MX-M260/M310/M260N/M310N ELECTRICAL SECTION 10 - 12
LUM2D Lift-up motor Drives the lift plate of the
paper tray.
OFF ON CN1 1 Standard
tray I/F
LUM3D Lift-up motor Drives the lift plate of the
paper tray.
OFF ON CN1 1 Option tray
I/F
LUM4D Lift-up motor Drives the lift plate of the
paper tray.
OFF ON CN4 14 Option tray
I/F
MHP Mirror home position sensor Corrects the initial
position of the scanner.
Other
than
home
position.
Home
position
CN23 33 MCU
MIRMOD Mirror motor Controls the mirror
operation.
CN906 1,2,3,4 OP I/F PWB
MMD Main motor Controls the main motor. ON OFF IC215 3 MCU
MMRDY Main motor lock Detects lock of the main
motor.
Rotation Lock IC215 2 MCU
OCCOVER OC cover open/close
detection
Detects open/close of
the OC cover.
OPEN CLOSE CN23 29 MCU
OZNFANOUT Ozone fan Controls the ozone fan. OFF ON CN502 10 MCU
PAP1H Paper pass sensor (Tray 1) Detects paper pass. YES NO CN14 6 MCU
PAP2 Paper pass sensor (Tray 2) Detects paper pass. YES NO CN8 4 Standard
tray I/F
PAP3 Paper pass sensor (Tray 3) Detects paper pass. YES NO CN8 4 Option tray
I/F
PAP4 Paper pass sensor (Tray 4) Detects paper pass. YES NO CN4 4 Option tray
I/F
PAPER Paper entry sensor Detects paper entry. YES NO CN5 18 SPF
interface
PCL1H Paper feed clutch (Tray 1) Controls ON/OFF of the
paper feed roller.
ON OFF CN15 2 MCU
PCL2 Paper feed clutch (Tray 2) Controls ON/OFF of the
paper feed roller.
ON OFF CN3 1 Standard
tray I/F
PCL3 Paper feed clutch (Tray 3) Controls ON/OFF of the
paper feed roller.
ON OFF CN3 1 Option tray
I/F
PCL4 Paper feed clutch (Tray 4) Controls ON/OFF of the
paper feed roller.
ON OFF CN4 10 Option tray
I/F
PCS1H Paper feed solenoid (Tray 1) Controls ON/OFF of the
paper feed roller.
ON OFF CN14 2 MCU
PCS2 Paper feed solenoid (Tray 2) Controls ON/OFF of the
paper feed roller.
ON OFF CN8 7 Standard
tray I/F
PCS3 Paper feed solenoid (Tray 3) Controls ON/OFF of the
paper feed roller.
ON OFF CN8 7 Option tray
I/F
PCS4 Paper feed solenoid (Tray 4) Controls ON/OFF of the
paper feed roller.
ON OFF CN4 12 Option tray
I/F
PDPX Duplex sensor Detects paper presence
for duplex.
YES NO CN19 3 MCU
PFULL2 No. 2 paper exit full sensor Detects paper full in the
No. 2 paper exit unit.
YES NO CN21 5 MCU
PFULL2_R Right paper exit full sensor Detects paper full in the
right paper exit unit.
YES NO CN17 5 MCU
PGSOL Paper exit gate solenoid Controls the paper exit
gate.
ON OFF CN22 2,3 MCU
PIN Paper entry sensor Detects paper entry. YES NO CN14 4 MCU
POUT1 No. 1 paper exit sensor Detects paper exit of the
No. 1 paper exit unit.
NO YES CN32 6 MCU
POUT2 No. 2 paper exit sensor Detects paper exit of the
No. 2 paper exit unit.
YES NO CN21 2 MCU
POUT2_R Right paper exit sensor Detects paper exit of the
right paper exit unit.
YES NO CN17 2 MCU
POUTCOV Paper exit cover open/close
detection
Detects open/close of
the paper exit cover.
OPEN CLOSE CN21 10 MCU
POUTFANOUT Paper exit cooling fan Cools the fusing unit. OFF ON CN504 3,6 MCU
POUTFANRDY Paper exit cooling fan lock
detection
Detects lock of the paper
exit cooling fan.
Rotation Lock CN504 2,5 MCU
PPD2 Paper pass sensor (Tray 2) Detects paper pass. YES NO CN8 2 Standard
tray I/F
Signal name Name Function/Operation
Connector level
Connector
No.
Pin No. PWB name NOTE
“L “H”
