Sharp MD-C2 User Manual

PRICE
RANK
DESCRIPTIONNO. PARTS CODE NO. PARTS CODE
PRICE
RANK
DESCRIPTION
MD-C2
– 1 –
INTEGRATED CIRCUITS
IC1 VHILA9241M/-1 J AS Servo Amp.,LA9241M
IC2 VHILC78622N-1 J AY Servo/Signal Control,
LC78622NE
IC3 VHIM63001FP-1 J AX Focus/Tracking/Spin/Sled/
Loading Driver,M63001FP
IC301 VHITA7358AP-1 J AG FM Front End,TA7358AP
IC302 VHILC72131/-1 J AP PLL Controller LC72131
IC303 VHILA1805//-1 J AM AM/FM IF/FM DET./MPX.,
LA1805
IC800 VHIAN78L05/-1 J AE Constant Voltage Regulator,
AN78L05
IC801 VHIKIA7812P-1 J AE Voltage Regulator,KIA7812P
IC803 VHIKIA7806P-1 J AG Voltage Regulator,KIA7806P
IC1101 VHIIR3R55//-1 J AQ RF Signal,Processor,IR3R55
IC1201 VHILR376484-1 J BC ATRAC Encoder/Decoder,
LR376484
IC1202 RH-IX2474AFZZ J BF 4Mbit D-RAM,IX2474AF
IC1300 VHI74ACT02F-1 J AF Head Driver,74ACT02F
IC1401 RH-IX0276AWZZ J MD System Microcomputer,
IX0276AW
IC1402 VHIS29294A/-1 J AH EEPROM,S29294A
IC1601 VHIM56788FP-1 J AX Motor Driver,M56788FP
IC1602 VHILB1930M/-1 J AH Motor Driver,LB1930M
IC1701 VHIUDA1344/-1 J AY AD/DA Converter UDA1344
IC1702 VHINJM431U/-1 J AE Regulator,NJM431U
IC1801 VHIXC62EP32-1 J AE Regulator,XC62EP32
ICD01 RH-IX0266AWZZ J AZ FL Driver,IX0266AW
ICF01 RH-IX0265AW00 J BQ System Control Microcomputer,
IX0265AW
ICG01 VHI74VHC00F-1 J AE Invertor,74VHC00F
ICG02 VHIPST9140/-1 J AG Reset,PST9140
ICH01 VHINJM4558MF- J AE Ope Amp.,NJM4558MF
ICK01 VHIAN7345K/-1 J AM Playback and Record/Playback
Amp.,AN7345K
ICS01 VHINJM4565M-1 J AC Buffer Amp.,NJM4565M
ICT21 VHILC72720/-1 J AW RDS Decorder,LC72720
ICU00 VHILC75397E-1 J BD Audio Processor,LC75397E
ICU01 VHINJM4558MF- J AE Ope Amp.,NJM4558MF
ICV00 VHISTK40705-1 J BA Power Amp.,STK40705
TRANSISTORS
Q1 VSKTA1266GR-1 J AB Silicon,PNP,KTA1266 GR
Q51 VSKRC102M//-1 J AC Digital,NPN,KRC102 M
Q52 VSKTC3203Y/-1 J AC Silicon,NPN,KTC3203 Y
Q302 VS2SC535-C/-1 J AC Silicon,NPN,2SC535 C
Q342 VSHSC1815GR-1 J AC Silicon,NPN,HSC1815 GR
Q343 VSKRA109M//-1 J AC Digital,PNP,KRA109 M
Q344 VSHSA1015GR-1 J AC Silicon,PNP,HSA1015 GR
Q800 VS2SB1375//-1 J AF Silicon,PNP,2SB1375
Q807 VS2SD2012//-1 J AD Silicon,NPN,2SD2012
Q808 VSHSC1815GR-1 J AC Silicon,NPN,HSC1815 GR
Q809 VS2SD2012//-1 J AD Silicon,NPN,2SD2012
