Sharp LC-65LE654U User Manual

Level
Child
P/N
Seq
Specification UIT Supply Type UOM Qty Circuit Number
Child P/N
6 1 9LE 040003215717 ZENER 3.25~3.50V KDZ3.3VY 1/5W SOD-323 LF G Assembly Pull EA 1 ZDL4
6 *R* 9LE 040003315012 ZENER 3.32~3.53V UDZSTE-17 3.3B 1/5W SOD-323 LF G Assembly Pull EA 1
6 1 9LE 040011715012 ZENER 11.74~12.24V UDZSTE-1712B 1/5W SOD-323 LF G Assembly Pull EA 1 ZDA3
6 *R* 9LE 040011415015 ZENER 11.4~12.7V BZT52C12S-7-F 1/5W SOD-323 LF G Assembly Pull EA 1
6 1 9LE 040013815713 ZENER 13.8-15.6V BZT52C15S-7-F 1/5W SOD-323 LF G Assembly Pull EA 1 ZDL1
6 *R* 9LE 040014215010 ZENER 14.25-15.75V MM3Z15VCWF 1/5W SOD-323 LF G Assembly Pull EA 1
6 1 9LE 041050005638 TR NPN 0.2A 40V LMBT3904LT1G SOT-23 HF G Assembly Pull EA 8 QA1,QA3,QA4,QH10,QH11,QI2,QL1,QP10
6 *R* 9LE 041050005643 TR NPN 0.2A 40V METR3904-G SOT-23 HF G Assembly Pull EA 8
6 1 9LE 041050005738 TR PNP 0.2A 40V LMBT3906LT1G SOT-23 L-F G Assembly Pull EA 1 QH14
6 *R* 9LE 041050005743 TR PNP 0.2A 40V METR3906-G SOT-23 HF G Assembly Pull EA 1
6 1 9LE 042010049630 MOSFET N-CH 2N7002-7-F 115mA 60V SMD (SOT-23) L-F G Assembly Pull EA 2 QL3,QL4
6 *R* 9LE 042010126611 MOSFET N-CH 300mA 60V 2N7002 SOT-23 HF G Assembly Pull EA 2
6 1 9LE 042020073636 MOSFET P-CH 9.5A 30V SSG4835P SOP 8PIN LF G Assembly Pull EA 1 UL2
6 *R* 9LE 042020093642 MOSFET P-CH 9A 30V APM4317KC-TRG SOP-8 HF G Assembly Pull EA 1
6 1 9LE 042020092643 MOSFET P-CH 3.2A 30V ME2303-G SOT-23 HF G Assembly Pull EA 1 QP4
6 *R* 9LE 042020058629 MOSFET P-CH 3.7A 30V AP2309GN SOT-23 3PIN LF G Assembly Pull EA 1
6 *R* 9LE 042020091642 MOSFET P-CH 4A 30V APM2303AC-TRG SOT-23-3 HF G Assembly Pull EA 1
6 1 9LE 043030163045 IC SERIAL FLASH 32M MX25L3206EM2I-12G SOP-8 LF G Assembly Pull EA 1 UM2
6 1 9LE 043050325953 IC MEMC PA136PDG eLQFP-208 LF G Assembly Pull EA 1 UM1
6 1 9LE 043060381075 IC CMOS LDO 300mA ADJ AX6646BTA TSOT-23-5L LF G Assembly Pull EA 1 UMP1
6 1 9LE 043060437039 IC STEP-DOWN CONV 1.5A 6V LA8013ACD SOT-23-5 LF G Assembly Pull EA 3 UMP2,UP15,UP4
6 *R* 9LE 043060442044 IC STEP-DOWN CONV 1.2A 6V IT7801TS SOT-23-5 LF G Assembly Pull EA 3
6 1 9LE 043060440015 IC STEP-DOWN CONV 5A 28V TPS54531DDAR SOIC-8 PowerPAD HF G Assembly Pull EA 1 UP2
6 1 9LE 043060454044 IC STEP-DOWN DC/DC CONV 3A 23V IT76630M-1 SOP8-EP LF G Assembly Pull EA 1 UP17
