– 2-9 –
Update : 2010/11/30
2
MFP 基板ﾕﾆｯﾄ (MFP PWB unit)
NO.
PARTS CODE
Inter-
change
PRICE RANK
NEW
MARK
PART
RANK
DESCRIPTION
TR No.
Effective
time
Ex. Ja.
154 QSOCZ0079FCPZ AP EQ C
Socket(FLASH100)(DMM-100G-133FNK31-FA)
(Japan)
[CN8] ｿｹｯﾄ
155 QSW-S0551FCPZS AM DX B
Switch(KSP22) [SW1] ｽｲｯﾁ
! 181 UBATL0021FCPZ AF DS B
Battery(CR2032L/BE) [AS12] ﾊﾞｯﾃﾘ
182 PRDAF0104FCPZ -AXFG C
Heat sink(Heat sink_SOC) [Missing parts code]
[AS5] ﾋｰﾄｼﾝｸ
1st lot
183 VHIAT24256P-1 AN EG B
IC(EEPROM)(AT24C256B-PU) [AS2] IC(EEPROM)
184 TLABN1235CCZZ AA DD D
Label(LABEL(MAC/LOT/LOT-Mng))
[AS14,AS15,AS16] ﾗﾍﾞﾙ
185 PCOVP1945FCZZ AC DJ C
Sheet(BAT_HOGO_SHEET) [AS13] ｼｰﾄ
186
QSOCN0108FCPZ AD DJ C
Short jumper(JM-2R-64) [AS10] ｼｮｰﾄｼﾞｬﾝﾊﾟｰ
PCAPH0010GCPZ 1ACDJ C
Short jumper(JM-2W-96) [AS10] ｼｮｰﾄｼﾞｬﾝﾊﾟｰ
11/02 R/C
187
VCKYRZ1EB223KN -AADD C
Capacitor(25WV 22000pF) (South Africa,Brazil)
[R11] ｺﾝﾃﾞﾝｻｰ
09/12
VCKYRZ1EB223KN -AADD C
Capacitor(25WV 22000pF)
(Except South Africa,Brazil,Taiwan,Japan)
[R11] ｺﾝﾃﾞﾝｻｰ
10/03
188
RFILN1063ACZZN -AADJNC
Filter(BLM18PG330SN1) (South Africa,Brazil)
[L4] ﾌｨﾙﾀｰ
09/12
RFILN1063ACZZN -AADJ C
Filter(BLM18PG330SN1(1608))
(Except South Africa,Brazil,Taiwan,Japan)
[L4] ﾌｨﾙﾀｰ
10/03
189 VHIBD3533F+-1L AH DX B
IC(REGULATOR)(BD3533F-E2) [IC14] IC
190 VHILHF00L28-1Q AN EQ B
IC(FLASH(LHF00L28)
(MX-M363F/M423F/M503F/M363U/M453U/M503U)
[IC30] IC(FLASH)
