MX-M182 SIMULATIONS 7-13
22 01 Counters display
Though SIM26-74 is set to "1: Scan counter is added," the count is not added to SIM22-01 total counter
display. The setting affects only the total counter display in the system settings.
03 Jam memory display
Used to check the jam kind occurred in the main unit and the SPF/RSPF.
The kinds of jams up to 30 items are displayed sequentially from the latest one. (The oldest one is deleted
sequentially.) This display is used for troubleshooting. (If there are extremely many troubles in a position, it
may be judged that a repair must be executed.)
The kinds and contents of jams to be displayed are as follows.
[CA] key: Exits the simulation mode.
[INTERRUPT] key: Shifts to the sub code input window.
key, key: Switches to another page.
04 Jam total counter display
Used to display the jam total counter.
Main
code
Sub
code
Contents Remark
Sim22-1 COUNTER 1/4
TOTAL :nnnnnnn
MAINTE :nnnnnnn
DEV :nnnnnnn(*)
DRUM :nnnnnnn
Sim22-1 COUNTER 2/4
key key
CPY JOB : nnnnnnn
PRT JOB : nnnnnnn
SCN JOB : nnnnnnn
OC SCN : nnnnnnn
Sim22-1 COUNTER 3/4
SPF : nnnnnnn
DUPLEX : nnnnnnn
OTHERS : nnnnnnn
MNTCYC : nnnnnnn
Sim22-1 COUNTER 4/4
DEV TTL : nnnnnnn
DRM TTL : nnnnnnn
Counter display
TOTAL : Total counter
MAINTE : Maintenance counter
DEV : Development counter
DRUM : Drum counter
CPY JOB : Copy job counter
PRT JOB : Print job counter
SCN JOB : Scan job counter
OC SCN : OC scan counter
SPF : SPF/RSPF counter
DUPLEX : DUPLEX counter
OTHERS : Other counter
MNTCYC : Maintenance cycle
DEV TTL : Development rotation accumulated time
DRM TTL : Drum rotation accumulated time
key key
key key
Sim22-3 JAM HIS. 1/4
XXXXXXX XXXXXXX
XXXXXXX XXXXXXX
XXXXXXX XXXXXXX
XXXXXXX XXXXXXX
Sim22-3 JAM HIS. 2/4
XXXXXXX XXXXXXX
XXXXXXX XXXXXXX
XXXXXXX XXXXXXX
XXXXXXX XXXXXXX
Kinds of jams and display contents
SPPD_ON : SPF paper entry sensor (Not reached)
SPPD_OFF : SPF paper entry sensor (Remaining)
SOUT_ON : SPF paper exit sensor (Not reached)
SOUT_OFF : SPF paper exit sensor (Remaining)
POUT_ON : Paper exit sensor (Not reached)
POUT_OFF : Paper exit sensor (Remaining)
DPX_ON : DUP sensor (Not reached)
DPX_OFF : DUP sensor (Remaining)
PIN_ON : Paper feed sensor (Not reached)
PIN_OFF : Paper feed sensor (Remaining)
PIN2_ON : Cassette 2 paper feed sensor (Not reached)
PIN3_ON : Cassette 3 paper feed sensor (Not reached)
PIN4_ON : Cassette 4 paper feed sensor (Not reached)
key key
Sim22-4 COUNTER
JAM : nnnnnn