6 *R* 9LE 0430604260C1 IC STEP-DOWN CONV 3A 23V FR9889SPCTR SOP-8 LF G Assembly Pull EA 1
6 1 9LE 043060460052 IC STEP-DOWN CONV 3.5A 18V RT7295AGJ6F TSOT-23-6 HF G Assembly Pull EA 3 UMP4,UMP5,UP16
6 1 9LE 043070865615 IC AUDIO OP DRV632PWR TSSOP-14 HF G Assembly Pull EA 1 UA2
6 1 9LE 043070942715 IC AUDIO POWER AMP 20W TAS5707LPHPR HTQFP-48 HF G Assembly Pull EA 1 UA1
6 1 9LE 043071043079 IC POWER SWITCH 2.1A AP2191WG-7 SOT-23-5 HF G Assembly Pull EA 1 UH3
6 1 9LE 043140032977 IC TV CONTROLLER RTD2986ID-GR TQFP(ePAD)-176? LF G Assembly Pull EA 1 U401
6 1 9LE 043160003937 IC DDR2 32M*16 W9751G6KB WBGA 84PIN HF G Assembly Pull EA 1 UMD1
6 1 9LE 043170019660 IC NAND FLASH 4Gb MT29F4G08ABAEAWP:E TSOP-48 LF G Assembly Pull EA 1 US3
6 1 9LE 045112500486 WAFER 1.25mm 4P 180' SMD (MS24014) L-F G Assembly Pull EA 1 JM2
6 1 9LE 366502720150B MAIN BD ASS'Y LC-65LE654U_AUO_T650HVN05.502_RTD2986ID BOT P Phantom EA 1
7 1 9LE 011131031617 C/M Multi. 0.01uF 16V X7R K 0402 G Assembly Pull EA 2 CN3,CN6
7 *R* 9LE 011231031617 C/M Multi. 0.01uF 16V X7R K 0402 G Assembly Pull EA 2
7 *R* 9LE 011551031617 C/M Multi. 0.01uF 16V X7R 0402 (CL05B103KO5NNN) G Assembly Pull EA 2
7 1 9LE 011131041617 C/M Multi. 0.1uF 16V X7R 0402 G Assembly Pull EA 68
C10,C11,C12,C13,C130,C131,C15,C16,C17,C18,C19,C20,C21,C22,C23,C24,C3,C4,C401,C420,
C437,C442,C443,C444,C445,C446,C447,C448,C450,C454,C460,C461,C462,C463,C464,C465,C
466,C5,C6,C7,C8,CH17,CH24,CM100,CM102,CM114,CM115,CM116,CM117,CM118,CM49,CM5
9,CM61,CM63,CM65,CM67,CM69,CM75,CM77,CM79,CM81,CM83,CM88,CM90,CM98,CN2,CN5,
CV36
7 *R* 9LE 011231041617 C/M Multi. 0.1uF 16V X7R 0402 G Assembly Pull EA 68
7 *R* 9LE 011551041617 C/M Multi. 0.1uF 16V X7R K 0402 (CL05B104KO5NNNC) G Assembly Pull EA 68
7 1 9LE 011131042516 C/M Multi. 0.1uF 25V X7R 0603 G Assembly Pull EA 6 CA45,CA49,CA61,CA62,CA64,CA65
7 *R* 9LE 011231042516 C/M Multi. 0.1uF 25V X7R 0603 G Assembly Pull EA 6
7 *R* 9LE 011551042516 C/M Multi. 0.1uF 25V X7R 0603 G Assembly Pull EA 6
7 1 9LE 011131045116 C/M MULTI 0.1uF 50V X7R 0603 G Assembly Pull EA 1 CA67
7 *R* 9LE 011231045116 C/M Muitl. 0.1uF 50V X7R 0603 G Assembly Pull EA 1
7 *R* 9LE 011551045116 C/M Muitl. 0.1uF 50V X7R 0603 G Assembly Pull EA 1
Confidential-do not copy
Page 14-10
File No. SG-0000351
