– 7-1 –
Update : 2010/11/30
7
PCU 基板ﾕﾆｯﾄ (PCU PWB unit)
NO.
PARTS CODE
Inter-
change
PRICE RANK
NEW
MARK
PART
RANK
DESCRIPTION
TR No.
Effective
time
Ex. Ja.
1 QCNCW0864FCPZ AF DS C
Connector(B12P-XL(LF)(SN)) [CN4] ｺﾈｸﾀｰ
3 QCNCM0878FCPZ AE DS C
Connector(B30B-PHDSS-B(LF)(SN))
[CN1,CN5,CN15] ｺﾈｸﾀｰ
4 QCNCM0923FC248 AD DJ C
Connector(B24B-PHDSS-B(LF)(SN)) [CN9] ｺﾈｸﾀｰ
5
QCNCM0923FC228 AF DJ C
Connector(B22B-PHDSS-B(LF)(SN)) [CN7] ｺﾈｸﾀｰ
QCNCM0160QSPZ 1AEDJ C
Connector(B22B-PHDSS) [CN7] ｺﾈｸﾀｰ
10/02 R/C
6 QCNCM0877FCPZ AD DJ C
Connector(B20B-PHDSS-B(LF)(SN)) [CN14] ｺﾈｸﾀｰ
7
QCNCM0923FC108 AC DJ C
Connector(B10B-PHDSS-B(LF)(SN)) [CN8] ｺﾈｸﾀｰ
QCNCM0155QSPZ 1ACDJ C
Connector(B10B-PHDSS) [CN8] ｺﾈｸﾀｰ
10/02 R/C
8 QCNCM0923FC188 AD DJ C
Connector(B18B-PHDSS-B(LF)(SN)) [CN10,CN12] ｺﾈｸﾀｰ
9 QCNCM1236FCPZ AE DS C
Connector(B16B-PNDZS-B(LF)(SN)) [CN11] ｺﾈｸﾀｰ
10 QCNCM1231FCPZ AE DJ C
Connector(B7P-VH-B(LF)(SN)) [CN13] ｺﾈｸﾀｰ
11 QCNCM0880FCPZ AE DS C
Connector(B26B-PHDSS-B(LF)(SN))
[CN3,CN6,CN16] ｺﾈｸﾀｰ
12 QCNCM0923FC3D8 AE DS C
Connector(B34B-PHDSS-B(LF)(SN)) [CN17] ｺﾈｸﾀｰ
13 QCNCM2401SC0H8 AC DJ C
Connector(B8B-PH-K-R(LF)(SN)) [CN18] ｺﾈｸﾀｰ
15 QSOCZ0094FCPA AL EB C
Socket(DMM2-SD72AR-113-FA) [SOCKET1] ｿｹｯﾄ
16 VHIH8S2373+-1Q AW FG B
CPU(H8S/2373(HD6412373)) [IC32] CPU
17
RH-IX7001XCPZL AN EQ B
SRAM(IS63LV1024L-12JL-TR) [IC25] SRAM
RH-IX0080FCPZL 1AREQ B
SRAM(IS63LV1024L-12JL-TR) [IC25] SRAM
10/02
RH-IX0099FCPZL 1APEQ B
SRAM [IC25] SRAM
10/11
18 VHIAT24C64P-1 AK DX B
EEPROM(AT24C64C-PU) [IC31] EEPROM
19 QSOCZ0002QSPZ AC DJ C
EEPROM Socket(MY02-0830-2L) [IC31] ｿｹｯﾄ
20 VHI658920130CQ AN EQ B
I/O ASIC(uPD65892GC-013-8EU) [IC33] IC
21 VHI659461780CQ AZ FX B
PMC(UPD65946GN-178-LMU-A) [IC22] PMC
22 RH-IX0051FCPZQ BD GN B
CPLD(EPM240T100C5) (Europe)[IC34] CPLD
24 VHIM51957BP-1L AE DS B
IC(M51957BFP) [IC28] IC
26 VHILCX574FT-1L AE DS B
IC(TC74LCX574FT EL K) [IC19] IC
27 VHI74LCX32FT/4 AD DJ B
IC(TC74LCX32FT EL K) [IC18] IC
28 VHI74LCX244FT7 AE DS B
IC(TC74LCX244FT(EL,K))
[IC16,IC42,IC43,IC49,IC52] IC
29 VHI74LCX14FT17 AD DJ B
IC(TC74LCX14FT(EL,K)) [IC51,IC53] IC
30 VHI7PA17FUF-1L AD DJ B
IC(TC7PA17FU(TE85L,F)) [IC26,IC27] IC
31 VHIHC151P++-1L AE DJ B
IC(SN74HC151PWR) [IC15,IC21,IC24] IC
32 VHIVHCT244F-1L AE DJ B
IC(TC74VHCT244AFT) [IC10,IC17,IC44] IC
33 VHID62503FG-1L AF DS B
IC(TD62503FG(5,EL)) [IC8,IC9,IC12,IC14,I
C20,IC23,IC48,IC13] IC
