Sharp LC-65LE654U User Manual

Level
Child
P/N
Seq
Specification UIT Supply Type UOM Qty Circuit Number
Child P/N
6 1 9LE 013115021614 RES. MF 15.0 K ohm 1/16W F 0402 G Assembly Pull EA 2 RA74,RA77
6 1 9LE 013116011614 RES. MF 1.6Kohm 1/16W F 0402 G Assembly Pull EA 2 RI19,RI21
6 1 9LE 013118021614 RES. MF 18kohm 1/16W F 0402 G Assembly Pull EA 3 RA44,RMP12,RMP6
6 1 9LE 013120011614 RES. MF 2Kohm 1/16W F 0402 G Assembly Pull EA 1 RP15
6 1 9LE 013120021614 RES. MF 20Kohm 1/16W F 0402 G Assembly Pull EA 1 RP75
6 1 9LE 013121521614 RES. MF 21.5 Kohm 1/16W F 0402 G Assembly Pull EA 1 RP70
6 1 9LE 013122041614 RES. MF 2.2 Mohm 1/16W F 0402 G Assembly Pull EA 1 RM164
6 1 9LE 013122111614 RES. MF 2.21 Kohm 1/16W F 0402 G Assembly Pull EA 1 RMP11
6 1 9LE 013124001614 RES. MF 240ohm 1/16W F 0402 G Assembly Pull EA 1 R60
6 1 9LE 013127021614 RES. MF 27Kohm 1/16W F 0402 G Assembly Pull EA 1 RP85
6 1 9LE 013129421614 RES. MF 29.4Kohm 1/16W F 0402 G Assembly Pull EA 1 RP9
6 1 9LE 013136021614 RES. MF 36Kohm 1/16W F 0402 G Assembly Pull EA 1 RMP5
6 1 9LE 013139021614 RES. MF 39Kohm 1/16W F 0402 G Assembly Pull EA 2 RA70,RA71
6 1 9LE 013143021614 RES. MF 43 Kohm 1/16W F 0402 G Assembly Pull EA 2 RA75,RA76
6 1 9LE 013156221614 RES. MF 56.2Kohm 1/16W F 0402 G Assembly Pull EA 1 RMP4
6 1 9LE 014122093853 ARRAY RES. A(X) 22 ohm 1/16W 4R8P J 0402 G Assembly Pull EA 9 RPM1,RPM2,RPM3,RPM4,RPM5,RPM6,RPM7,RPM8,RPM9
6 1 9LE 018467510083 POLYSWITCH 0.75A 8V SMD (1206L075THYR) HF G Assembly Pull EA 1 FU5
6 *R* 9LE 018467510084 POLYSWITCH 0.75A 8V SMD (KMC3S075RY006) HF G Assembly Pull EA 1
6 1 9LE 030310023417 CONN B TO FPC 0.5mm 41P 90' SMD(196334-41041-3) HF G Assembly Pull EA 1 JM5
6 1 9LE 030310023517 CONN B TO FPC 0.5mm 51P 90' SMD(196334-51041-3) HF G Assembly Pull EA 1 JM4
6 *R* 9LE 030310023516 CONN B TO FPC 0.5mm 51P 90' SMD(FBSNL05002N51) HF G Assembly Pull EA 1
6 1 9LE 030410000510 CONN HDMI 19P 90' SMD WITH SPRING (1165-2CG04-24P) HF G Assembly Pull EA 3 PH4,PH5,PH6
6 1 9LE 035410000150 X'FMR LAN FILTER SMD 16PIN G Assembly Pull EA 1 TN1
6 *R* 9LE 035410000190 X'FMR LAN 10/100Base-T (NS601683) SMD LF G Assembly Pull EA 1
6 1 9LE 036020100170 PWR IND. 10uH 3.2A(LVS808040L-100M-N) LF G Assembly Pull EA 1 LP5
6 *R* 9LE 036020100150 PWR IND 10uH 3.1A (MNR-8040-100M) LF G Assembly Pull EA 1
6 1 9LE 036020100520 PWR IND. 10uH 2.5A 6x6x4.5 (VLC6045T-100M) LF G Assembly Pull EA 4 LA4,LA5,LA6,LA7
