MFP 基板ﾕﾆｯﾄ (MFP PWB unit)
NO.
PARTS CODE
Inter-
change
PRICE RANK
NEW
MARK
PART
RANK
DESCRIPTION
TR No.
Effective
time
Ex. Ja.
111 VHIBD9111NV-1L AK EB B
IC(DCDC)(BD9111NV-E2) [IC38] IC(DCDC)
112 VHILT3850GN-1L AR EQ B
IC(DCDC)(LTC3850EGN#TRPBF) [IC8] IC(DCDC)
113 VHISRV054TC-1L AH DX B
IC(Di-ARRAY)(SRV05-4.TCT) [IC2,IC3] IC(Di-ARRAY)
114 VHIVSC8641X-1Q AX FG B
IC(Ether-PHY)(VSC8641XKO) [IC9] IC(Ether-PHY)
116
VHIICSV385A-1L AL EB B
IC(FPDLINK)(ICSV385AGLFT) [IC52,IC58] IC(FPDLINK)
VHIICSV385A-1L AL EB B
IC(FPDLINK)(ICSV385AGLFT) (MX-M283N/M363N/
M453N/M503N/M282N/M362N/M452N/M502N)
[IC48] IC(FPDLINK)
117
VHIICSV386+-1L AL EB B
IC(FPDLINK)(ICSV386GLFT) [IC51] IC(FPDLINK)
VHIVP386PAG-1L 1ALEBN B
IC(FPDLINK)(IDTVP386PAG8) [IC51] IC(FPDLINK)
09/04 mid
118 VHI74LCX14FT17 AD DJ B
IC(LOGIC)(TC74LCX14FT(EL,K)) [IC24,IC44] IC
119
VHI74LCX244FT- -AEDSN B
IC(LOGIC)(TC74LCX244FT(EL,K))
[Missing parts code][IC7,IC25,IC31,IC32,IC47] IC(LOGIC)
1st lot
VHI74LCX244FT- -AEDSN B
IC(LOGIC)(TC74LCX244FT(EL,K))
[Missing parts code][IC505] IC(LOGIC)
1st lot
120
VHIT7SZ04FU-1L AC DJ B
IC(LOGIC)(TC7SZ04FU(TE85L,F)) [IC39,IC46] IC
VHIT7SZ04FU-1L AC DJ B
IC(LOGIC)(TC7SZ04FU(TE85L,F))
(Except South Africa)[IC17] IC
VHIT7SZ04FU-1L -ACDJ B
IC(LOGIC)(TC7SZ04FU(TE85L,F))
(Except South Africa,Brazil,Taiwan,Japan)[IC17] IC
10/03
121
VHI7SZ07FUF-1L AC DJ B
IC(LOGIC)(TC7SZ07FU(TE85L,F)) [IC19,IC20,IC21] IC
VHI7SZ07FUF-1L -ACDJ B
IC(LOGIC)(TC7SZ07FU(TE85L,F)) [IC19,IC20,IC21] IC
10/12 R/C
122
VHI7SZ08FUF-1L AD DJ B
IC(LOGIC)(TC7SZ08FU(TE85L,F)) [IC26,IC40] IC
VHI7SZ08FUF-1L AD DJ B
IC(LOGIC)(TC7SZ08FU(TE85L,F))
(Except South Africa)[IC18] IC
VHI7SZ08FUF-1L -ADDJ B
IC(LOGIC)(TC7SZ08FU(TE85L,F))
(Except South Africa,Brazil,Taiwan,Japan)[IC18] IC(LOGIC)
10/03
VHIV1G09DFT-1L AE DS B
IC(LOGIC)(MC74VHC1G09DFT2G) [IC40] IC
123
VHI7WB66FKF-1R AE DS B
IC(LOGIC)(TC7WB66FK(TE85L,F))
(Except South Africa)[IC53,IC59] IC
VHI7WB66FKF-1R -AEDS B
IC(LOGIC)(TC7WB66FK(TE85L,F))
(Except South Africa,Brazil,Taiwan,Japan)[IC53,IC59] IC(LOGIC)
10/03
124 VHIU90LV048-1L AL EB B
IC(LVDS)(BU90LV048-E2) [IC57] IC(LVDS)
125 VHIBU90LV49-1L -ALEB B
IC(LVDS)(BU90LV049) [Missing parts code][IC5] IC(LVDS)
1st lot
126 VHILM393D++-17 AE DJ B
IC(OPAMP)(LM393DR) [IC6] IC(OPAMP)
127 VHIBH25FB1W-1R -AEDS B
IC(REGULATOR)(BH25FB1WG-TR)
