ﾏｻﾞｰ基板ﾕﾆｯﾄ (Mother PWB unit)
NO.
PARTS CODE
Inter-
change
PRICE RANK
NEW
MARK
PART
RANK
DESCRIPTION
TR No.
Effective
time
Ex. Ja.
1 QCNCM0787FCPZ AE DS C
Connector(B10P-VH-B(LF)(SN)) [CN10] ｺﾈｸﾀｰ
2 QCNCM1069ACPZ AD DJ C
Connector(B6P-VH(LF)(SN)) [CN11] ｺﾈｸﾀｰ
3 QCNCM1351FCPZ AD DJ C
Connector(B4P-VH(LF)(SN)) [CN12] ｺﾈｸﾀｰ
4 QCNCM1411FCPZ AR EQ C
Connector(TX25-120P-LT-H1E) [CN1] ｺﾈｸﾀｰ
5 QCNCM0923FC108 AC DJ C
Connector(B10B-PHDSS-B(LF)(SN)) [CN13] ｺﾈｸﾀｰ
6 QCNCM0923FC248 AD DJ C
Connector(B24B-PHDSS-B(LF)(SN)) [CN2] ｺﾈｸﾀｰ
7 QCNCM0923FC328 AE DJ C
Connector(B32B-PHDSS-B(LF)(SN))
(MX-M363F/M423F/M503F)[CN15] ｺﾈｸﾀｰ
8 QCNCW1428FCPZL AF DS C
Connector(BM10B-GHS-TBT(LF)(SN)) [CN16] ｺﾈｸﾀｰ
9 QCNCM1354FCPZ AD DJ C
Connector(B15B-PH-K-S(LF)(SN)) [CN7] ｺﾈｸﾀｰ
10 RC-EZ0357FCPZ+ AD DD C
Capacitor(16V 470µF) [C43] ｺﾝﾃﾞﾝｻｰ
11 RCRSP0107FCPZ+ AE DS B
Crystal(AT-51/(9.8304MHz)) [X1] ｸﾘｽﾀﾙ
12 VCERSX1CN106ML AC DD C
Capacitor(16V 10µF) [C41] ｺﾝﾃﾞﾝｻｰ
13 VCERSX1EN476ML AC DD C
Capacitor(25V 47µF) [C14] ｺﾝﾃﾞﾝｻｰ
14 VCERSX1VN336ML AC DD C
Capacitor(35V 33µF) [C13] ｺﾝﾃﾞﾝｻｰ
15 VCEASX1CN226ML AC DD C
Capacitor(EMVL160ADA220ME60G)
[C15,C16,C17,C18,C21,C39] ｺﾝﾃﾞﾝｻｰ
16 VCERSX1VN226ML AC DD C
Capacitor(35V 22µF) (MX-M363F/M423F/M503F)
[C78] ｺﾝﾃﾞﾝｻｰ
17 RC-AZ0002FCPZL -AGDX C
Capacitor(APXA100ARA470ME60G)
[Missing parts code](North America)[C63] ｺﾝﾃﾞﾝｻｰ
1st lot
18 VCCCRZ1HH120JN AA DD C
Capacitor(50V 12pF) [C27,C28] ｺﾝﾃﾞﾝｻｰ
19 VCCCRZ1HH100JN AA DD C
Capacitor(50V 10pF) (North America)
[C46] ｺﾝﾃﾞﾝｻｰ
20 VCCCRZ1HH150JN AA DD C
Capacitor(50V 15pF(CH)) (North America)
[C56,C60] ｺﾝﾃﾞﾝｻｰ
21 VCKYRZ1EB103KN AA DD C
Capacitor(25V 0.01µF) (North America)[C69] ｺﾝﾃﾞﾝｻｰ
22 VCKYRY1HB104KN AA DD C
Capacitor(50V 0.1µF) [C1,C8,C45] ｺﾝﾃﾞﾝｻｰ
23 VCKYRY1HB104KN AA DD C
Capacitor(50V 0.1µF) (North America)
[C77] ｺﾝﾃﾞﾝｻｰ
24 VCKYRZ1EF223ZN AA DD C
Capacitor(25V 22000pF) [C24] ｺﾝﾃﾞﾝｻｰ
25
VCKYRZ1HB102KN AA DD C
Capacitor(50V 1000pF)
[C2,C3,C6,C9,C10,C12,C19] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1HB102KN AA DD C
Capacitor(50V 1000pF)
[C20,C22,C25,C29,C30,C31,C32] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1HB102KN AA DD C
Capacitor(50V 1000pF)
[C33,C34,C35,C36,C42,C44] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1HB102KN AA DD C
