MX-M260/M310/M260N/M310N SIMULATION 6 - 7
Operation/procedure
Used to display the operations of sensors and detectors in the finisher
section.
The active sensors and detectors are highlighted.
Note: Executable only when the finisher is installed.
Operation/procedure
Select the load to be checked with the 10-key, and press the [START] key.
The finisher main motor operates for 10sec, the staple motor 5 times,
the tray lift-up motor one reciprocating operation, other motors max. 20
reciprocating operations from the home position, the solenoid repeats
500msec ON and 500msec OFF 20 times.
The staple operation motor operates only when there is no cartridge
installed.
Operation/procedure
1. Select an item to be adjusted with 10-key, and press [START] key.
2. Enter an adjustment value with 10-key, and press [START] key.
Operation/procedure
Select item “1,” and press the [START] key.
The shifter is reciprocated continuously at the specified interval.
[Selection 2]
1. Select item “2,” and press the [START] key.
2. Move the shifter to the home position or in one way by the specified
steps with the following keys.
3
3-2
Purpose Operation test/check
Function
(Purpose)
Used to check the operation of sensor and detector in
the finisher and the related circuit.
Section Finisher
Item Operation
FDTPD Paper delivery tray paper detector
FSTPD Staple tray paper detector
FAPHPS-R Paper alignment plate HP sensor R
FAPHPS-F Paper alignment plate HP sensor F
FDRPS Delivery roller position sensor
FPPD1 Paper pass detector
FDTLLS Delivery tray lower limit sensor
FTPS Tray position sensor
FPLD Paper level detector
FSSW Safety switch
FSLD Staple lead edge detector
FSED Staple empty detector
FSHPS Staple HP sensor
FPRD Process tray paper rear edge detection
3-3
Purpose Operation test/check
Function
(Purpose)
Used to check the operation of the load in the finisher
and the control circuit.
Section Finisher
Item Operation
Item Content
1 FTLM Tray lift motor
2 FSM Staple motor
3 FPAM-R Paper alignment motor R
4 FPAM-F Paper alignment motor F
5 FPDM Paper delivery motor
6 FPS Paddle solenoid
7 FPTM Paper transport motor
8 FDRLM Delivery roller lift motor
9 FPGS Paper gate solenoid
10 FARLS Alignment roller lift solenoid
11 FSL Staple light
3-10
Purpose Adjustment
Function
(Purpose)
Used to make each adjustment of the finisher.
Item Operation
Item Content
Installation
range
Default
1 FPAM ADJUST
Paper alignment
width adjustment
40-60 50
2 FDRLM ADJUST
Paper delivery roller
descending position
adjustment
40-60 50
3-11
Purpose Operation test/check
Function
(Purpose)
Used to check the shifter operation.
Reciprocating operations are continuously performed
or the home position is checked.
(The shifter is shifted to the home position or moved in
one way by the specified steps.)
Item Operation
Item Content
1 F-R Reciprocating operation
2 HP CHECK Home position check
[*] key Shifts the position toward R side by the specified steps.
[0 key Shifts the position toward HP side by the specified steps.
[#] key Shifts to F.
SFTHP Shifter home position (At detection, highlighted)
