Level
Child
P/N
Seq
Specification UIT Supply Type UOM Qty Circuit Number
Child P/N
7 1 9LE 011134715107 C/M Multi. 470pF 50V NPO J 0402 G Assembly Pull EA 28
CM101,CM105,CM107,CM109,CM111,CM113,CM53,CM55,CM57,CM58,CM60,CM62,CM64,CM6
6,CM68,CM74,CM76,CM78,CM80,CM82,CM84,CM87,CM89,CM92,CM94,CM96,CM97,CM99
7 *R* 9LE 011234715107 C/M Multi. 470pF 50V NPO J 0402 G Assembly Pull EA 28
7 *R* 9LE 011554715107 C/M Multi. 470pF 50V NPO J 0402 G Assembly Pull EA 28
7 1 9LE 011231051157 C/M Multi. 1.0uF 10V X5R 0402 G Assembly Pull EA 14 C9,CA79,CM104,CM106,CM108,CM110,CM112,CM52,CM54,CM56,CM91,CM93,CM95,CP21
7 *R* 9LE 011551051157 C/M Multi. 1.0uF 10V X5R 0402 G Assembly Pull EA 14
7 *R* 9LE 011131051157 C/M Multi. 1.0uF 10V X5R 0402 G Assembly Pull EA 14
7 1 9LE 011231051616 C/M MULTI 1.0uF 16V X7R 0603 G Assembly Pull EA 1 C421
7 *R* 9LE 011551051616 C/M MULTI 1.0uF 16V X7R K 0603 G Assembly Pull EA 1
7 *R* 9LE 011131051616 C/M MULTI 1.0uF 16V X7R K 0603 G Assembly Pull EA 1
7 1 9LE 011231052556 C/M Multi. 1.0uF 25V X5R 0603 G Assembly Pull EA 2 CA54,CA55
7 *R* 9LE 011131052556 C/M Multi. 1.0uF 25V X5R 0603 G Assembly Pull EA 2
7 *R* 9LE 011551052556 C/M Multi. 1.0uF 25V X5R 0603 G Assembly Pull EA 2
7 1 9LE 011231061114 C/M Multi. 10UF 10V X7R 1206 G Assembly Pull EA 1 CA48
7 *R* 9LE 011551061114 C/M Multi. 10UF 10V X7R 1206 G Assembly Pull EA 1
7 1 9LE 011231061155 C/M Multi. 10uF 10V X5R 0805 L-F G Assembly Pull EA 1 CA68
7 *R* 9LE 011551061155 C/M Multi. 10uF 10V X5R 0805 G Assembly Pull EA 1
7 1 9LE 011231066086 C/M MULTI 10UF 6.3V X5R M 0603 G Assembly Pull EA 6 C457,C458,C467,C474,CM179,CM180
7 *R* 9LE 011551066086 C/M MULTI 10UF 6.3V X5R M 0603 G Assembly Pull EA 6
7 1 9LE 011232251116 C/M MULTI 2.2UF 10V K X7R 0603 G Assembly Pull EA 4 C438,C449,C451,C455
7 *R* 9LE 011132251116 C/M MULTI. 2.2UF 10V K X7R 0603 G Assembly Pull EA 4
7 *R* 9LE 011552251116 C/M MULTI 2.2UF 10V K X7R 0603 G Assembly Pull EA 4
7 1 9LE 011232266085 C/M MULTI 22UF 6.3V X5R M 0805 L-F G Assembly Pull EA 12 C173,CM175,CM176,CM177,CM178,CM181,CM182,CM183,CM184,CM185,CM186,CM187
7 *R* 9LE 011552266085 C/M MULTI 22UF 6.3V X5R M 0805 L-F G Assembly Pull EA 12
7 1 9LE 011234751655 C/M Multi 4.7uF 16V X5R K 0805 L-F G Assembly Pull EA 1 CA51
7 *R* 9LE 011134751655 C/M Multi 4.7uF 16V X5R K 0805 L-F G Assembly Pull EA 1
7 *R* 9LE 011554751655 C/M Multi 4.7uF 16V X5R K 0805 G Assembly Pull EA 1
7 1 9LE 013000000055 RES. CF 0.0ohm 1/10W J 0603 G Assembly Pull EA 3 R1,R2,R454
7 1 9LE 013000001654 RES. CF 0ohm 1/16W J 0402 G Assembly Pull EA 7 R407,R408,RH45,RH46,RH47,RH50,RH51
7 1 9LE 013000001858 RES. CF 0.0ohm 1/8W J 0805 G Assembly Pull EA 3 R3,R4,RA48
7 1 9LE 013010001654 RES. CF 100ohm 1/16W J 0402 G Assembly Pull EA 5 R27,RH25,RH26,RH27,RH28
7 1 9LE 013010011654 RES. CF 1Kohm 1/16W J 0402 G Assembly Pull EA 3 RH63,RH64,RP19
7 1 9LE 013010021654 RES. CF 10Kohm 1/16W J 0402 G Assembly Pull EA 6 R30,RH40,RH42,RM160,RM161,RM162
7 1 9LE 013010041654 RES. CF 1Mohm 1/16W J 0402 G Assembly Pull EA 1 RH53
7 1 9LE 013010080055 RES. CF 1.0ohm 1/10W J 0603 G Assembly Pull EA 1 R63
7 1 9LE 013010091654 RES. CF 10ohm 1/16W J 0402 G Assembly Pull EA 5 RM179,RM180,RM181,RM182,RM183
7 1 9LE 013020001654 RES. CF 200ohm 1/16W J 0402 G Assembly Pull EA 1 RH24
7 1 9LE 013022091654 RES. CF 22ohm 1/16W J 0402 G Assembly Pull EA 2 R57,R58
7 1 9LE 013030031654 RES. CF 300K ohm 1/16W J 0402 G Assembly Pull EA 1 RH49
7 1 9LE 013047011654 RES. CF 4.7Kohm 1/16W J 0402 G Assembly Pull EA 22
R145,R146,R412,R416,R423,R424,R431,R432,R433,R434,R435,R444,RA85,RA86,RH18,RH19,
RH20,RH21,RH35,RS11,RV56,RV57
7 1 9LE 013047021654 RES. CF 47Kohm 1/16W J 0402 G Assembly Pull EA 2 RH62,RH71
7 1 9LE 013056031654 RES. CF 560Kohm 1/16W J 0402 G Assembly Pull EA 1 RH41
7 1 9LE 013075090055 RES. CF 75ohm1/10W J 0603 G Assembly Pull EA 2 RN1,RN2
7 1 9LE 013110011614 RES. MF 1K ohm 1/16W F 0402 G Assembly Pull EA 2 R61,R62
7 1 9LE 013122120015 RES. MF 22.1Kohm 1/10W F 0603 G Assembly Pull EA 1 RA58
7 1 9LE 013131611614 RES. MF 3.16K ohm 1/16W F 0402 G Assembly Pull EA 1 RV58
7 1 9LE 013149991614 RES. MF 49.9ohm 1/16W F 0402 G Assembly Pull EA 2 R49,R50
7 1 9LE 013162011614 RES. MF 6.2Kohm 1/16W F 0402 G Assembly Pull EA 1 R403
7 1 9LE 017122725678 PCB MAIN BD 185*141*1.6t 4L (LC-65LE654U)(1:2) G Assembly Pull EA 1
Confidential-do not copy
Page 14-11
File No. SG-0000351
