– 2-7 –
Update : 2010/11/30
2
MFP 基板ﾕﾆｯﾄ (MFP PWB unit)
NO.
PARTS CODE
Inter-
change
PRICE RANK
NEW
MARK
PART
RANK
DESCRIPTION
TR No.
Effective
time
Ex. Ja.
75
VRSRCZ1JD473JN AA DD C
Resistor(1/16W 47KΩ ±5%)
[R12,R16,R27,R30,R57,R72,R95,R115,R155,R173] 抵抗
VRSRCZ1JD473JN AA DD C
Resistor(1/16W 47KΩ ±5%) [R511,R512,R530,R539,
R540,R596,R682,R703,R780,R781] 抵抗
76 RR-SZ0410FCPZN AA DD C
Resistor(49.9F(1005))
[R182,R184,R186,R188] 抵抗
77 VRSRCZ1JD562FN AA DD C
Resistor(1/16W 5.6KΩ ±1%) [R758] 抵抗
78 VRSRCZ1JD562JN AA DD C
Resistor(1/16W 5.6KΩ ±5%)
[R579,R590,R591,R592,R647,R648,R658,R659] 抵抗
79 VRSRCZ1JD592FN AA DD C
Resistor(1/16W 5.9KFΩ ±1%) [R69] 抵抗
80
VRSRCZ1JD510JN AA DD C
Resistor(1/16W 51Ω ±5%) [R600,R601,R602,R603,
R604,R605,R606,R609,R610,R611] 抵抗
VRSRCZ1JD510JN AA DD C
Resistor(1/16W 51Ω ±5%) [R612,R613,R614,R615,
R616,R617,R618,R621,R622,R623] 抵抗
VRSRCZ1JD510JN AA DD C
Resistor(1/16W 51Ω ±5%) [R624,R625,R626,R632,
R633,R634,R636,R637,R638,R642] 抵抗
VRSRCZ1JD510JN AA DD C
Resistor(1/16W 51Ω ±5%) [R712,R713,R727,R728,
R729,R730,R739,R740,R749,R750] 抵抗
VRSRCZ1JD510JN AA DD C
Resistor(1/16W 51Ω ±5%) [R751,R752,R755,R756,
R757,R762,R763,R764,R770,R771] 抵抗
VRSRCZ1JD510JN AA DD C
Resistor(1/16W 51Ω ±5%)
[R785,R797,R798,R799,R800,R819] 抵抗
81
VRSRCZ1JD560JN AA DD C
Resistor(1/16W 56Ω ±5%) [R79,R84,R86,R87,R88,
R89,R91,R107,R175,R199,R201] 抵抗
VRSRCZ1JD560JN AA DD C
Resistor(1/16W 56Ω ±5%) [R202,R203] 抵抗
VRSRCZ1JD560JN AA DD C
Resistor(1/16W 56Ω ±5%) [R555,R620] 抵抗
82 VRSRCZ1JD821JN AA DD C
Resistor(1/16W 820Ω ±5%) [R50] 抵抗
83 RR-FZ0002FCPZN -AFDS C
Resistor(PMR50HZPFU10L0) [Missing parts code]
[R513] 抵抗
1st lot
84 RR-FZ0003FCPZN -AFDS C
Resistor(PMR50HZPFU6L00) [Missing parts code]
[R524] 抵抗
1st lot
85 VS2SB1198K/-14 AC DJ B
Transistor(2SB1198KT146) [Q7] ﾄﾗﾝｼﾞｽﾀｰ
86 VS2SC2412K/-14 AB DJ B
Transistor(2SC2412KT146) [Q5] ﾄﾗﾝｼﾞｽﾀｰ
87 VSDTA114EUB-1L AB ZZ B
Transistor(DTA114EUBTL) [Q28] ﾄﾗﾝｼﾞｽﾀｰ
88
VSDTC114YUB-1L AB DJ B
Transistor(DTC114YUBTL) [Q1,Q2,Q3,Q4,Q6,Q8,Q9,
Q10,Q11,Q13,Q14,Q15,Q17,Q18] ﾄﾗﾝｼﾞｽﾀｰ
VSDTC114YUB-1L AB DJ B
Transistor(DTC114YUBTL) [Q19,Q23,Q24,Q25,Q26,
Q27,Q29,Q30,Q31,Q32,Q33] ﾄﾗﾝｼﾞｽﾀｰ
VSDTC114YUB-1L AB DJ B
Transistor(DTC114YUBTL) [Q35,Q20,Q21,Q22] ﾄﾗﾝｼﾞｽﾀｰ
VSDTC114YUB-1L AB DJ B
