Sharp MX-M363F User Manual

– 4-1 –
Update : 2009/12/31
4
HL 基板ﾕﾆｯﾄ (HL PWB unit)
NO.
PARTS CODE
Inter-
change
PRICE RANK
NEW
MARK
PART
RANK
DESCRIPTION
TR No.
Effective
time
Ex. Ja.
1 RRLYD1192QCPZ AQ EQ B
Relay(G2R-1A-E-ASIDC24) [RY1] ﾘﾚｰ
2 VHD1SS133++-1T AB DJ B
Diode(1SS133T-72) [D1] ﾀﾞｲｵｰﾄﾞ
4 VCQYHA1HM104K AE DJ C
Film capacitor(AMZVA0050K104) [C1,C2,C3] ｺﾝﾃﾞﾝｻｰ
9 RC-FZ1026QCPZ AD DJ C
Capacitor(LE104-M) [C4,C5,C6] ｺﾝﾃﾞﾝｻｰ
10 VHRF11YVZBF-1 AG DX B
Photo Triac(PC3SF11YVZBF)
[SSR1,SSR2,SSR3] ﾄﾗｲｱｯｸ
11 VHSTMA164PL-F -APEQ B
Triac(TMA164P-L-LF113) [Missing parts code]
(100V series)[TD1,TD3] ﾄﾗｲｱｯｸ
1st lot
13 VHSTMA166PL-F -APEQ B
Triac(TMA166P-L-LF113) [Missing parts code]
(200V series)[TD1,TD3] ﾄﾗｲｱｯｸ
1st lot
17 PRDAR0057FCZ1 AS EZ C
Heat sink(FOR TO220)(KSP0187PE) [TD2] ﾋｰﾄｼﾝｸ
(TO220 用 )
19 XBPS730P10K00 AB DD C
Screw(SEMS-ASMP3×10 3-BC)
[TD1,TD2,TD3] ﾋﾞｽ
20 QCNCM0895FCPZ AF DS C
Connector(B03P-VL) [CN1] ｺﾈｸﾀｰ
21 QCNCM1234FCPZ AF DS C
Connector(B03P-VL-K) [CN2] ｺﾈｸﾀｰ
22 QCNCM0989FCPZ AF DS C
Connector(B03P-VL-R) [CN3] ｺﾈｸﾀｰ
23 QCNCM0170QSPZ AC DJ C
Connector(B6B-PH-K-S(LF)(SN)) [CN4] ｺﾈｸﾀｰ
24
RCILF0120FCPZ AK EB C
Normal mode coil(DR-S041320) [L2] ｺｲﾙ
RCILF0120FCPZ AK EB C
Normal mode coil(DR-S041320) (200V series)[L1] ｺｲﾙ
8
