Sharp MX-M363F User Manual

– 7-3 –
Update : 2010/11/30
7
PCU 基板ﾕﾆｯﾄ (PCU PWB unit)
NO.
PARTS CODE
Inter-
change
PRICE RANK
NEW
MARK
PART
RANK
DESCRIPTION
TR No.
Effective
time
Ex. Ja.
86
VRSRCZ1JD152JN AA DD C
Resistor(1/16W 1.5KΩ ±5%) [R61,R62,R63,R64,
R65,R66,R67,R68,R70,R179,R180] 抵抗
VRSRCZ1JD152JN AA DD C
Resistor(1/16W 1.5KΩ ±5%) [R213,R236] 抵抗
87 VRSRCZ1JD152FN AA DD C
Resistor(1/16W 1.5kΩ ±1%) [R222,R353,R368] 抵抗
88 VRSRCZ1JD202JN AA DD C
Resistor(1/16W 2KΩ ±5%)
[R110,R146,R214,R216,R225,R312] 抵抗
89 VRSRCZ1JD202FN AA DD C
Resistor(1/16W 2KΩ ±1%)
[R324,R377,R379,R396,R433] 抵抗
90 VRSRCZ1JD302JN AA DD C
Resistor(1/16W 3.0kΩ ±1%) [R47,R49,R51,R53,R69] 抵抗
91 VRSRCZ1JD332JN AA DD C
Resistor(1/16W 3.3kΩ ±5%) [R15,R29,R203,R418] 抵抗
92
VRSRCZ1JD472JN AA DD C
Resistor(1/16W 4.7kΩ ±5%) [R1,R2,R31,R43,
R57,R71,R78,R79,R98,R99,R103,R104] 抵抗
VRSRCZ1JD472JN AA DD C
Resistor(1/16W 4.7kΩ ±5%) [R105,R109,R113,
R118,R119,R120,R121,R125,R130,R143] 抵抗
VRSRCZ1JD472JN AA DD C
Resistor(1/16W 4.7kΩ ±5%) [R144,R149,R156,
R175,R176,R186,R205,R221,R253,R295] 抵抗
VRSRCZ1JD472JN AA DD C
Resistor(1/16W 4.7kΩ ±5%) [R348,R358,R369,
R370,R375,R385,R386,R400,R402,R425] 抵抗
VRSRCZ1JD472JN AA DD C
Resistor(1/16W 4.7kΩ ±5%) [R427,R437,R439,
R452,R454,R475,R477,R509,R510,R514] 抵抗
VRSRCZ1JD472JN AA DD C
Resistor(1/16W 4.7kΩ ±5%) [R516] 抵抗
93 VRSRCZ1JD472FN AA DD C
Resistor(1/16W 4.7KΩ ±1%) [R210,R367,R406] 抵抗
94
VRSRCZ1JD103JN AA DD C
Resistor(1/16W 10KΩ ±5%) [R4,R6,R8,R36,
R48,R50,R52,R54,R85,R90,R106,R114] 抵抗
VRSRCZ1JD103JN AA DD C
Resistor(1/16W 10KΩ ±5%) [R116,R122,R123,
R127,R131,R132,R133,R134,R137,R138] 抵抗
VRSRCZ1JD103JN AA DD C
Resistor(1/16W 10KΩ ±5%) [R139,R140,R142,
R145,R150,R151,R157,R158,R161,R162] 抵抗
VRSRCZ1JD103JN AA DD C
Resistor(1/16W 10KΩ ±5%) [R163,R164,R187,
R190,R195,R196,R197,R200,R207,R208] 抵抗
VRSRCZ1JD103JN AA DD C
Resistor(1/16W 10KΩ ±5%) [R217,R223,R224,
R229,R230,R238,R239,R240,R241,R242] 抵抗
VRSRCZ1JD103JN AA DD C
Resistor(1/16W 10KΩ ±5%) [R244,R250,R254,
R262,R264,R266,R276,R288,R292,R293] 抵抗
VRSRCZ1JD103JN AA DD C
Resistor(1/16W 10KΩ ±5%) [R297,R298,R299,
R300,R301,R302,R303,R304,R305,R306] 抵抗
VRSRCZ1JD103JN AA DD C
Resistor(1/16W 10KΩ ±5%) [R307,R308,R311,
R314,R321,R330,R347,R362,R388,R390] 抵抗
VRSRCZ1JD103JN AA DD C
Resistor(1/16W 10KΩ ±5%) [R392,R404,R410,
