Sharp MD-C2 User Manual

NO.
PRICE
RANK
DESCRIPTION
PARTS CODENO. PARTS CODE
PRICE
RANK
DESCRIPTION
MD-C2
T302 RCILA1064AFZZ J AD AM Tracking
T304 RCILB1074AFZZ J AC AM Band Coverage
T351 RCILI0011AWZZ J AD AM IF
T352 RCILI0312AFZZ J AC FM Detector
! T900 RTRNP0235AWZZ J BE Power,Main
! T901 RTRNP0266AWZZ J AQ Power,Sub
COILS
L61 VP-XHR82K0000 J AC 0.82 µH
L302 RCILR0029AWZZ J AA FM RF
L303 RCILB0045AWZZ J AD FM Band Coverage
L343 VP-DH101K0000 J AB 100 µH,Choke
L900 RCILZ0019AWZZ J AE Line Filter
L1101 VPBNN100K0000 J AC 10 µH
L1200 VPBNN4R7K0000 J AC 4.7 µH
L1201 VPBNNR47K0000 J AC 0.47 µH
L1300 VP-NM470K0000 J AC 47 µH
L1501 RCILZ0016AWZZ J AD 1 µH
L1503 VPBNN4R7K0000 J AC 4.7 µH
L1600 RCILZ0016AWZZ J AD 1 µH
L1602 RCILZ0016AWZZ J AD 1 µH
L1700,1701 VPBNN100K0000 J AC 10 µH
L1910 VPBNNR47K0000 J AC 0.47 µH
LD01 VP-DH2R2K0000 J AB 2.2 mmH,Peaking
LE51 VP-XH2R2K0000 J AB 2.2 µH,Choke
LG01~03 VP-DH2R2K0000 J AB 2.2 mmH,Peaking
LK01,02 VP-MK182K0000 J AC 1.8 mH,Choke
LK03 VP-MK102K0000 J AB 1 mH,Choke
LK04 VP-MK331K0000 J AB 330 µH,Choke
VARIABLE RESISTOR
VR351 RVR-M0025AWZZ J AC 6.8 kohms (B),VCO Adjustment
VIBRATORS
X352 RCRSP0002AWZZ J AH Crystal,4.5 MHz
XL1 RCRSP0005AWZZ J AF Crystal,16.934 MHz
XL1201 RCRSC0001AWZZ J AL Crystal,33.8688 MHz
XLD01 RCRSP0003AWZZ J AH Crystal,4.194304 MHz
XLF01 RCRM-0037AWZZ J AG Ceramic,8.38 MHz
CAPACITORS
C1 VCEAZA1CW476M J AB 47 µF,16V,Electrolytic
C2 VCKYTV1HB103K J AA 0.01 µF,50V
C3 VCEAZA1HW105M J AB 1 µF,50V,Electrolytic
C4 VCEAZA1HW104M J AB 0.1 µF,50V,Electrolytic
C5,6 VCTYPA1CX333K J AA 0.033 µF,16V
C7 VCEAZA1HW104M J AB 0.1 µF,50V,Electrolytic
C8 VCTYPA1CX683K J AA 0.068 µF,16V
C9 VCTYPA1CX473K J AA 0.047 µF,16V
C10 VCCSTV1HL181J J AA 180 pF,50V
C11,12 VCTYPA1CX104K J AB 0.1 µF,16V
C13 VCKYTV1HB331K J AA 330 pF,50V
C14,15 VCKYTV1HB103K J AA 0.01 µF,50V
C16 VCKYTV1HB472K J AA 0.0047 µF,50V
C17 VCKYTV1HB102K J AA 0.001 µF,50V
C18 VCEAZA1HW474M J AB 0.47 µF,50V,Electrolytic
C19 VCEAZA1HW105M J AB 1 µF,50V,Electrolytic
C20 VCEAZA1CW476M J AB 47 µF,16V,Electrolytic
C21 VCKYTV1HB332K J AA 0.0033 µF,50V
