MX-M182 TROUBLE CODE LIST 8-2
CE 05 Content FTP directory error
Detail The designation of the directory in the FTP
server is improper.
Check
and
remedy
Since the directory of the FTP server
registered as the destination of file server send
scan is improper, the scan data cannot be sent.
Check to confirm that the registration of the
destination is correct.
06 Content Email address error
Detail Improper email address
Check
and
remedy
Since the email address registered as the
destination of the email send scan is improper,
scan data cannot be sent. Check to confirm
that the registered destination information is
correct.
09 Content Email over size limit
Detail The size of an email to be sent exceeds the
limit.
Check
and
remedy
The size of the scan data exceeds the upper
limit of the file size set on the Web screen.
Reduce the number of sheets of documents or
change the upper limit value in "Send data
upper limit" of the Web screen.
11 Content Scanner memory shortage
Detail Memory shortage in scanner process of MX-
NB12.
Check
and
remedy
The memory becomes full during scanning
documents Reduce the number of sheets of
documents, or change the resolution and the
color mode in order to reduce the file size of
the scan data, then retry sending again.
12 Content LDAP number over
Detail The number of LDAP exceeds the
specification.
Check
and
remedy
The number of destinations which are the
targets of the global address search exceeds
the max. number. Use a longer set of
characters for search to narrow the area of
search.
18 Content RTC battery error
Detail The battery for RTC is low.
Check
and
remedy
Replace the battery for RTC.
E7 01 Content Duplex model memory error/ Image data error
Detail 1. The memory capacity for the duplex model
machine is wrong. Insufficient memory
capacity.
2. Duplex setting is set for a single surface
model.
Cause 1. The memory capacity on the MCU PWB is
wrong.
2. Setting for a single surface model is wrong.
Check
and
remedy
1. Use SIM26-39 to check to confirm that the
memory capacity is 128MB. If it is not
128MB, replace the MCU PWB.
2. If SIM26-04 is set to 1, change the setting to
0. If it is 0, replace the MCU PWB.
Main
code
Sub
code
Details of trouble
E7 02 Content LSU trouble
Detail The BD signal from the LSU cannot be
detected in a certain cycle. (Always OFF or
always ON)
Cause LSU connector or LSU harness defect or
disconnection
Polygon motor rotation abnormality
Laser beams are not generated.
MCU PWB abnormality.
Check
and
remedy
Check connection of the LSU connector.
Execute SIM 61-03 to check the LSU
operations.
Check that the polygon motor rotates normally.
Replace the LSU unit.
Replace the MCU PWB.
06 Content Image data decode error
Detail Image expansion error
Cause MCU PWB abnormality
USB cable trouble
Check
and
remedy
Replace the MCU PWB.
Replace the USB cable.
10 Content Shading trouble (Black correction)
Detail The CCD black scan level is abnormal when
the shading.
Cause Improper connection of the CCD unit flat cable
CCD unit abnormality
MCU PWB abnormality.
Check
and
remedy
Check connection of the CCD unit flat cable.
Check the CCD unit.
11 Content Shading trouble (White correction)
Detail The CCD white scan level is abnormal when
the shading.
Cause Improper connection of the CCD unit flat cable
Dirt on the mirror, the lens, and the reference
white plate
Copy lamp lighting abnormality
CCD unit abnormality
MCU PWB abnormality
(When occurred in the SPF scan position.)
Improper installation of the mirror unit
Check
and
remedy
Clean the mirror, the lens, and the reference
white plate.
Check lighting and the light quantity of the copy
lamp (SIM05-03).
Check the CCD unit.
Check the MCU PWB.
16 Content Abnormal laser output
Detail When the laser output is stopped, HSYNC is
detected.
Cause Laser abnormality
MCU PWB abnormality.
Check
and
remedy
Replace the LSU.
Replace the MCU PWB.
91 Content Decode error (FAX print)
Detail When image data sent from the FAX board to
the machine are judged as decode error:
Cause Connector connection trouble
MCU PWB abnormality
Check
and
remedy
Turn OFF/ON the power.
Connect the connector again.
Replace the MCU PWB.
Main
code
Sub
code
Details of trouble