Transistor(DTC114YUBTL) [Q500,Q501,Q502] ﾄﾗﾝｼﾞｽﾀｰ
VSDTC114YUB-1L AB DJ B
Transistor(DTC114YUBTL) (Except South Africa)
[Q34] ﾄﾗﾝｼﾞｽﾀｰ
VSDTC114YUB-1L -ABDJ B
Transistor(DTC114YUBTL)
(Except South Africa,Brazil,Taiwan,Japan)[Q34] ﾄﾗﾝｼﾞｽﾀｰ
10/03
89 VHEHZM6R2Z4-1L AC DJ B
Diode(HZM6.2Z4MWATL-E) [D5,D6] ﾀﾞｲｵｰﾄﾞ
90 RCILC0145FCPZN -ACDJ C
Coil(LQH32PN4R7NN0_4.7uH) [Missing parts code]
[L11,L23] ｺｲﾙ
1st lot
91 RCILZ0155FCPZN -AEDJ C
Coil(NR6020T2R2N) [Missing parts code]
[L24] ｺｲﾙ
1st lot
92 RCILZ0149FCPZN -ADDJ C
Coil(NR6045T2R3N) [Missing parts code]
[L6] ｺｲﾙ
1st lot
94
QCNCM1367FCPZL AE DJ C
Connector(BM08B-SRSS-TB(LF)(SN)) [CN5] ｺﾈｸﾀｰ
QCNCM1367FCPZL -AEDJ C
Connector(BM08B-SRSS-TB(LF)(SN)) [CN5] ｺﾈｸﾀｰ
10/10 R/C
95 VKB-F08008001R -APEQ C
Connector(ACRE)(240414380W*)
[Missing parts code][CN17] ｺﾈｸﾀｰ
1st lot
96 QCNCW1388FCPZ AQ EQ C
Connector(BtoB)(TX24-120R-LT-H1E) [CN18] ｺﾈｸﾀｰ
97 QSOCN0111FCPZ AF DJ C
Connector(DSUSB9)(DBR30-091F100) [CN1] ｿｹｯﾄ
98 QJAKT0005FCPZ AU EZ C
Connector(SI-51005-F) [CN4] ｺﾈｸﾀｰ
99 VKWTM03110001 AH DX C
Connector(FAX)(B31B-CSRK(LF)(SN)) [CN6] ｺﾈｸﾀｰ
100 VKWTM0071D001 -AKEB C
Connector(SATA)(6SAT07P-328B-B5(15um))
[Missing parts code][CN15] ｺﾈｸﾀｰ
1st lot
101 QSOCN0012QSPZ AE DS C
Connector(USBA)(UAR27-4K5J00) [CN3] ｿｹｯﾄ
102 QSOCN0005ESPZ AE DJ C
Connector(USBB)(UBR23-4K2200) [CN2] ｿｹｯﾄ
103 RCNVD0015FCPZL AU EZ B
DC_DC converter(MPD5M006S) [MOD1,MOD2] DC_DC ｺﾝﾊﾞｰﾀ
105 VHIM8AA17520CQ -BLHL B
IC(ASIC)(MB8AA1752PBH(Uranos-ASIC))
[Missing parts code][IC45] IC(ASIC)
1st lot
106
VHICY23EP05-1L -APEQ B
IC(CLOCK-BUFFER)(CY23EP05SXC-1T)
[Missing parts code][IC16] IC
1st lot
VHI6T60009D-1L -AMEG B
IC(CLOCK-BUFFER)(IDT6T60009DCGI8)
(Except South Africa,Brazil,Taiwan,Japan)[IC16] IC
10/03
107
VHI9FG108CG-1L AP EQ B
IC(CLOCK-BUFFER)(ICS9FG108CGLFT)
(MX-M283N/M363N/M453N/M503N/
M282N/M362N/M452N/M502N)
[IC33] IC
VHI9FG108DG-1L 1ANEQ B
IC(ICS9FG108DGLFT) (MX-M283N/M363N/
M453N/M503N/M282N/M362N/M452N/M502N)[IC33] IC
11/03 R/C
108 RH-IX0072FCPZL -AQEQ B
IC(CLOCK-GENERATOR)(CY25404ZXI009T)
[Missing parts code][IC28] IC
1st lot
109 RH-IX0081FCPZQ -BTNE B
IC(CPLD)(EPM570F256C5-2) [Missing parts code]
(MXM453N/M503N)[IC34] IC(CPLD)
1st lot
110 VHIBD9104FV-1L AH DX B
IC(DCDC)(BD9104FVM-TR) [IC37] IC(DCDC)
To Next Page
