– 6-1 –
Update : 2010/11/30
6
ﾄﾞﾗｲﾊﾞｰﾒｲﾝ基板ﾕﾆｯﾄ (Driver main PWB unit)
NO.
PARTS CODE
Inter-
change
PRICE RANK
NEW
MARK
PART
RANK
DESCRIPTION
TR No.
Effective
time
Ex. Ja.
1 VHISTA7100M-1H AN EQ B
DRIVE IC(STA7100M) [IC1,2,3,4,5] IC
2 QCNCM1404FCPZ AE DJ C
Connector(B12B-PASK-1(LF)(SN)) [CN2] ｺﾈｸﾀｰ
3 QCNCM1405FCPZ AE DS C
Connector(B13B-PASK-1(LF)(SN)) [CN3] ｺﾈｸﾀｰ
4 QCNCM1398FCPZ AD DJ C
Connector(B6B-PASK-1(LF)(SN)) [CN1] ｺﾈｸﾀｰ
5 QCNCM1507FCPZ AD DJ C
Connector(B3P-VH-R(LF)(SN)) [CN5] ｺﾈｸﾀｰ
6 QCNCM1380FCPZ AF DS C
Connector(B26B-PNDZS-B(LF)(SN)) [CN4] ｺﾈｸﾀｰ
7 VRSRRE3DA1R0J AC DD C
Resistor(2W 1.0Ω ±5%)
[R1,R2,R23,R24,R38,R39,R44,R45,R46,R47] 抵抗
8 VRNHT2EK2001F1 -ABDJ C
Resistor(2.0KΩF(1/4W)) [Missing parts code]
[R30] 抵抗
1st lot
9 VRNHT2EK2701F1 -ABDJ C
Resistor(2.7KF (1/4W)) [Missing parts code]
[R9,R17,R32,R43] 抵抗
1st lot
10 VRNHT2EK5100F1 AA DD C
Resistor(510ΩF (1/4W)) [R7,R15,R29,R34,R50] 抵抗
11 VRNHT2EK1301F1 AA DD C
Resistor(1.3kΩF (1/4W)) [R8,R16,R33,R42] 抵抗
12 VRNHT2EK1601F1 AA DD C
Resistor(1.6kΩF (1/4W)) [R28] 抵抗
13 VRDRHT2EY104JA AA DD C
Resistor(1/4W 100kΩ ±5%) [R12] 抵抗
14
VRDRHT2EY103JA AA DD C
Resistor(1/4W 10KΩ ±5%) [R3,R4,R5,R6,R10,
R13,R14,R18,R19,R20,R21,R22,R25] 抵抗
VRDRHT2EY103JA AA DD C
Resistor(1/4W 10KΩ ±5%) [R26,R27,R31,R35,
R36,R37,R40,R41,R48,R49,R51,R52] 抵抗
15 VCES4A1HN476M+ AC DD C
Capacitor(50V 47µF) [C4,C9,C10] ｺﾝﾃﾞﾝｻｰ
16 VCES4A1AN476M+ -ACDD C
Capacitor(EKMG100ETC470ME11D)
[Missing parts code]
[C3] 電解ｺﾝﾃﾞﾝｻｰ
1st lot
17 RC-KZ1054CCN28 AC DD C
Capacitor(RPEF11H104Z2M2A01A)
[C1,C5,C7,C11,C12,C13,C14,C15,C16,C17] ｺﾝﾃﾞﾝｻｰ
18 VSDTC114YS/-12 AD DJ B
Transistor(DTC114YSA) [Q1∼5] ﾄﾗﾝｼﾞｽﾀｰ
! 19 QFS-K9321QCPZ+ AE DJ A
Fuse(SRT1.6A) [ICP1∼5] ﾋｭｰｽﾞ
