MX-C250 SIMULATION 6 – 84
119 1, 2 Threshold of primary channel fall
back EQM when V.34 is received
Not used at this moment 0 0
Not used at this moment 0 1
Not used at this moment 1 0
Not used at this moment 1 1
3, 4 SC threshold of TCF reception
judgement
Loose(-3 dB against the Nor-
mal)
0 0
Normal (Default) 0 1
Severe (+3 dB against the
Normal)
1 0
Not used at this moment 1 1
5 - 8 Prohibit the waiting after sending
CFR for 1.6 sec.
Setting range
0 - 3000ms
Two states input
120 1 - 4 High speed CD OFF decision time Setting range
0(150ms) - 15(1650ms)
Interval 100ms
Two states input
5 - 8 Not used
121 -
122
Not used
123 1 Alternate reception 0 : OFF 1 : ON
2 Document quantity count confir-
mation when the error occurs
0 : Remove the sending error
page
1 : Include the sending error
page
3 Remaining receivable memory 0 : 128KB 1 : 64KB
4 Recover from the energy saving of
external telephone
0 : Does not recover 1 : Recover
5 Origin telephone number registra-
tion
0 : Possible 1 : Impossible
6 PC-FAX job finish waiting time 0 : 2min 1 : 10min
7, 8 Modem speaker volume OFF 0 0
Low 0 1
Medium 1 0
High 1 1
124 1 Telephone line menu 0 : Permitted 1 : Prohibited
2 Extend the time of FSS data
reception (Extend the communica-
tion time)
0 : Not used at this moment 1 : Not used at this moment
3 Answerphone connection permis-
sion
0 : OFF 1 : ON
4 - 7 TEL/LIU PWB setting Japan 0 0 0 0
Europe 0 0 1 0
North America 0 0 1 1
No 0 1 0 0
Asia 0 1 0 1
China 0 1 1 0
8 Not used
125 1 Test mode judgement flag 0 : Normal mode 1 : Test mode
2, 3 Threshold of primary channel fall
back EQM when V.34 is received
Very fine 0 0
Fine 0 1
Small 1 0
Normal 1 1
4 Debug display 0 : Does not display 1 : Display
5 Encryption 0 : Does not encrypt 1 : Encrypt
6, 7 Delayed time when releasing the
line during the dial test
2s 0 0
3s 0 1
4s 1 0
5s 1 1
8 Not used
126 -
139
Not used
140 1 F code password transmission set-
ting when the other party’s
machine has no password capac-
ity
0 : Disconnect with DCN 1 : Send with password
2 Observe the polar reverse during
communication
0 : OFF 1 : ON
3 Print the copy of the sending con-
tents when sending the F code.
0 : Print 1 : Does not print
4, 5 Speaker volume when sending
DTMF
No sound 0 0
Small 0 1
Middle 1 0
Large 1 1
6 CI detection method 0 : Ring detection circuit 1 : Silicon DAA-RGDT sig-
nal
7 AGC lock 0 : Not used at this moment 1 : Not used at this moment
8 V.17 Tap hold 0 : Not used at this moment 1 : Not used at this moment
SW
No.
Bit
No.
System set-
tings
Item SW selection and function Remarks
