Sharp MX-M232D Service Manual

MX-M182 SPECIFICATIONS 3-2
(2) Feedable paper
*1: Switches by SIM26-2. (Operation UI supports by 8.5x13 and exclusion.)
(3)Types of feedable paper
F. Multi copy
G. Warm-up time
H. Copy magnification ratio
I. Copy density
J. Void width
K. Auto duplex
L. Paper exit / finishing
Paper size 1st tray 2nd tray
Bypass
tray
A3 297x420 Ye s Ye s Ye s
B4 257x364 Ye s Ye s Ye s
A4 297x210 Ye s Ye s Ye s
A4-R 210x297 Ye s Ye s Ye s
B5 257x182 Ye s Ye s Ye s
B5R 182x257 Ye s Ye s Ye s
A5 210x148.5 Ye s N/A Ye s
A5R 148.5x210 N/A N/A Ye s
A6R 105x148.5 N/A N/A Ye s
B6R 128.5x182 N/A N/A Ye s
Ledger 11x17 in 279.4x431.8 Ye s Ye s Ye s
Legal 8.5x14in. 215.9x355.6 Ye s Ye s Ye s
8.5x13.4 *1 216x340 *1 *1 *1 *1
Foolscap 8.5x13 in 215.9x330.2 Ye s Ye s Ye s
Letter 11x8.5in 279.4x215.9 Ye s Ye s Ye s
Letter-R 8.5x11in 215.9x279.4 Ye s Ye s Yes
Executive-R 7.25x10.5in. 184.2x266.7 N/A N/A Yes
Invoice 8.5x5.5 in. 215.9x139.7 Ye s N/A Ye s
Invoice-R 5.5x8.5 in 139.7x215.9 N/A N/A Ye s
8K 270x390 Ye s Ye s Yes
16K 270x195 Ye s Ye s Yes
16KR 195x270 Ye s Ye s Ye s
COM10 104.8x241.3 N/A N/A Ye s
Types of paper 1st tray 2nd tray Bypass tray
Thin paper 56-59g/m
2
15-15.9lbs
Ye s Ye s Ye s
Plain paper 60-90g/m
2
16-24lbs
Ye s Ye s Ye s
Heavy paper 91-105g/m
2
16-24lbs
N/A N/A Ye s
(Multi paper feed enable)
Heavy paper 106-128g/m
2
24.1-33.5lbs
N/A N/A Ye s
(A4 or less)
(Multi paper feed enable)
Heavy paper 129-200g/m
2
33.6-53.2lbs
N/A N/A Ye s
(A4 or less)
(Only single paper feed)
Heavy paper 201-256g/m
2
53.3-68lbs
N/A N/A N/A
Envelope 75-90g/m
2
20-24lbs
N/A N/A Ye s
Postcard N/A N/A Ye s
OHP film N/A N/A Ye s
Label sheet N/A N/A Ye s
Tab paper 20 N/A N/A N/A
Max. number of multi copy 999 sheets
Warm-up time 25 seconds or less
Pre-heat Available
Jam recovery Within 25 sec
Fixed magnification
ratio
AB system:
400, 200, 141, 122, 115, 100, 86, 81, 70, 50, 25%
Inch system:
400, 200, 141, 129, 121, 100, 95, 77, 64, 50, 25%
Zooming 25 ~ 400%
SPF/RSPF (50 ~ 200%)
Independent
zooming (vertical)
Available (25 ~ 400%)
SPF/RSPF (50 ~ 200%)
Independent
zooming (horizontal)
Available (25 ~ 400%)
SPF/RSPF (50 ~ 200%)
Density mode Auto / Text / Photo
No. of manual
adjustment
5 steps (Text / Photo)
Resolution Writing: 600 x 600dpi
Reading: 400 (main) x 600 (sub) (PHOTO mode)
400 (main) x 600 (sub) (AUTO exposure 
mode)
400 (main) x 600 (sub) dpi (TEXT mode)
Gradation Reading: 256 gradations
Writing: Binary
Void area Lead edge 1 ~ 4mm
Rear edge 4mm or less
Total of both sides: 6mm or less
Image loss OC Same size 3mm or less
SPF/RSPF Same size 4mm or less
Standard/
Option
Standard provision (MX-M182D/M202D/M232D only)
(D D / D  S enable only when RSPF is installed)
Not available for MX-M182
Paper exit section
capacity
Face down 250 sheets
Full detection Upper stage: Yes (Job separator is installed)
Lower stage: No (Copy/printer 250 sheets
count detection)
Finishing None
Electronic sort
capacity
A4/ 8.5" x 11" standard document 
(6% coverage) 160 sheets
Offset function Ye s
Staple function None
