MX-C250 SIMULATION 6 – 71
14 1, 2 FAX initial setting Flash send out waiting time 0s 0 0
0.5s 0 1
1s 1 0
2s 1 1
3, 4 FAX initial setting Flash send out time 90ms 0 0
180ms 0 1
270ms 1 0
360ms 1 1
5 Setting Dial tone detection 0 : 10s 1 : 17s
6, 7 Setting Busy tone detection 2 puls 0 0
4 puls 0 1
6 puls 1 0
10 puls 1 1
8 Not used
15-
16
Not used
17 1, 2 Adjustment value 1300Hz detection time 1.5s 0 0
2.5s 0 1
3.0s 1 0
3 FAX initial setting 150V ON control 0: No 1: Yes
4 - 7 Settings/FAX ini-
tial setting
Setting of the number of calls for
changing over from manual to
automatic reception
Setting range 1 to 9times
8 ECM 150V ON control 0: No 1: Yes
18 1 - 7 FAX initial setting CI signal off detection time Setting range 0 to 1270 ms
(10ms intervals)
Two states input
8 Not used
19 1 - 7 FAX initial setting Maximum RING disappear OFF
time
5s 0 0
10s 0 1
15s 1 0
20s 1 1
8 Not used
20 Not used
21 1-4 Adjustment value Ring back tone send out number 0 - 15 times Two states input
5-8 Adjustment value Ring back tone limit number Setting range
0 - 15 times
0 : Fixed value
Two states input
22 1-4 Adjustment value Ring back tone ON time Setting range
0.2 - 0.3 s
(200ms intervals)
0 : Fixed value
Two states input
5-8 Adjustment value Ring back tone OFF time Setting range
0.2 - 0.3 s
(200ms intervals)
0 : Fixed value
Two states input
23 1-4 Adjustment value CNG detecting time Setting range
0 - 15 times
0 : Fixed value
Two states input
5, 6 Adjustment value Telefone/FAX transmission auto-
matical voice message
Message 1 before simulated
ring
0 0
Message 2 before simulated
ring
0 1
Message after simulated ring 1 0
No message 1 1
7, 8 Not used
24 Not used
25 1-5 Adjustment value Signal sending out level 0(0dBm) - 26(-26dBm) Two states input
6-8 Not used
26 1 - 4 Timer T1 timer setting Setting range
15 - 90s
(5s intervals)
Two states input
5 - 6 Timer T2 timer setting 6s 0 0
7s 0 1
8s 1 0
9s 1 1
7 - 8 Timer T4 timer setting
Timer during automatic operation
(+1.5 seconds at times of manual
operation)
3s 0 0
4s 0 1
5s 1 0
6s 1 1
