MX-M182 SIMULATIONS 7-15
22 15 Trouble memory display
The latest 20 troubles are displayed. (The oldest one is overwritten sequentially.)
[CA] key: Exits the simulation mode.
[INTERRUPT] key: Shifts to the sub code input window.
key, key: Switches to another page.
The display sequence is as shown below.
In this case, (1) is the latest one and (12) is the oldest.
22 SPF/RSPF jam counter display
Used to display the SPF/RSPF JAM counter.
When [INTERRUPT] key is pressed, the machine goes to the sub code input window. When [CA] key is
pressed, the machine exits the simulation mode.
(Only when the
SPF/RSPF is
installed.)
24 01 Jam total counter clear
When this simulation is executed, the clear confirmation window is displayed as shown below.
When [OK] key or [START] key is pressed, the jam total count and the jam memory are cleared and the
machine shifts to the sub code input window.
02 Trouble memory clear
Used to clear the trouble memory and the trouble history data in the EEPROM.
When [INTERRUPT] key is pressed, the machine shifts to the sub code input window. When [CA] key is
pressed, the machine exits the simulation mode.
(Only when the
SPF/RSPF is
installed.)
04 SPF/RSPF counter clear
Used to clear the SPF/RSPF paper feed counter.
[CA] key: Exits the simulation mode.
[INTERRUPT] key: Shifts to the sub code input window.
Main
code
Sub
code
Contents Remark
Sim22-15 TROUBLE 1/2 Sim22-15 TROUBLE 2/2
XX-XX XX-XX XX-XX
XX-XX XX-XX XX-XX
XX-XX XX-XX XX-XX
XX-XX XX-XX XX-XX
XX-XX XX-XX XX-XX
XX-XX XX-XX XX-XX
XX-XX XX-XX
key
key
Sim22-15 TROUBLE 1/2
1
2
3
4
5
6
7
8
9
10
11
12
Sim22-22 JAM CNT
SPF : nnnnnnn
Sim24-1 COUNTER CLR
AER YOU SURE? EXEC
JAM COUNTER CLEAR
Sim24-2 COUNTER CLR
AER YOU SURE? EXEC
TROUBLE
COUNTER
CLEAR
Sim24-4 COUNTER CLR
AER YOU SURE? EXEC
SPF
COUNTER
CLEAR
