MX-C250 SIMULATION 6 – 70
9 1-4 Setting External line connection number
setting 1 <Second digit>
The numbers and codes which
can be registered are as fol-
lows.
0 - 9 / * (a) / # (b) / – (pause)
(c) / Not used for this digit and
after (d) /
Any is OK (f).
5-8 Setting External line connection number
setting 1 <Third digit>
The numbers and codes which
can be registered are as fol-
lows.
0 - 9 / * (a) / # (b) / – (pause)
(c) / Not used for this digit and
after (d) /
Any is OK (f).
10 1-4 Setting External line connection number
setting 1 <Fourth digit>
The numbers and codes which
can be registered are as fol-
lows.
0 - 9 / * (a) / # (b) / – (pause)
(c) / Not used for this digit and
after (d) /
Any is OK (f).
5-8 Setting External line connection number
setting 2 <First digit>
The numbers and codes which
can be registered are as fol-
lows.
0 - 9 / * (a) / # (b) / – (pause)
(c) / Not used for this digit and
after (d) /
Any is OK (f).
11 1-4 Setting External line connection number
setting 2 <Second digit>
The numbers and codes which
can be registered are as fol-
lows.
0 - 9 / * (a) / # (b) / – (pause)
(c) / Not used for this digit and
after (d) /
Any is OK (f).
5-8 Setting External line connection number
setting 2 <Third digit>
The numbers and codes which
can be registered are as fol-
lows.
0 - 9 / * (a) / # (b) / – (pause)
(c) / Not used for this digit and
after (d) /
Any is OK (f).
12 1-4 Setting External line connection number
setting 2 <Fourth digit>
The numbers and codes which
can be registered are as fol-
lows.
0 - 9 / * (a) / # (b) / – (pause)
(c) / Not used for this digit and
after (d) /
Any is OK (f).
5 Not used
6 -7 Adjustment value DT/BT detection level MODEM fixed (400Hz) 0 0
420Hz - 600Hz 0 1
360Hz - 440Hz 1 0
245Hz - 650Hz 1 1
8 Setting Busy tone detection 0: No 1: Yes
13 1-4 Adjustment value Lower limit of call signal ON time Not used 0 0 0 0
100ms 0 0 0 1
200ms 0 0 1 0
300ms 0 0 1 1
400ms 0 1 0 0
500ms 0 1 0 1
600ms 0 1 1 0
700ms 0 1 1 1
800ms 1 0 0 0
900ms 1 0 0 1
5-8 Adjustment value Upper limit of call signal ON time Setting range 1000ms to
4000ms
Two states input
SW
No.
Bit
No.
System set-
tings
Item SW selection and function Remarks
To Next Page
