DSPF ﾄﾞﾗｲﾊﾞｰ基板ﾕﾆｯﾄ (DSPF Driver PWB unit)
Except MX-M282N/M362N/M452N/M502N
NO.
PARTS CODE
Inter-
change
PRICE RANK
NEW
MARK
PART
RANK
DESCRIPTION
TR No.
Effective
time
Ex. Ja.
1 VRSRCZ1JD103JN AA DD C
Resistor(1/16W 10KΩ ±5%) [R2∼5,16,22∼25,31] 抵抗
2 VRSRCZ1JD101JN AA DD C
Resistor(1/16W 100Ω ±5%) [R6∼9] 抵抗
3 VRSRCZ1JD511JN AA DD C
Resistor(1/16W 510Ω ±5%) [R17,18] 抵抗
4 VRSRCZ1JD331FN AA DD C
Resistor(1/16W 330Ω ±1%) [R11] 抵抗
5 VRSRCZ1JD681FN -AADD C
Resistor(CR1/16S681FV) [Missing parts code]
[R13,R27] 抵抗
1st lot
6 VRSRCZ1JD911FN -AADD C
Resistor(CR1/16S911FV) [Missing parts code]
[R26] 抵抗
1st lot
7 VRSRCZ1JD472FN AA DD C
Resistor(1/16W 4.7KΩ ±1%) [R12,28] 抵抗
8 VCKYRZ1CF104ZN AA DD C
Capacitor(16V 0.1µF) [C1,17] ｺﾝﾃﾞﾝｻｰ
9 VCKYCZ1CF473Z- AA DD C
Capacitor(16V 0.047µF) [C11,16] ｺﾝﾃﾞﾝｻｰ
10 VCKYRY1HB223KN AA DD C
Capacitor(50V 22000pF) [C6,12,14] ｺﾝﾃﾞﾝｻｰ
11 VSRT1N141C+-1L -ACDD B
Transistor(RT1N141C-T12-C) [Missing parts code]
[Q1,3,4,5,6] ﾄﾗﾝｼﾞｽﾀｰ
1st lot
12 VS2SK3065++-17 AE DJ B
FET(2SK3065) [Q2] FET
13 VCERSM1VM476ML AC DD C
Capacitor(35V 47µF) [C15] ｺﾝﾃﾞﾝｻｰ
14 VHDDSS133//-11 AA DJ B
Diode(1SS133T-77) [D1,2] ﾀﾞｲｵｰﾄﾞ
15 VHEMTZJ20B/-11 AB DJ B
Zener diode(MTZJ20BT) [ZD1] ﾂｪﾅｰﾀﾞｲｵｰﾄﾞ
16 VHERD16FMAY-1L -AFDS B
Zener diode(RD16FM-T1-AY) [Missing parts code]
[ZD2] ﾂｪﾅｰﾀﾞｲｵｰﾄﾞ
1st lot
17 VRD-HT2EY242JA AA DD C
Resistor(RD16ST262.4KΩJ) [R30] 抵抗
18 VRDRHT2EY104JA AA DD C
Resistor(1/4W 100kΩ ±5%) [R1] 抵抗
19 VRDRHT2HY242JA AA DD C
Resistor(CFS1/2CT26A242J) [R20] 抵抗
20 VCESGA1VW476M+ AB DD C
Capacitor(35V 47µF) [C5,13] ｺﾝﾃﾞﾝｻｰ
22 VHVICPN15//-1T AD DJ B
IC protector(ICP-N15) [ICP2,6] IC ﾌﾟﾛﾃｸﾀｰ
23 VHVICPN20//-1T AE DJ B
IC protector(ICP-N20) [ICP3,4] IC ﾌﾟﾛﾃｸﾀｰ
24 VHVICPN38//-12 AD DJ B
IC protector(ICP-N38) [ICP1,5] IC ﾌﾟﾛﾃｸﾀｰ
25 VS2SB1240-/-12 AD DJ B
Transistor(2SB1240 T146 PQR) [Q7] ﾄﾗﾝｼﾞｽﾀｰ
26 VRSRRE3DAR47J AC DD C
Resistor(2W 0.47Ω ±5%) [R10,15,32,33] 抵抗
27 VHISLA7066M-1S AT EZ B
IC(SLA7066M) [IC3] IC
28 VHISTA7100M-1H AN EQ B
IC(STA7100M) [IC1] IC
29 VHITD62003AP18 AE DS B
IC(TD62003AP) [IC2] IC
30 QCNCM0880FCPZ AE DS C
Connector(B26B-PHDSS-B) [CNA] ｺﾈｸﾀｰ
31 QCNCM2401SC0F8 AC DJ C
Connector(B6B-PH-K-R) [CNB] ｺﾈｸﾀｰ
32 QCNCM7014SC0G8 AC DJ C
Connector(B7B-PH-K-S) [CNC] ｺﾈｸﾀｰ
33
QCNCM7014SC0C8 AB DJ C
Connector(B3B-PH-K-S) [CND] ｺﾈｸﾀｰ
QCNCM0042ESPZ 1ABDJ C
Connector(B3B-PH-K-S) [CND] ｺﾈｸﾀｰ
10/02 R/C
34 QCNCM7014SC0E8 AC DJ C
Connector(B5B-PH-K-S) [CNE] ｺﾈｸﾀｰ
35 QCNCM7014SC0F8 AC DJ C
Connector(B6B-PH-K-S) [CNF] ｺﾈｸﾀｰ