6 *R* 9LE 036020100030 PWR IND. 10uH 2.4A (NRS6045T100MMGK) LF G Assembly Pull EA 4
6 *R* 9LE 036020100270 PWR IND. 10uH 3.2A(LVS606045L-100M-N) LF G Assembly Pull EA 4
6 *R* 9LE 036023100520 PWR IND. 10uH 3.4A 6x6x4.5mm(VLS6045EX-100M) HF G Assembly Pull EA 4
6 1 9LE 036020101040 PWR INDUCTOR 10uH 6A 10*10(EM-100M08V01)LF G Assembly Pull EA 1 LP6
6 *R* 9LE 036020101050 IND. MOLDING 10uH 6.5A 10x11x4mm (MMD-10DZ-100M-X2) LF G Assembly Pull EA 1
6 1 9LE 036020229520 PWR IND. 2.2uH 4.8A (VLC6045T-2R2N) LF G Assembly Pull EA 3 LMP2,LMP3,LP2
6 *R* 9LE 036020229550 PWR IND. 2.2uH 4.8A (MNR-6045-2R2N-E) LF G Assembly Pull EA 3
6 *R* 9LE 036023229520 PWR IND. 2.2uH? 5.1A 6x6x4.5mm (VLS6045EX-2R2N) HF G Assembly Pull EA 3
6 1 9LE 037000014252 BEAD 80ohm 6A 0805 GMLB-201209-0080P-N8B HF G Assembly Pull EA 11 FBA1,FBA2,FBA3,FBA4,FBH6,FBM2,FBP4,FBP5,FBP6,FBU2,LA1
6 *R* 9LE 037000014282 CHIP BEAD 80ohm 6A 0805 (GB201212K800TM) LF G Assembly Pull EA 11
6 1 9LE 037000025052 CHIP BEAD 120ohm 6A 0805 (GMLB-201209-0120P-N8B) LF G Assembly Pull EA 1 FBT1
6 1 9LE 037000025153 CHIP BEAD CORE? 0.47uH ±10% 35mA 0603(GMLI-160808-R47K) LF G Assembly Pull EA 2 LT1,LT2
6 1 9LE 037022900128 CHIP INDUCTOR 2.2uH ±20% 1.27A 2520 (LVT252A10-2R2M-N)LF G Assembly Pull EA 3 LMP1,LP1,LP3
6 1 9LE 039050034293 DUAL SURFACE DIODE BAV70-7-F SMD (SOT-23) L-F G Assembly Pull EA 2 DA1,DA5
6 *R* 9LE 039050073273 DUAL SURFACE DIODE BAV70 SMD SOT-23 HF G Assembly Pull EA 2
6 1 9LE 039050042343 GEN. DIODE LL4148WP (CD4148WP) SMD 1206 LF G Assembly Pull EA 4 DA2,DI2,DL1,DP5
6 *R* 9LE 039050071293 DIODE FAST 0.3A 100V 1N4148W-7-F SOD-123 LF G Assembly Pull EA 4
6 1 9LE 039060050293 Schottky Diode 0.2A 30V BAT54C-7-F SOT-23 HF G Assembly Pull EA 3 DV3,DV4,DV5
6 *R* 9LE 039060110273 Schottky Diode 0.2A 30V BAT54C SOT-23 HF G Assembly Pull EA 3
6 1 9LE 039060073413 SCHOTTKY DIODE 5A 40V SM540C SMC LF G Assembly Pull EA 1 DP2
6 *R* 9LE 039060073103 SCHOTTKY DIODE 5A 40V MBRS540T3G SMC LF G Assembly Pull EA 1
6 *R* 9LE 039060073293 SCHOTTKY DIODE 5A 40V B540C-13-F SMC LF G Assembly Pull EA 1
6 1 9LE 039060086413 SCHOTTKY DIODE 0.2A 30V SCS520S SOD-523 2PIN LF G Assembly Pull EA 1 DA6
6 *R* 9LE 039060086203 SCHOTTKY DIODE 0.2A 30V RB520S- 30F SOD-523 LF G Assembly Pull EA 1
Confidential-do not copy
Page 14-9
File No. SG-0000351
