MX-M260/M310/M260N/M310N SIMULATION 6 - 15
NONE: When it is not installed, “- - - - - - - - - -” is displayed.
[ ]: Shows the product code in the list below.
*1: The number of installed units is displayed beside the model code.
For the tray, only the option tray is displayed.
Operation/procedure
Used to display the FAX send/receive counter.
The counter display is in 8 digits.
Note: Executable only when the FAX is installed.
Operation/procedure
Used to display the RSPF jam history data sequentially from the latest
one.
Forty RSPF jam histories are displayed sequentially from the latest.
Operation/Procedure
Used to display the CRUM type.
Operation/procedure
Used to display the scanner counter.
The counter display is in 7 digits.
Operation/procedure
Jam/trouble counter is cleared individually. (The history of each
counter is deleted when clearing)
1. Select the counter to be cleared with the 10-key.
2. Press the [START] key.
The confirmation menu is shown.
3. Select “1: YES.”
1: YES (Cleared)
2: NO (Not cleared) (Default)
ICCARDR/W NONE/MX-ECX2
No. Item Model code
1 RSPF MX-RP10
2 Finisher MX-FN13
3 Job separator MX-TR11
4 1 tray paper feed unit MX-DE10 (*1)
5 2 tray paper feed unit MX-DE11 (*1)
6 PRINTER MX-PB12
7 PS3 MX-PK10
8 NIC STANDARD (Only SoftNic)
9 SCANNER MX-NSX1
10 FAX AR-FX7
11 Handset AR-HN4
22-11
Purpose
Adjustment/setting/operation data output/check
(display/print)
Function
(Purpose)
Used to display the FAX send/receive counter
(FAX reception and print counter).
Section FAX
Item Counter
FAX SEND PAGE/TIME FAX send page and time
FAX RECEIVE PAGE/TIME FAX receive page and time
FAX OUTPUT FAX output (number of print)
22-12
Purpose
Adjustment/setting/operation data output/check
(display/print)
Function
(Purpose)
Used to check the misfeed positions and the number of
misfeed at each position.
(When the number of misfeed is considerably great, it
can be judged as necessary for repair.)
Section RSPF
Item Trouble Misfeed
Error code Name Sensor name
Paper Reached/
Not Reached to
the sensor
DFD_ND
RSPF paper in lead
edge jam
SPF P-IN
sensor
Not Reached
DFD_ST
RSPF paper in rear
edge jam
SPF P-IN
sensor
Reached
RDD_ND
RSPF paper out
lead edge jam
SPF P-IN
sensor
Reached,
P_OUT Not
Reached
RDD_ST
RSPF paper out
rear edge jam
SPF P-OUT
sensor
Reached, P_IN
passed (OFF)
JAM_REV
RSPF duplex
reverse jam
SPF P-IN
sensor
Not Reached
(Paper after
reversing)
ORG_SHORT
RSPF short size
error
SPF P-IN
sensor
Passed (OFF at
JAM)
Item Display items
ORG_LONG
RSPF long size
error
SPF P-OUT
sensor
Reached
SPF P-IN
sensor
Reached
22-13
Purpose
Adjustment/setting/operation data output/check
(display/print)
Function
(Purpose)
Used to display the CRUM type.
Item Specifications
Item Content
00 Not fixed.
01 AR-A
02 AR-B
03 AR-C
04 China
05 Japan
99 Conversion completed.
22-19
Purpose
Adjustment/setting/operation data output/check
(display/print)
Function
(Purpose)
Used to display the scanner counter in the network
scanner mode.
Section Network scanner
Item Counter
SCANMODE
Scanner mode counter
24
24-1
Purpose Data clear
Function
(Purpose)
Used to clear the misfeed counter, the misfeed history,
the trouble counter, and the trouble history. (The
counters are cleared after completion of maintenance.)
Section Memory
Item Counter
Item Content
1
JAM
JAM counter/JAM history
2
SPF JAM
RSPF JAM counter/RSPF JAM history
3
TROUBLE
Trouble counter/Trouble history
Error code Name Sensor name
Paper Reached/
Not Reached to
the sensor
To Next Page
