MD-C2
– 82 –
1 DEFI Input Input terminal of detect detection signal (DEF).
2 TAI Input For PLL Input terminal for test. Pull-down resistor is integrated.
3 PDD Output Output terminal of phase comparison for external VCO control.
4 VVSS – Ground terminal for integrated VCO.
5 ISET AI Resistance connection terminal for current adjustment of PDO output.
6 VVDD – Power terminal for integrated VCO.
7 FR AI VCO frequency range adjustment.
8 VSS – Ground terminal of digital system.
9 EFMO Output For slice level control EFM signal output terminal.
10 EFMIN Input EFM signal input terminal.
11 TEST2 Input Input terminal for test. Pull-down resistor is integrated.
12 CLV+ Output Output for disk motor control. 3 values can be output with the commands.
13 CLV- Output Output for disk motor control. 3 values can be output with the commands.
14 V/*P Output Monitor output terminal for automatic switch of rough servo/phase control
"H" for rough servo, and "L" for phase servo.
15 HLF Input Input terminal of track detection signal. Schmit input.
16 TES Input Input terminal of tracking error signal. Schmit input.
17 TOFF Output Tracking OFF output terminal.
18 TGL Output Output terminal for switch of tracking gain "L" increses the gain.
19 JP+ Output Output for track jump control. 3 values can be output with the commands.
20 JP- Output Output for track jump control. 3 values can be output with the commands.
21* PCK Output Clock monitor terminal for EFM data replay. 4,3218MHz as phase clock.
22* FSEQ Output Output terminal synchronous signal detection. "H" is output when synchronous signal detected
by EFM signal matches synchronous signal internally generated.
23* VDD – Power terminal of digital system.
24 CONT1 In/Output General purpose input/output terminal 1
25 CONT2 In/Output General purpose input/output terminal 2
26 CONT3 In/Output General purpose input/output terminal 3
27 CONT4 In/Output General purpose input/output terminal 4
28* CONT5 In/Output General purpose input/output terminal 5
29* EMPH/CONT6 Output Difference monitor terminal At "H", deemphasis disk being replayed.
30* C2F Output C2 flag output terminal.
31 DOUT Output Output terminal of digital OUTPUT. (EIAJ format)
32* TEST3 Input Input terminal for test. Pull-down resistor is integrated.
33 TEST4 Input Input terminal for test. Pull-down resistor is integrated.
34 PCCL Input Terminal not used. Open during operation.
35* MUTEL/CONT7 Output L channel 1 bit DAC Mute outout terminal for L channel.
36 LVDD – Power terminal for L channel.
37 LCHO Output L channel output terminal.
38 LVSS – Ground terminal for L channel Surely connected to 0V.
39 RVSS – R channel 1 bit DAC Ground terminal for R channel Surely connected to 0V.
40 RCHO Output R channel output terminal.
41 RVDD – Power terminal for R channel.
42* MUTER/CONT8 Output Mute output terminal for R channel.
43 XVDD – Power terminal for quartz oscillation.
44 XOUT Output Ground terminal of 16.9344MHz quartz oscillator.
45 XIN Input Ground terminal of 16.9344MHz quartz oscillator.
46 XVSS – Ground terminal for quartz oscillation.
47* SBSY Output Output terminal of synchronous signal of subcode block.
48 EFLG Output Correction monitor terminal of C1, C2, signal and double.
49* PW Output Output terminal of subcodes P, A, R, S, T, U and W.
50* SFSY Output Output terminal of synchronous signal of subcode frame. It drops when subcode stands by.
IC2 VHiLC78622N-1: Servo/Signal Control (LC78622NE) (1/2)
Pin No.
Function
Terminal Name
Input/Output
In this unit, the terminal with asterisk mark (*) is (open) terminal which is not connected to the outside.
Controlled with serial data command
from microcomputer.
When not used, set it as the input terminal and
open it by connecting to 0V, or set it as the output
terminal and open it.