Q811 VSKRC107M//-1 J AC Digital,NPN,KRC107 M
Q900 VSHSC1815GR-1 J AC Silicon,NPN,HSC1815 GR
Q1300 VSBSH103///-1 J AF FET,BSH103
Q1301 VS2SK2911//-1 J AE FET,2SK2911
Q1302 VSBSH103///-1 J AF FET,BSH103
Q1303 VS2SK2911//-1 J AE FET,2SK2911
Q1400,1401 VSRNC1404//-1 J AB Digital,NPN,RNC1404
Q1402,1403 VSRN2404///-1 J AC Digital,PNP,RN2404
Q1500 VSRNC1407//-1 J AC Digital,NPN,RNC1407
Q1700 VS2SC2412KR-1 J AB Silicon,NPN,2SC2412 KR
Q1701 VSRNC1404//-1 J AB Digital,NPN,RNC1404
Q1702 VS2SA1162G/-1 J AB Silicon,PNP,2SA1162 G
Q1800 VSRNC1407//-1 J AC Digital,NPN,RNC1407
Q1801 VS2SA1162G/-1 J AB Silicon,PNP,2SA1162 G
Q1802 VSRNC1407//-1 J AC Digital,NPN,RNC1407
Q1803 VSRN1406///-1 J AB Digital,NPN,RN1406
Q1804,1805 VS2SA1314C/-1 J AD Silicon,PNP,2SA1314 C
Q1806 VSRN1406///-1 J AB Digital,NPN,RN1406
QD01 VSHSC1815GR-1 J AC Silicon,NPN,HSC1815 GR
QD04~14 VSKRC107M//-1 J AC Digital,NPN,KRC107 M
QG01 VSKRC107M//-1 J AC Digital,NPN,KRC107 M
QG02,03 VSKTC3199GR-1 J AB Silicon,NPN,KTC3199 GR
QK01~04 VS2SC2389SS-1 J AD Silicon,NPN,2SC2389 SS
QK05,06 VSHSC1815GR-1 J AC Silicon,NPN,HSC1815 GR
QK07 VSHSA1015GR-1 J AC Silicon,PNP,HSA1015 GR
QK08~10 VSKRC104M//-1 J AC Digital,NPN,KRC104 M
QK11~14 VSHSC1815GR-1 J AC Silicon,NPN,HSC1815 GR
QK15 VSHSA1015GR-1 J AC Silicon,PNP,HSA1015 GR
QK16 VSKRC104M//-1 J AC Digital,NPN,KRC104 M
QK19 VS2SC2236-Y-1 J AB Silicon,NPN,2SC2236 Y
QM01 VSHE8550D//-1 J AF Silicon,PNP,HE8550 D
QM02 VSHE8550SD1-1 J AD Silicon,PNP,HE8550 SD
QM04~06 VSKRC107M//-1 J AC Digital,NPN,KRC107 M
QS01 VSKRA107M//-1 J AE Digital,PNP,KRA107 M
QS02 VS2SK246GR/-1 J AB FET,2SK246 GR
QT21 VSHSC1815GR-1 J AC Silicon,NPN,HSC1815 GR
QU02,03 VSHSC1815GR-1 J AC Silicon,NPN,HSC1815 GR
QU07 VSHSA1015GR-1 J AC Silicon,PNP,HSA1015 GR
QV00~04 VSHSC1815GR-1 J AC Silicon,NPN,HSC1815 GR
QV06 VSHSC1815GR-1 J AC Silicon,NPN,HSC1815 GR
QV07 VSKTA1270Y/-1 J AD Silicon,PNP,KTA1270 Y
QV08 VSKRC107M//-1 J AC Digital,NPN,KRC107 M
DIODES
D1 VHD1SS133//-1 J AA Silicon,1SS133
D81,82 VHD1SS133//-1 J AA Silicon,1SS133
D91~93 VHD1SS133//-1 J AA Silicon,1SS133
D301~303 VHDDS1SS133-1 J AB Silicon,1SS133
D341,342 VHDDS1SS133-1 J AB Silicon,1SS133
D361,362 VHDDS1SS133-1 J AB Silicon,1SS133
D800 VHDTS6B04GM-1 J AP Silicon,TS6B04G
