 C/M MULTI 1.0uF 16V X7R 0603 G Assembly Pull EA 2 C429,C430
6 *R* 9LE 011551051616 C/M MULTI 1.0uF 16V X7R K 0603 G Assembly Pull EA 2
6 *R* 9LE 011131051616 C/M MULTI 1.0uF 16V X7R K 0603 G Assembly Pull EA 2
6 1 9LE 011231051657 C/M Multi. 1.0uF 16V X5R 0402 L-F G Assembly Pull EA 2 CS3,CS4
6 1 9LE 011231052556 C/M Multi. 1.0uF 25V X5R 0603 G Assembly Pull EA 7 CA40,CA52,CA60,CA90,CA93,CL14,CP50
6 *R* 9LE 011551052556 C/M Multi. 1.0uF 25V X5R 0603 G Assembly Pull EA 7
6 *R* 9LE 011131052556 C/M Multi. 1.0uF 25V X5R 0603 G Assembly Pull EA 7
6 1 9LE 011231061115 C/M Multi. 10UF 10V X7R K 0805 G Assembly Pull EA 2 C439,C440
6 *R* 9LE 011551061115 C/M Multi. 10UF 10V X7R K 0805 G Assembly Pull EA 2
6 1 9LE 011231061155 C/M Multi. 10uF 10V X5R 0805 L-F G Assembly Pull EA 28
CMP2,CMP20,CMP21,CMP22,CMP24,CMP25,CMP26,CMP3,CMP5,CMP6,CMP7,CP10,CP11,CP
12,CP13,CP14,CP17,CP18,CP34,CP4,CP5,CP64,CP65,CP7,CT25,CT32,CU22,CU3
6 *R* 9LE 011551061155 C/M Multi. 10uF 10V X5R 0805 G Assembly Pull EA 28
6 1 9LE 011231061655 C/M MULTI 10uF 16V X5R K 0805 G Assembly Pull EA 2 CMP12,CMP14
6 *R* 9LE 011551061655 C/M MULTI 10uF 16V X5R K 0805 G Assembly Pull EA 2
