Sharp MX-M310 Service Manual

MX-M260/M310/M260N/M310N SELF DIAG AND TROUBLE CODE 7 - 1
[7] SELF DIAG AND TROUBLE CODE
1. Trouble code list
Trouble code
Trouble contents
Trouble
detection
Main
code
Sub
code
A0 01 Security incompatibility error
E1 00 IMC PWB communication trouble MCU
10 IMC PWB trouble
11 IMC PWB ASIC error
12 IMC PWB CODEC IC error
13 IMC PWB flash ROM error
14 IMC PWB expaned memory module
(DIMM) error
15 IMC PWB page memory error
/SRAM error
16 IMC PWB standard compression memory
error
17 IMC PWB smoothing IC error
80 IMC PWB communication trouble
(protocol)
81 IMC PWB communication trouble
(Parity)
82 IMC PWB communication trouble
(Overrun)
84 IMC PWB communication trouble
(Framing)
88 IMC PWB communication trouble
(Time-out)
E7 02 LSU trouble
10 CCD black level error
11 CCD white level error
12 Shading trouble
F1 00 Finisher communication trouble FIN
03 Delivery roller lift motor trouble
10 Staple motor trouble
15 Tray lift motor trouble
19 Paper alignment motor F trouble
20 Paper alignment motor R trouble
37 RAM data trouble
50 Incompatible trouble
95 Paper exit option configuration error
F2 02 Toner supply failure
04 Identification error
Model error
Type error
Destination error
Data abnormality
Misc error
05 CRUM chip communication error
58 Temperature humidity sensor abnormality
F5 02 Copy lamp (xenon lamp) error
F6 00 FAX control PWB communication trouble MCU
10 FAX control PWB trouble
80 FAX control PWB communication trouble
(Protocol)
81 FAX control PWB communication trouble
(Parity)
82 FAX control PWB communication trouble
(Overrun)
84 FAX control PWB communication trouble
(Framing)
88 FAX control PWB communication trouble
(Time-out)
96 Combination error between the MCU and
the FAX firmware.
99 FAX control PWB destination error
F9 00 Printer PWB communication trouble MCU
10 Printer PWB trouble
80 Printer PWB communication trouble
(Protocol)
81 Printer PWB communication trouble
(Parity)
82 Printer PWB communication trouble
(Overrun)
84 Printer PWB communication trouble
(Framing)
88 Printer PWB communication trouble
(Time-out)
96 MCU and PCL PWB communication
versions discrepancy error
99 Printer PWB language error
H2 00 Main heater lamp thermistor open hard
detection
01 Sub heater lamp thermistor open hard
detection
H3 00 Main heater lamp abnormally high
temperature hard detection trouble
01 Sub heater lamp abnormally high
temperature hard detection trouble
10 Main heater lamp abnormally high
temperature soft detection trouble
11 Sub heater lamp abnormally high
temperature soft detection trouble
H4 00 Main heater lamp abnormally low
temperature detection
01 Sub heater lamp abnormally low
temperature detection
20 Main heater lamp abnormally low
temperature detection
21 Sub heater lamp abnormally low
temperature detection
H5 01 10 times of continuous detection of the
lower paper exit sensor (POD1) lead edge
jam or the upper paper exit sensor
(POD2) lead edge jam or the duplex
sensor (PPD2) rear edge jam
L1 00 Scanner feed trouble
L3 00 Scanner return trouble
L4 01 Main motor trouble
11 Shifter motor trouble
31 Fusing fan lock trouble
32 Power (back up) fan lock trouble
33 Paper exit fan lock trouble
L6 10 Polygon motor trouble
L8 10 Power abnormality detection trouble
U1 01 FAX battery error
02 PANEL LOW battery error
U2 04 EEPROM communication error
20 Machine speed code data error
U7 00 RIC communication trouble
Trouble code
Trouble contents
Trouble
detection
Main
code
Sub
code