D801~812 VHD1N4004S/-1 J AB Silicon,1N4004S
D813 VHDDS1SS133-1 J AB Silicon,1SS133
D814 VHD1N4004S/-1 J AB Silicon,1N4004S
D815 VHDDS1SS133-1 J AB Silicon,1SS133
D816,817 VHD1N4004S/-1 J AB Silicon,1N4004S
D818 VHDDS1SS133-1 J AB Silicon,1SS133
D819 VHDDS1SS133-1 J AB Silicon,1SS133
D820 VHD1N4004S/-1 J AB Silicon,1N4004S
D900~903 VHD1N4004S/-1 J AB Silicon,1N4004S
D906 VHDDS1SS133-1 J AB Silicon,1SS133
D1300,1301 VHDSB0209CP-1 J AC Silicon,SB0209CP
D1401 VHDSB00703Q-1 J AB Silicon,SB00703Q
DD01 VHEDZ5R1BSB-1 J AC Zener,5.1V,DZ5.1B
DD02 VHD1N4004S/-1 J AB Silicon,1N4004S
DG02~05 VHDDS1SS133-1 J AB Silicon,1SS133
DH03~10 VHDDS1SS133-1 J AB Silicon,1SS133
DM01~03 VHDDS1SS133-1 J AB Silicon,1SS133
DS01 VHDDS1SS133-1 J AB Silicon,1SS133
DU00~03 VHDDS1SS133-1 J AB Silicon,1SS133
DU04~06 VHDDS1SS133-1 J AB Silicon,1SS133
DV00~06 VHDDS1SS133-1 J AB Silicon,1SS133
DV08 VHDDS1SS133-1 J AB Silicon,1SS133
LEDD01 VHPSLI342UCE1 J AC LED,Red,SLI342UCE
LEDD02,03 VHPSLI342YCB1 J AC LED,Yellow,SLI342YCB
LEDD04~07 VHPSLI342YCE1 J AC LED,Yellow,SLI342YCE
LEDD08 VHPLMKD515B-1 J AE LED,Green,LMKD515B
LEDD09,10 VHPSLI342YCG1 J AE LED,Yellow,SLI342YCG
LEDD11~13 VHP333GTH4/-1 J AC LED,Green,333GTH4
LEDD14~17 VHP333GTH2/-1 J AD LED,Green,333GTH2
LEDD18 VHPSLI342UCE1 J AC LED,Red,SLI342UCE
LEDD19 VHPSLI342YCE1 J AC LED,Yellow,SLI342YCE
LEDD20 VHPLMKD515B-1 J AE LED,Green,LMKD515B
LEDD21~23 VHP333GTH4/-1 J AC LED,Green,333GTH4
VD301 VHCKV1236Z23F J AS Variable Capacitance,
KV1236Z23F
VD303,304 VHCKDV147B/-1 J AH Variable Capacitance, KDV147B
ZD61 VHEMTZJ5R6B-1 J AD Zener,5.6V,MTZJ5.6B
ZD351 VHEDZ5R1BSB-1 J AC Zener,5.1V,DZ5.1B
ZD800 VHEDZ330BSD-1 J AC Zener,33V,DZ330D
ZD801 VHEDZ5R6BSC-1 J AC Zener,5.6V,DZ5.6C
ZD803 VHEDZ130BSA-1 J AC Zener,13V,DZ130A
ZD805 VHEDZ6R2BSB-1 J AC Zener,6.2V,DZ6.2B
ZD806 VHEDZ5R1BSB-1 J AC Zener,5.1V,DZ5.1B
ZD808 VHEDZ7R5BSA-1 J Zener,7.5V,DZ7.5A
ZD810 VHEDZ6R8BSA-1 J AC Zener,6.8V,DZ6.8A
ZDG02 VHEDZ3R0BSA-1 J AB Zener,3V,DZ3.0B
ZDV00 VHEDZ5R6BSB-1 J AC Zener,5.6V,DZ5.6B
FILTERS
BF301 92LFILTF1759A J AD FM Band Pass Filter
CF301 RFILF0124AFZZ J AD FM IF,10.7 MHz
CF352 RFILA0009AWZZ J AE AM IF
TRANSFORMERS
T301 RCILI0007AWZZ J AD FM IF
MD-C2
