Sharp MX-M310 Service Manual

MX-M260/M310/M260N/M310N MAINTENANCE 8 - 2
(For 31cpm)
✕: Check (Check, clean, replace or adjust according to necessity.)
❍: Cleaning ▲ : Replace ✩: Lubricate
Unit Parts 100k 150k 200k 300k 400k 450k 500k 600k Note
Process Drum ▲✕▲▲▲✕▲▲
Cleaner blade ▲✕▲▲▲✕▲▲
Seal F/R ✕✕✕✕✕✕✕✕
Drum frame unit
(Toner reception sheet)
✕✕✕▲✕✕✕▲
Usable for three PM cycles
MC unit ▲✕▲▲▲✕▲▲
Separation pawl unit ✕▲✕▲✕▲✕▲
Star ring ▲▲▲▲▲▲▲▲
DV Developer ▲✕▲▲▲✕▲▲
Toner filter unit ▲✕▲▲▲✕▲▲
DV blade ✕▲✕▲✕▲✕▲
DV side sheet F ✕▲✕▲✕▲✕▲
DV side sheet R ✕▲✕▲✕▲✕▲
Toner sensor ✕ – ✕✕✕ – ✕✕
Fusing Upper heat roller ❍▲ ❍▲ ❍▲ ❍▲
Lower heat roller ❍❍❍▲❍❍❍▲
Upper separation pawl ❍▲ ❍▲ ❍▲ ❍▲
Upper cleaning pad ✕▲✕▲✕▲✕▲
Lower separation pawl ❍❍❍▲❍❍❍▲
Thermistor ❍❍❍❍❍❍❍❍
Fuser gear ✩▲✩▲✩▲✩▲
Upper heat roller bearing ✕▲✕▲✕▲✕▲
Lower fuser bearing ✕✕✕▲✕✕✕▲
Thermistor cleaning pad ✕▲✕▲✕▲✕▲
Paper guide ❍❍❍❍❍❍❍❍
Paper feed Pickup roller ✕✕✕✕✕✕✕✕Changing criteria for parts: 100k
Paper feeding sheet ✕✕✕✕✕✕✕✕
Pickup roller and feed roller
(RSPF)
✕✕✕✕✕✕✕✕
Transport Transport roller unit ❍▲ ❍▲ ❍▲ ❍▲
Gear ✕ – ✕ – ✕ – ✕ –
Others Paper feed rollers ❍❍❍❍❍❍❍❍
Gears ✩✩✩✩✩✩✩✩
Ozone filter ▲▲▲▲▲▲▲▲