R415,R417,R420,R461,R464,R466,R468] 抵抗
VRSRCZ1JD103JN AA DD C
Resistor(1/16W 10KΩ ±5%)
[R470,R472,R480,R496,R501,R502,R503,R505] 抵抗
95
VRSRCZ1JD103FN AA DD C
Resistor(1/16W 10kΩ ±1%) [R165,R209,R352,
R371,R373,R394,R405,R408,R413,R431] 抵抗
VRSRCZ1JD103FN AA DD C
Resistor(1/16W 10kΩ ±1%) [R446] 抵抗
96 VRSRCZ1JD113FN AA DD C
Resistor(1/16W 11KΩ ±1%) [R166] 抵抗
97 VRSRCZ1JD153FN AA DD C
Resistor(1/16W 15KΩ ±1%) [R366,R407,R414] 抵抗
98 VRSCZ1JD1912F6 AA DD C
Resistor(1/16W 19.1kΩ ±1%) [R376,R378,R434] 抵抗
99
VRSRCZ1JD203JN AA DD C
Resistor(1/16W 20kΩ ±5%) [R13,R14,R37,R38,
R39,R40,R135,R235,R260,R275,R278] 抵抗
VRSRCZ1JD203JN AA DD C
Resistor(1/16W 20kΩ ±5%) [R280,R356,R419] 抵抗
100 VRSRCZ1JD203FN AA DD C
Resistor(1/16W 20kΩ ±1%) [R360,R393] 抵抗
102 VRSRCZ1JD243FN AA DD C
Resistor(1/16W 24kΩ ±1%) [R291,R332,R342] 抵抗
103
VRSRCZ1JD473JN AA DD C
Resistor(1/16W 47KΩ ±5%) [R3,R9,R82,R154,
R170,R211,R220,R334,R416,R441,R445] 抵抗
VRSRCZ1JD473JN AA DD C
Resistor(1/16W 47KΩ ±5%) [R491] 抵抗
104 VRSRCZ1JD473FN AA DD C
Resistor(1/16W 47KΩ ±1%) [R351] 抵抗
105 VRSRCZ1JD104JN AA DD C
Resistor(1/16W 100kΩ ±5%)
[R296,R412,R455,R456,R458,R507] 抵抗
106 VRSRCZ1JD204FN AA DD C
Resistor(1/16W 200kΩ ±1%) [R290,R318,R341] 抵抗
107 VRSRCZ1JD304FN AA DD C
Resistor(1/16W 300kΩ ±1%) [R319,R333,R355] 抵抗
108 VRSRCZ1JD474JN AA DD C
Resistor(1/16W 470kΩ ±5%) [R251] 抵抗
109 VRSRCZ1JD105JN AA DD C
Resistor(1/16W 1kΩ ±5%) (MX-M283N/M282N)
[R178,R191,R361,R365,R160,R237] 抵抗
110 VRSRCZ1JD105JN AA DD C
Resistor(1/16W 1kΩ ±5%) (MX-M363N/M362N)
[R178,R191,R361,R365,R159,R237] 抵抗
111 VRSRCZ1JD105JN AA DD C
Resistor(1/16W 1kΩ ±5%) (MX-M423F)
[R178,R191,R361,R365,R159,R160] 抵抗
112 VRSRCZ1JD105JN AA DD C
Resistor(1/16W 1kΩ ±5%) (MX-M453N/M453U/M452N)
[R178,R191,R361,R365,R159] 抵抗
113 VRSRCZ1JD105JN AA DD C
Resistor(1/16W 1kΩ ±5%)
(MX-M503N/M503U/M503F/M502N)
[R178,R191,R361,R365] 抵抗
115 VRSRCY1JD000JN AA DD C
Resistor(1/16W 0Ω ±5%)
[R5,R7,R81,R93,R257,R350,R387,R500,R512] 抵抗
119 VRSRTP2BD000JN AA DD C
Resistor(1/8W 0Ω ±5%) [R457,R499] 抵抗
120 VRSRTP2BD101JN AA DD C
Resistor(1/8W 100Ω ±5%)
[R24,R25,R26,R27,R462,R479] 抵抗
122 VRSRTP2BD201JN AA DD C
Resistor(1/8W 200Ω ±5%) [R231,R247,R343] 抵抗
123 VRSRTP2BD271JN AA DD C
Resistor(RMC1/8271JTP) [R77] 抵抗
125 VRSRTP2BD391JN AA DD C
Resistor(RMC1/8391JTP) [R58,R59,R100,R444] 抵抗
