Sharp MX-M363F User Manual

– 2-1 –
Update : 2010/11/30
2
MFP 基板ﾕﾆｯﾄ (MFP PWB unit)
NO.
PARTS CODE
Inter-
change
PRICE RANK
NEW
MARK
PART
RANK
DESCRIPTION
TR No.
Effective
time
Ex. Ja.
1 VCARPF0JJ127ML AF DS C
Capacitor(6.3V 120µF) [C116,C210] ｺﾝﾃﾞﾝｻｰ
2 VCARPF0GJ157ML AF DS C
Capacitor(4V 150µF) [C234] ｺﾝﾃﾞﾝｻｰ
3 VCARPF0EJ227ML -AFDS C
Capacitor(APXA2R5ARA221MF60G)
[Missing parts code]
[C13,C68,C123,C208] ｺﾝﾃﾞﾝｻｰ
1st lot
4 VCARPF0JJ227ML AG DX C
Capacitor(APXA6R3ARA221MH70G) [C12] ｺﾝﾃﾞﾝｻｰ
5 VCERSX1VN226ML AC DD C
Capacitor(35V 22µF) [C1] ｺﾝﾃﾞﾝｻｰ
6 VCERSX1CN476ML AC DD C
Capacitor(16V 47µF) [C2,C7,C25] ｺﾝﾃﾞﾝｻｰ
8 QSOCB0127FCPZ AH DX C
Battery holder(BCR20V4E) [BT1] ﾊﾞｯﾃﾘｰﾎﾙﾀﾞｰ
9
RMPTR4102ACPZN AA DD B
Block resistor(1KΩ×4 ±5%)
[BR515,BR518,,BR544,BR548] ﾌﾞﾛｯｸ抵抗
RMPTR4102ACPZN AA DD B
Block resistor(1KΩ×4 ±5%) (MX-M283N/M363N/
M453N/M503N/M282N/M362N/M452N/M502N)
[BR541] ﾌﾞﾛｯｸ抵抗
10
RMPTR4220ACPZN AA DD B
Block resistor(22Ω×4 1/16W ±5%) [BR503,BR504,
BR507,BR509,BR510,BR513,BR514,BR517] ﾌﾞﾛｯｸ抵抗
RMPTR4220ACPZN AA DD B
Block resistor(22Ω×4 1/16W ±5%)
[BR520,BR543,BR546,BR562] ﾌﾞﾛｯｸ抵抗
11
RMPTR4330ACPZN AA DD B
Block resistor(33Ω×4 ±5%) [BR500,BR521,
BR522,BR531,BR532,BR533,BR534,BR535] ﾌﾞﾛｯｸ抵抗
RMPTR4330ACPZN AA DD B
Block resistor(33Ω×4 ±5%)
[BR536,BR537,BR538,BR539,BR540,BR563,BR564] ﾌﾞﾛｯｸ抵抗
12 RMPTR4470ACPZN AA DD B
Block resistor(47Ω×4 1/16W ±5%)
[BR547,BR549,BR552,BR553,BR554,BR559] ﾌﾞﾛｯｸ抵抗
13
RMPTR4473ACPZN AA DD B
Block resistor(47KΩ×4 ±5%) [BR542,BR545,
BR550,BR551,BR555,BR556,BR557,BR558] ﾌﾞﾛｯｸ抵抗
RMPTR4473ACPZN AA DD B
Block resistor(47KΩ×4 ±5%) [BR560,BR561] ﾌﾞﾛｯｸ抵抗
15 RMPTR4680ACPZN AA DD B
Block resistor(68Ω×4 ±5%) [BR523,BR524,
BR525,BR526,BR527,BR528,BR529,BR530] ﾌﾞﾛｯｸ抵抗
16
VCKYRZ1EB103KN AA DD C
Capacitor(25V 0.01µF) [C6,C26,C141,
C158,C159,C160,C161,C199,C226,C235] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1EB103KN AA DD C
Capacitor(25V 0.01µF) [C241] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1EB103KN AA DD C
Capacitor(25V 0.01µF) [C504,C515,C529,
C578,C579,C580,C617,C698,C699,C714] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1EB103KN AA DD C
Capacitor(25V 0.01µF) [C715,C716,C717,
C767,C969,C979,C1012,C1059,C1063] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1EB103KN AA DD C
Capacitor(25V 0.01µF) [C1079,C1102,
C1104,C1107,C1108,C1112,C1120,C1121] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1EB103KN AA DD C
Capacitor(25V 0.01µF) [C1122] ｺﾝﾃﾞﾝｻｰ
17
VCKYRY1HB104KN AA DD C
Capacitor(50V 0.1µF) [C3,C4,C5,C9,C15] ｺﾝﾃﾞﾝｻｰ
VCKYRY1HB104KN AA DD C
Capacitor(50V 0.1µF) [C742] ｺﾝﾃﾞﾝｻｰ
18
VCKYRZ1AB104KN AA DD C
Capacitor(10V 0.1µF) [C8,C10,C17,C18,
C20,C24,C27,C29,C31,C42,C43,C59] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1AB104KN -AADD C