34 VHILM339D++-17 AE DJ B
IC(LM339) [IC30,IC45,IC46] IC
35 VHID65001AF-17 AF DS B
IC(KID65001AF-EL/P) [IC1,IC2,IC3,IC7] IC
36 VHITA7291AS-18 AG DX B
IC(TA7291ASG) [IC6] IC
37 VHISTA481A+-1S AH DX B
IC(STA481A) [IC11] IC
38 VHILM324D++-17 AE DJ B
IC(LM324D) [IC36,IC40] IC
39 VHILM393D++-17 AE DJ B
IC(LM393DR) [IC41] IC
41 VHILM358DR+-17 AF DS B
IC(LM358DR) [IC39] IC
42 VHINJ7805DL-1L -AEDS B
RegIC(NJM7805DL1A) [Missing parts code]
[IC5] RegIC
1st lot
43 VHINJ7812DL-1L -AEDS B
RegIC(NJM7812DL1A) [Missing parts code]
[IC4] RegIC
1st lot
44 VSTPC8109++-17 AG DX B
FET(TPC8109) [Q14] FET
45 VS2SK3018++-17 AC DJ B
FET(2SK3018) [Q5,Q6,Q7,Q8,Q37,Q49] FET
46
VSKRC102S++-17 AB DJ B
Transistor(KRC102S) [Q9,Q21,Q22,Q23,
Q24,Q25,Q27,Q33,Q34,Q35,Q36,Q38] ﾄﾗﾝｼﾞｽﾀｰ
VSKRC102S++-17 AB DJ B
Transistor(KRC102S) [Q48,Q50] ﾄﾗﾝｼﾞｽﾀｰ
47 VS2SB1197KR-17 AC DJ B
Transistor(2SB1197KT146R) [Q17,Q18,Q19,Q20] ﾄﾗﾝｼﾞｽﾀｰ
48 VSKRC106S++-17 AB DJ B
Transistor(KRC106S) [Q40] ﾄﾗﾝｼﾞｽﾀｰ
49 VS2SB1240-/-12 AD DJ B
Transistor(2SB1240) [Q15,Q16] ﾄﾗﾝｼﾞｽﾀｰ
50 VS2SA2056++-17 AD DJ B
Transistor(2SA2056) [Q1,Q2,Q3,Q29,Q31,Q39] ﾄﾗﾝｼﾞｽﾀｰ
51 VSKTA1505S+-17 AC DJ B
Transistor(KTA1505S) [Q4,Q32] ﾄﾗﾝｼﾞｽﾀｰ
52 VS2SD1898//-14 AD DJ B
Transistor(2SD1898) [Q10,Q11,Q28,Q45] ﾄﾗﾝｼﾞｽﾀｰ
53 VS2SD1733++-17 AE DS B
Transistor(2SD1733) [Q12] ﾄﾗﾝｼﾞｽﾀｰ
54 VSKRA119S++-17 AB DJ B
Transistor(KRA119S) [Q26,Q42] ﾄﾗﾝｼﾞｽﾀｰ
55 VS2SA1576UBA1L AB DJ B
Transistor(2SA1576UBTL) [Q30] ﾄﾗﾝｼﾞｽﾀｰ
56 VSKTC3875SX-14 AB DJ B
Transistor(KTC3875S-Y-RTK/P) [Q41] ﾄﾗﾝｼﾞｽﾀｰ
58 VHPLT1F67AF-1- -ACDJN B
LED(LT1F67AF) [Missing parts code]
[LED1] LED
1st lot
59
VHD1SS355//-14 AB DJ B
Diode(1SS355) [D1,D2,D3,D4,D6,
D7,D8,D11,D12,D18,D19,D20,D21,D22] ﾀﾞｲｵｰﾄﾞ
VHD1SS355//-14 AB DJ B
Diode(1SS355)
[D27,D29,D40,D42,D48,D51,D117] ﾀﾞｲｵｰﾄﾞ
60
VHDKDS226++-17 AB DJ B
Diode(KDS226) [D5,D13,D15,D17,
D30,D37,D57,D64,D76,D83,D88,D89] ﾀﾞｲｵｰﾄﾞ
VHDKDS226++-17 AB DJ B
Diode(KDS226) [D92,D93,D96,D99,D102,D103] ﾀﾞｲｵｰﾄﾞ
61
VHDMA704A//-14 AD DJ B
Diode(MA704) [D68,D72,D85] ﾀﾞｲｵｰﾄﾞ
VHDRB420D++-1L 1ADDJN B
Diode(RB420d) [D68,D72,D85] ﾀﾞｲｵｰﾄﾞ
10/07
63 VHEHZS3C2//-11 AB DJ B
Zener diode(HZS3C2) [ZD8] ﾂｪﾅｰﾀﾞｲｵｰﾄﾞ
! 64 QFS-L0116FCPZN AD DJ A
Fuse(0603SFF100FM) [F1,F3,F4] ﾋｭｰｽﾞ
! 65 QFS-L0118FCPZN AD DJ A
Fuse(0603SFF250FM) [F5] ﾋｭｰｽﾞ
66 RMPTR4103ACPZN AA DD B
Block resistor(10KΩ×4 ±5%) [BR7,BR8,BR9,BR10,
BR11,BR12,BR13,BR14,BR16,BR17] ﾌﾞﾛｯｸ抵抗
