MX-M182 SIMULATIONS 7-19
25 10 Polygon motor operation check
When [OK] key or [START] is pressed, the polygon motor is rotated for 30sec.
After completion of the process, the machine shifts to the sub code input window.
[CA] key: Exits the simulation mode.
[INTERRUPT] key: Interrupts the output operation, and shifts to the sub code input window.
26 01 Job separator setting
Used to set YES/NO of installation of the hob separator.
After installation of the job separator, setting must be manually set to YES.
[CA] key: Exits the simulation mode. (When setting is changed, the machine exits the simulation mode and
performs the hard reset.)
[INTERRUPT] key: Shifts to the sub code input window. (When setting is changed, it is invalid.)
[START] key: Setting contents are saved in the EEPROM and the machine shifts to the code input window.
(When setting is changed, the machine does not shift to the code input window.)
02 Size setting
Used to set Enable/Disable of FC (8.5" x 13") size detection and mexican legal size detection.
Detection size when FC (8.5" x 13") size and mexican legal size document is used.
* For destinations other than the above, this setting is invalid.
Main
code
Sub
code
Contents Remark
Sim25-10 LSU CHECK
PRESS OK KEY EXEC
Sim25-10 LSU CHECK
EXEC
[OK] key or [START] Key
(Execution start window) (Execution window)
Sim26-1 JBS SET
1:JOB SEPARATOR
0=NONE
1=SEPARATOR
[ 0-1]
0 : No job separator
1 : Job separator provided
0
0
Window display Code number Setting
1: B4/LG, FC 0 FC detection disable (The set values to items marked with
are ignored.)
1 (Follows the setting of items below marked with .)
2: Use Mex Legal 0 Mexican legal detection disable (FC detection enable)
1 Mexican legal detection enable (FC detection disable)
Unit to
be used
Destination Destination Detection size
1: B4/LG,
FC: 0
1: B4/LG, FC
2: Use Mex
Legal: 0
2: Use Mex
Legal: 1
Document SPF EX Japan AB
series (FC)
FC(8.5"x13") B4 FC
(8.5"x13")
Mexican legal
(8.5"x13.4")
B4
Inch series
(FC)
FC(8.5"x13") LG
(8.5"x14")
LG(8.5"x14")
Sim26-2 SIZE SET
1:B4/LG,FC
2:Use Max Legal 0
[ 0-1]
0
0
Code: Setting
0 : Detection disabled
1 : FC detection enabled