C22 VCCSPA1HL221J J AA 220 pF,50V
C23 VCKYTV1HB272K J AA 0.0027 µF,50V
C24 VCCSTV1HL2R2C J AB 2.2 pF,50V
C25 VCCSTV1HL270J J AA 27 pF,50V
C26 VCTYPA1CX333K J AA 0.033 µF,16V
C27 VCKYTV1HB102K J AA 0.001 µF,50V
C28 VCTYPA1CX104K J AB 0.1 µF,16V
C29 VCEAZA1HW475M J AB 4.7 µF,50V,Electrolytic
C30 VCEAZA1HW104M J AB 0.1 µF,50V,Electrolytic
C31 VCEAZA0JW227M J AC 220 µF,6.3V,Electrolytic
C32 VCKYTV1HB103K J AA 0.01 µF,50V
C33 VCEAZA1HW474M J AB 0.47 µF,50V,Electrolytic
C34 VCEAZA1HW334M J AB 0.33 µF,50V,Electrolytic
C35 VCEAZA1HW105M J AB 1 µF,50V,Electrolytic
C36 VCEAZA1CW107M J AC 100 µF,16V,Electrolytic
C37 VCKZPA1HF223Z J AA 0.022 µF,50V
C38 VCKYTV1HB103K J AA 0.01 µF,50V
C39,40 VCKZPA1HF473Z J AA 0.047 µF,50V
C41 VCCSPA1HL120J J AA 12 pF,50V
C42 VCCSPA1HL150J J AA 15 pF,50V
C43 VCEAZA0JW337M J AC 330 µF,6.3V,Electrolytic
C44~47 VCCCTV1HH101J J AA 100 pF (CH),50V
C48 VCCSPA1HL101J J AA 100 pF,50V
C49 VCCCTV1HH101J J AA 100 pF (CH),50V
C50 VCKYTV1EF223Z J AA 0.022 µF,25V
C51,52 VCEAZA1CW107M J AC 100 µF,16V,Electrolytic
C54 VCKYTV1HB102K J AA 0.001 µF,50V
C55 VCEAZA1CW107M J AC 100 µF,16V,Electrolytic
C56 VCKYTV1EF223Z J AA 0.022 µF,25V
C57 VCKYBT1HB102K J AA 0.001 µF,50V
C71,72 VCEAZA1HW106M J AB 10 µF,50V,Electrolytic
C73,74 VCKYTV1HB221K J AA 220 pF,50V
C75 VCKYTV1HB102K J AA 0.001 µF,50V
C76 VCKZPA1HF223Z J AA 0.022 µF,50V
C77 VCEAZA1CW107M J AC 100 µF,16V,Electrolytic
C82 VCEAZA1CW107M J AC 100 µF,16V,Electrolytic
C83 VCTYBT1EF223Z J AA 0.022 µF,25V
C302 VCCCMN1HH180J J AA 18 pF (CH),50V
C303 VCTYMN1CY103K J AA 0.01 µF,16V
C304 VCCSMN1HL4R7C J AA 4.7 pF,50V
C305 VCCCMN1HH150J J AA 15 pF (CH),50V
C306 VCCSMN1HL330J J AA 33 pF,50V
C307 VCTYMN1CX472K J AA 0.0047 µF,16V
C308 VCTYMN1CX472K J AA 0.0047 µF,16V
C309 VCCUMN1HJ6R8D J AB 6.8 pF (UJ),50V
C310 VCKYMN1HB102K J AA 0.001 µF,50V
C311 VCTYMN1EF223Z J AA 0.022 µF,25V
C312 VCKYMN1HB102K J AA 0.001 µF,50V
C313 VCTYMN1EF223Z J AA 0.022 µF,25V
C314 VCEAEA1CW106M J AB 10 µF,16V,Electrolytic
C316 VCKYMN1HB101K J AA 100 pF,50V
C317 VCCUMN1HJ3R9K J AA 3.9 pF (UJ),50V
C318 VCCCMN1HH220J J AA 22 pF (CH),50V
