– 7-4 –
Update : 2010/11/30
7
PCU 基板ﾕﾆｯﾄ (PCU PWB unit)
NO.
PARTS CODE
Inter-
change
PRICE RANK
NEW
MARK
PART
RANK
DESCRIPTION
TR No.
Effective
time
Ex. Ja.
126 VRSRTP2BD102JN AA DD C
Resistor(1/8W 1.0KΩ ±5%) [R23,R32,R168,R169] 抵抗
127 VRSRTP2BD152JN AA DD C
Resistor(1/8W 1.5KΩ ±5%)
[R19,R20,R21,R22,R336] 抵抗
128 VRSRTP2BD242JN AA DD C
Resistor(1/8W 2.4KΩ ±5%) [R12] 抵抗
129 VRSRTP2BD472JN AA DD C
Resistor(1/4W 4.7KΩ ±5%) [R18,R83,R153,R219] 抵抗
130 VRSRTP2BD562JN -AADD C
Resistor(RMC1/8562JTP) [Missing parts code
[R28] 抵抗
1st lot
131 VRSRTX2HD560JN -ABDD C
Resistor(RMC1/2-560JTE(KAMAYA))
[Missing parts code]
[R147] 抵抗
1st lot
132 VRSRTX2HD561JN -ACDJ C
Resistor(RMC1/2-561JTE(KAMAYA))
[Missing parts code]
[R73,R74,R75,R76] 抵抗
1st lot
134 VCCCRZ1HH120JN AA DD C
Capacitor(50V 12pF) [C143,C148] ｺﾝﾃﾞﾝｻｰ
135 VCCCRZ1HH330JN AA DD C
Capacitor(50V 33pF)
[C31,C50,C74,C130,C192,C193,C209] ｺﾝﾃﾞﾝｻｰ
136 VCCCRZ1HH820JN AA DD C
Capacitor(50V 82pF) [C36,C57] ｺﾝﾃﾞﾝｻｰ
137
VCCCRZ1HH101JN AA DD C
Capacitor(50V 100pF) [C8,C12,C30,C35,
C37,C45,C46,C47,C54,C56,C58,C65] ｺﾝﾃﾞﾝｻｰ
VCCCRZ1HH101JN AA DD C
Capacitor(50V 100pF) [C70,C73,C114,
C115,C116,C125,C126,C127,C128,C133] ｺﾝﾃﾞﾝｻｰ
VCCCRZ1HH101JN AA DD C
Capacitor(50V 100pF) [C134,C135,C136,
C144,C178,C180,C188,C189,C204,C205] ｺﾝﾃﾞﾝｻｰ
VCCCRZ1HH101JN AA DD C
Capacitor(50V 100pF) [C215,C216,C229,
C230,C236,C239,C240,C245,C246,C247] ｺﾝﾃﾞﾝｻｰ
VCCCRZ1HH101JN AA DD C
Capacitor(50V 100pF) [C248,C249,C252,
C253,C261,C262,C265,C266,C269,C270] ｺﾝﾃﾞﾝｻｰ
138 VCCCRZ1HH102JN AA DD C
Capacitor(50V 1000pF) [C3,C14,C49,C71,
C88,C138,C190,C194,C196,C207,C235] ｺﾝﾃﾞﾝｻｰ
139 VCKYRZ1CB103KN AA DD C
Capacitor(16V 0.01µF) [C79] ｺﾝﾃﾞﾝｻｰ
140
VCKYRZ1CB223KN AA DD C
Capacitor(16V 22000pF)
[C10,C16,C20,C197,C201,C203,C221,C228] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1CB223KN -AADD C
Capacitor(16V 22000pF) [C10] ｺﾝﾃﾞﾝｻｰ
09/08
141
VCKYRZ1CF104ZN AA DD C
Capacitor(16V 0.1µF) [C5,C11,C25,C29,
C38,C39,C40,C41,C42,C44,C51,C52] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1CF104ZN AA DD C
Capacitor(16V 0.1µF) [C53,C55,C60,C63,
C66,C67,C68,C72,C75,C76,C77,C81] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1CF104ZN AA DD C
Capacitor(16V 0.1µF) [C82,C89,C90,C92,
C94,C95,C96,C97,C99,C102,C103] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1CF104ZN AA DD C
Capacitor(16V 0.1µF) [C104,C105,C106,
C107,C113,C117,C119,C120,C132,C137] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1CF104ZN AA DD C
Capacitor(16V 0.1µF) [C139,C142,C145,
C146,C147,C156,C162,C163,C173,C174] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1CF104ZN AA DD C
Capacitor(16V 0.1µF) [C198,C199,C200,
C202,C210,C211,C213,C214,C220,C222] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1CF104ZN AA DD C
Capacitor(16V 0.1µF)
[C224,C225,C238,C244,C250,C260,C267,C268] ｺﾝﾃﾞﾝｻｰ
VCKYRZ1CF104ZN AA DD C
Capacitor(16V 0.1µF) (Europe)
[C121,C122,C140,C141,C157,C158,C164] ｺﾝﾃﾞﾝｻｰ
143 VCKYRY1HB473KN AA DD C
Capacitor(50V 0.047µF) [C1] ｺﾝﾃﾞﾝｻｰ
144 VCKYRY1HB104KN AA DD C
Capacitor(50V 0.1µF) [C242,C243] ｺﾝﾃﾞﾝｻｰ
145 VCKYRV1CB105KN AA DD C
Capacitor(16V 1µF) [C112] ｺﾝﾃﾞﾝｻｰ
146 VCKYRV1AB225MN AB DD C
Capacitor(10V 2.2µF) [C129] ｺﾝﾃﾞﾝｻｰ
147 VCERSM1CM226ML AC DD C
Capacitor(16V 10µF) [C21,C233,C263] ｺﾝﾃﾞﾝｻｰ
148
VCERSM1CM476ML AC DD C
Capacitor(16V 47µF) [C28,C109,C182] ｺﾝﾃﾞﾝｻｰ
VCERSM1CM476ML AC DD C
Capacitor(16V 47µF) (Europe)[C175] ｺﾝﾃﾞﾝｻｰ
149 VCERSM1EM476ML AD DD C
Capacitor(25V 47µF) [C232] ｺﾝﾃﾞﾝｻｰ
150 VCERSM1VM106ML AC DD C
Capacitor(35V 10µF) [C17] ｺﾝﾃﾞﾝｻｰ
151 VCERSM1VM476ML AC DD C
Capacitor(35V 47µF) [C2,C4,C15,C231] ｺﾝﾃﾞﾝｻｰ
152 RCRSP0016QSPZ+ AE DJ B
Crystal(HC-49U/S) [X1] ｸﾘｽﾀﾙ
To Next Page