[Missing parts code][IC12] IC
1st lot
128 VHI2596SETR-1L AG DS B
IC(REGULATOR)(SC2596SETRT) [IC54] IC
129 VHIBU4238F+-1R AD DJ B
IC(RESETIC)(BU4238F-TR) [IC49] IC
130 VHIBU4240F+-1R AD DJ B
IC(RESETIC)(BU4240F-TR) [IC55] IC
131 VHIBU4242F+-19 AD DJ B
IC(RESETIC)(BU4242F-TR) [IC27] IC
132 VHI3243ECPW-1L AL EB B
IC(RS232CDRIVER)(MAX3243ECPWR) [IC1] IC
133 VHIM8578BVG-1L -AGDX B
IC(RTC)(SM8578BV-G-E2) [Missing parts code]
[IC15] IC(RTC)
1st lot
134
RH-IX0074FCPZQ -AREQ B
IC(SDRAM)(K4S561632J-UC75/HY57V561620FTP-H)
[Missing parts code][IC35,IC36] IC(SDRAM)
1st lot
RH-IX0074FCPZQ -AREQ B
IC(SDRAM)(K4S561632J-UC75/HY57V561620FTP-H)
[Missing parts code][IC507,IC508] IC(SDRAM)
1st lot
135 VHI8377EALG-1Q -CATX B
IC(SoC)(MPC8377EVRALG) [Missing parts code]
(MX-M453N/M503N)[IC22] IC(SoC)
1st lot
136 VHI16LV1024-1Q -AREQ B
IC(SRAM)(CS16LV10243GIR70) [Missing parts code]
[IC504] IC(SRAM)
1st lot
137 VHI1647GIR7-1Q BA FX B
IC(SRAM)(CS16LV40973GIR70) [IC11] IC(SRAM)
138 RH-IX0075FCPZL -ALEB B
IC(SSCG)(CY25100SXC-049T) [Missing parts code]
[IC23] IC(SSCG)
1st lot
139 VHID62503FG-1L AF DS B
IC(TR-ARRAY)(TD62503FG) [IC42,IC56] IC(TR-ARRAY)
140 VHIUSB3300E-1L -ASEQ B
IC(USB-PHY)(USB3300-EZK) [Missing parts code]
[IC10] IC(USB-PHY)
1st lot
141 VHIBD6512LF-1L AH DX B
IC(USBPOWERSW)(BD6512F-E2) [IC4] IC
142
RCRSC0102FCPZL AF DS B
Crystal(DMX-26S(32.768KHz/SERIES8PF))
(Except MX-M282N/M362N/M452N/M502N)
[X3] ｸﾘｽﾀﾙ
RCRSC0115FCPZL AG DX B
Crystal(32.768KHz)
(MX-M282N/M362N/M452N/M502N)[X3] ｸﾘｽﾀﾙ
143 RCRSC0113FCPZN -AHDX B
Crystal(FA-238(24.0000MHZ)) [Missing parts code]
[X2] ｸﾘｽﾀﾙ
1st lot
145 RCRUA0065FCPZL -AHDX B
Crystal(SG-310SCF(25.0000MHZ)(B))
[Missing parts code][X1,X6] ｸﾘｽﾀﾙ
1st lot
146 RCRUA0054QSPZL -AHDX B
Crystal(SG-310SCF(48.0000MHZ)(C))
[Missing parts code][X8] ｸﾘｽﾀﾙ
1st lot
148 QPIN-0003GCPZ AC DJ C
Pin header(3pin)(T3B-SQ(LF)(SN)) [CN7] ﾋﾟﾝ
149
VHQNSMDC110-1N AE DS B
Poly switch(NANOSMDC110F-2)
(except MX-M282N/M362N/M452N/M502N)[R13] ﾎﾟﾘｽｲｯﾁ
VHQFSMD110R-1N AD DJ B
Poly switch(FSMD110-1206R)
(MX-M282N/M362N/M452N/M502N)[R13] ﾎﾟﾘｽｲｯﾁ
150 QSOCZ0002QSPZ AC DJ C
Socket(8pin)(MY02-0830-2L) [IC29] ｿｹｯﾄ
151 VKBCF20006001 AQ EQ C
Socket(DDR2)(CA0410-200N32(DDR2_SODIMM_TypeA))
[CN13,CN14] ｿｹｯﾄ
153 QSOCZ0094FCPA AL EB C
Socket(FLASH)(DMM2-SD72AR-113-FA)
[CN9,CN10,CN11,CN12] ｿｹｯﾄ