C319 VCTYMN1EF223Z J AA 0.022 µF,25V
C328 VCKYMN1HB102K J AA 0.001 µF,50V
C329 VCKYMN1HB102K J AA 0.001 µF,50V
C330 VCCUMN1HJ8R2D J AA 8.2 pF (UJ),50V
C331 VCKYPA1HF473Z J AB 0.047 µF,50V
C332 VCTYMN1EF223Z J AA 0.022 µF,25V
C333 VCTYMN1EF223Z J AA 0.022 µF,25V
C334 VCCUMN1HJ180J J AA 18 pF (UJ),50V
C336 VCKYMN1HB471K J AA 470 pF,50V
C337 VCEAEA1CW106M J AB 10 µF,16V,Electrolytic
C338 VCKYMN1HB101K J AA 100 pF,50V
C339,340 VCKYPA1HB102K J AA 0.001 µF,50V
C348,349 VCTYMN1EF223Z J AA 0.022 µF,25V
C350 VCEAZA1AW227M J AC 220 µF,10V,Electrolytic
C351 VCTYMN1CX222K J AA 0.0022 µF,16V
C353 VCTYMN0JY183M J AA 0.018 µF,6.3V
C354 VCKYMN1HB471K J AA 470 pF,50V
C355 VCEAEA1HW335M J AB 3.3 µF,50V,Electrolytic
C356 VCEAZA1HW335M J AB 3.3 µF,50V,Electrolytic
C357 VCEAEA1HW335M J AB 3.3 µF,50V,Electrolytic
C358 CPU100V1500PJ J AC 0.0015 µF,100V, Polypropylene
C359 VCTYMN1EF223Z J AA 0.022 µF,25V
C360 VCTYMN1EF223Z J AA 0.022 µF,25V
C361 VCEAEA1CW226M J AB 22 µF,16V,Electrolytic
C363,364 VCTYPA1CX273K J AA 0.027 µF,16V
C365~367 VCEAEA1HW105M J AB 1 µF,50V,Electrolytic
C369 VCEAZA1CW476M J AB 47 µF,16V,Electrolytic
C370 VCEAEA1HW105M J AB 1 µF,50V,Electrolytic
C381 VCCCMN1HH120J J AA 12 pF (CH),50V
C382 VCCCMN1HH150J J AA 15 pF (CH),50V
C383 VCTYMN1EF223Z J AA 0.022 µF,25V
C384 VCKYMN1HB102K J AA 0.001 µF,50V
C385 VCEAZA1CW476M J AB 47 µF,16V,Electrolytic
C386 VCEAZA1CW107M J AC 100 µF,16V,Electrolytic
C392 VCKYMN1HB102K J AA 0.001 µF,50V
C393 VCEAEA1HW105M J AB 1 µF,50V,Electrolytic
C800,801 VCQYKA1HM224K J AB 0.22 µF,50V,Mylar
C802~805 VCQYKA1HM473K J AB 0.047 µF,50V,Mylar
C806~808 VCEAZA1HW107M J AC 100 µF,50V,Electrolytic
C809 VCEAZA1JW476M J AC 47 µF,63V,Electrolytic
C810,811 VCEAZA1HW476M J AB 47 µF,50V,Electrolytic
C812 VCEAZA1VW107M J AC 100 µF,35V,Electrolytic
C813,814 VCEAZW1HW338M J AH 3300 µF,50V,Electrolytic
C815,816 VCEAZW1EW478M J AK 4700 µF,25V,Electrolytic
C817 VCKYPA1HF473Z J AB 0.047 µF,50V
C818 VCEAEA1HW474M J AB 0.47 µF,50V,Electrolytic
C819 VCFYHA1HA473J J AB 0.047 µF,50V,Thin Film
C820 VCKYPA1HF473Z J AB 0.047 µF,50V
– 2 –