Capacitor(10V 0.1µF) (South Africa,Brazil)[C17] ｺﾝﾃﾞﾝｻｰ
09/12
VCKYRZ1AB104KN -AADD C
Capacitor(10V 0.1µF)
(Except South Africa,Brazil,Taiwan,Japan)[C17] ｺﾝﾃﾞﾝｻｰ
10/03
VCKYRZ1AB104KN AA DD C
Capacitor(10V 0.1µF) [C60,C64,C65,C69,
C70,C71,C72,C81,C82,C87,C88,C93] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1AB104KN AA DD C
Capacitor(10V 0.1µF) [C94,C97,C103,
C104,C107,C108,C111,C112,C124,C128] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1AB104KN AA DD C
Capacitor(10V 0.1µF) [C130,C131,C132,
C133,C134,C135,C136,C138,C139] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1AB104KN AA DD C
Capacitor(10V 0.1µF) [C142,C143,C147,
C149,C150,C151,C153,C162,C163,C165] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1AB104KN AA DD C
Capacitor(10V 0.1µF)
[C169,C177,C178,C186,C187,C191,C192,C194] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1AB104KN AA DD C
Capacitor(10V 0.1µF) [C202,C203,C216,
C217,C218,C219,C220,C221,C222,C223] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1AB104KN AA DD C
Capacitor(10V 0.1µF) [C230,C233,C240,C242] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1AB104KN AA DD C
Capacitor(10V 0.1µF) [C510,C514,C516,
C520,C521,C522,C523,C524,C525,C526] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1AB104KN AA DD C
Capacitor(10V 0.1µF)
[C528,C533,C534,C535,C536,C537,C538,C541] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1AB104KN AA DD C
Capacitor(10V 0.1µF) [C542,C555,C557,
C559,C569,C570,C574,C575,C576,C577] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1AB104KN AA DD C
Capacitor(10V 0.1µF) [C581,C582,C583,
C584,C585,C586,C587,C588,C589,C591] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1AB104KN AA DD C
Capacitor(10V 0.1µF) [C592,C593,C594,
C595,C596,C597,C598,C599,C600,C601] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1AB104KN AA DD C
Capacitor(10V 0.1µF) [C602,C603,C604,
C605,C606,C607,C608,C609,C610,C611] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1AB104KN AA DD C
Capacitor(10V 0.1µF) [C612,C613,C614,
C615,C616,C618,C619,C620,C621,C622] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1AB104KN AA DD C
Capacitor(10V 0.1µF) [C623,C624,C625,
C626,C627,C628,C629,C630,C631,C632] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1AB104KN AA DD C
Capacitor(10V 0.1µF) [C561,C566,C567,C746] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1AB104KN AA DD C
Capacitor(10V 0.1µF) [C633,C634,C635,C636] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1AB104KN AA DD C
Capacitor(10V 0.1µF) [C637,C638,C639,
C640,C641,C642,C643,C644,C645,C646] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1AB104KN AA DD C
Capacitor(10V 0.1µF) [C647,C648,C649,
C650,C651,C652,C653,C654,C655,C656] ｺﾝﾃﾞﾝｻｰ