Capacitor(50V 1000pF) (North America)[C53] ｺﾝﾃﾞﾝｻｰ
26 VCKYRV1AF106ZN AB DD C
Capacitor(10V 10µF) (North America)
[C47,C48,C55,C66,C70,C72] ｺﾝﾃﾞﾝｻｰ
27 VCKYRY1AB105KN AA DD C
Capacitor(10V 1µF) (North America)
[C50,C59,C64] ｺﾝﾃﾞﾝｻｰ
28 VCKYRY1AB105KN AA DD C
Capacitor(10V 1µF) (MX-M363F/M423F/M503F)[C73] ｺﾝﾃﾞﾝｻｰ
29 VCKYRZ1AB104KN AA DD C
Capacitor(10V 0.1µF)
[C4,C5,C7,C11,C23,C26,C40] ｺﾝﾃﾞﾝｻｰ
30
VCKYRZ1AB104KN AA DD C
Capacitor(10V 0.1µF) (North America)
[C49,C51,C52,C54,C57,C58,C61,C65,C67] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1AB104KN AA DD C
Capacitor(10V 0.1µF) (MX-M363F/M423F/M503F)[C75] ｺﾝﾃﾞﾝｻｰ
31 RH-IX0053FCPZL -AUEZ B
IC(PIC16F882-I-SS) [Missing parts code][IC2] IC
1st lot
32 VHIAHCT14PW-1L -ADDJ B
IC(SN74AHCT14PWR(74VHCT14AFT))
[Missing parts code][IC3] IC
1st lot
33 VHIBU4242F+-19 AD DJ B
IC(BU4242F-TR) [IC1] IC
34 VHIBU4238F+-1R AD DJ B
IC(BU4238F-TR) (North America)[IC5] IC
35 VHILVDS049P-1L AK DX B
IC(SN65LVDS049PW) (MX-M363F/M423F/M503F)[IC9] IC
36 VHI3USB221R-1L -AGDX B
IC(TS3USB221RSER) [Missing parts code]
(Except North America)[IC7] IC
1st lot
37 VHIL1087MAN-1L AN EG B
IC(L1087MPX-ADJ/NOPB) (North America)[IC4] IC
38 VHIBD6512LF-1L AH DX B
IC(BD6512F-E2) (North America)[IC8] IC
39 VHI2514AEZG-1Q -AUEZ B
IC(USB2514AEZG) [Missing parts code]
(North America)[IC6] IC
1st lot
40
VRSRCZ1JD000JN AA DD C
Resistor(1/16W 0Ω ±5%) [R104,R106] 抵抗
VRSRCZ1JD000JN AA DD C
Resistor(1/16W 0Ω ±5%) (Except North America)
[R87,R88,R89] 抵抗
41 VRSRCZ1JD000JN AA DD C
Resistor(1/16W 0Ω ±5%) (MX-M363F/M423F/M503F)
[R93] 抵抗
42 VRSRCZ1JD101JN AA DD C
Resistor(1/16W 100Ω ±5%) [R8,R18] 抵抗
43 VRSRCZ1JD101JN AA DD C
Resistor(1/16W 100Ω ±5%)
(MX-M363F/M423F/M503F)[R99,R101] 抵抗
44
VRSRCZ1JD102JN AA DD C
Resistor(1/16W 1kΩ ±5%)
[R7,R10,R11,R12,R25,R30,R31] 抵抗
VRSRCZ1JD102JN AA DD C
Resistor(1/16W 1kΩ ±5%)
[R35,R36,R37,R38,R39,R41,R45,R49] 抵抗
45 VRSRCZ1JD102JN AA DD C
Resistor(1/16W 1kΩ ±5%)
(MX-M363F/M423F/M503F)[R91,R97] 抵抗
46
VRSRCZ1JD103JN AA DD C
Resistor(1/16W 10KΩ ±5%)
[R50,R55,R56,R62] 抵抗
VRSRCZ1JD103JN AA DD C
Resistor(1/16W 10KΩ ±5%)
[R6,R16,R17,R21,R27,R28,R44] 抵抗
VRSRCZ1JD103JN AA DD C
Resistor(1/16W 10KΩ ±5%) (North America)
[R77] 抵抗
