MX-M182 SIMULATIONS 7-24
26 42 Transfer ON/OFF timing control setting
Used to set the ON/OF timing of the transfer charger (TC) individually. Select an item to be changed with the
arrow keys, and change the set value to a desired value, and press [OK] key or [START] key. The entered
value is saved to the EEPROM and the machine shifts to the sub code input window.
Variation in the adjustment value
•18cpm/20cpm machine
•23cpm machine
* Setting range is 1 - 99.
In the case of 88mm/s, when the set value is increased by 1, the timing is increased by 2ms.
[CA] key: Exits the simulation mode.
[INTERRUPT] key: Shifts to the sub code input window.
Default:
38 (TC ON)
50 (TC OFF)
43 Side void amount setting
Used to set the left and right side void amounts. The left side void amount and the right side void amount
can be set individually. Select an item to be changed with the arrow keys and change the set value to a
desired value. The setting range is 0-10. When the value is increased by 1, the void amount is increased by
0.5mm. The default is 5 (= 2.5mm).
Display: Set item
1:SIDE BOID(L) : Left side void amount setting
2:SIDE VOID(R) : Right side void amount setting
[CA] key: Exits the simulation mode.
[INTERRUPT] key: Shifts to the sub code input window.
Default:
5 (Void amount:
2.5mm)
Main
code
Sub
code
Contents Remark
(Item selection)
Sim26-42 TC TIMING Sim26-42 TC TIMING Sim26-42 TC TIMING
2
1:TC(ON)
2:TC(OFF)
[ 1- 99]
38
50
50
1:TC(ON)
2:TC(OFF)
[ 1- 99]
38
50
60
1:TC(ON)
2:TC(OFF)
[ 1- 99]
60
50
60
(Value input) (Settlement)
[OK] key or [START] Key
Numeric Key
Key, Key
1:TC(ON) 2:TC(OFF)
PS release TC ON PIN OFF TC OFF
Set value Time (ms) Difference (ms) Set value Time (ms) Difference (ms)
99 442 +122 99 402 +98
• • • • • • • • • • • • • • • • • •
50 344 +24 51 306 +2
• • • • • • • • • 50 304 0
38 320 0 49 302 -2
• • • • • • • • • • • • • • • • • •
1 246 -74 1 206 -98
1:TC(ON) 2:TC(OFF)
PS release TC ON PIN OFF TC OFF
Set value Time (ms) Difference (ms) Set value Time (ms) Difference (ms)
99 367 101 99 334 82
• • • • • • • • • • • • • • • • • •
50 286 20 51 254 2
• • • • • • • • • 50 252 0
38 266 0 49 251 -1
• • • • • • • • • • • • • • • • • •
1 204 -62 1 171 -81
(Item selection)
Sim26-43 SIDE VOID Sim26-43 SIDE VOID Sim26-43 SIDE VOID
2
1:SIDE VOID(L)
2:SIDE VOID(R)
[ 0- 10]
3
3
3
1:SIDE VOID(L)
2:SIDE VOID(R)
[ 0- 10]
3
3
4
1:SIDE VOID(L)
2:SIDE VOID(R)
[ 0- 10]
4
3
4
(Value input) (Settlement)
[OK] key or [START] Key
Numeric Key
Key, Key
