– 9-1 –
Update : 2010/11/30
9
SCN ｺﾝﾄﾛｰﾙ基板ﾕﾆｯﾄ (SCN control PWB unit)
NO.
PARTS CODE
Inter-
change
PRICE RANK
NEW
MARK
PART
RANK
DESCRIPTION
TR No.
Effective
time
Ex. Ja.
1 QCNCM0976FCZZ- AD DJ C
Connector(B4B-PH-SM4-TB(LF)(SN)) [CN1] ｺﾈｸﾀｰ
2 QCNCM1171FCZZL AE DJ C
Connector(B6B-PH-SM4-TB(LF)(SN)) [CN4] ｺﾈｸﾀｰ
3
QCNCW1424FCPZL AE DS C
Connector(BM06B-GHS-TBT(LF)(SN)) [CN14] ｺﾈｸﾀｰ
QCNCW1424FCPZL -AEDS C
Connector(BM06B-GHS-TBT(LF)(SN)) [CN14] ｺﾈｸﾀｰ
09/12
4 VHIKIA393F+-17 AD DJ B
IC(Comparator)(KIA393F-EL/P) [IC6] IC
5
VHDDAN202U/-14 AB DJ B
Diode(DAN202U) [D1,D2,D3,D5,D7,D9] ﾀﾞｲｵｰﾄﾞ
VHDDAN202U/-14 AB DJ B
Diode(DAN202U)
[D12,D14,D15,D17,D26,D32] ﾀﾞｲｵｰﾄﾞ
VHDDAN202U/-14 AB DJ B
Diode(DAN202U)
[D34,D35,D38,D39,D40,D46,D51] ﾀﾞｲｵｰﾄﾞ
VHDDAN202U/-14 AB DJ B
Diode(DAN202U) (MX-M363N/M453N/M503N)
[D36,D37] ﾀﾞｲｵｰﾄﾞ
VHDDAN202U/-14 AB DJ B
Diode(DAN202U) (Except MX-M363N/M453N/M503N)
[D30,D31,D33,D41,D42,D43] ﾀﾞｲｵｰﾄﾞ
VHDDAN202U/-14 AB DJ B
Diode(DAN202U) (Except MX-M363N/M453N/M503N)
[D44,D45,D47,D48,D49,D50] ﾀﾞｲｵｰﾄﾞ
VHDDAN202U/-14 -ABDJ B
Diode(DAN202U) [D38,D40] ﾀﾞｲｵｰﾄﾞ
10/03
VHDDAN202U/-14 AB DJ B
Diode(DAN202U)
[D11,D13,D16,D25,D27,D28,D52] ﾀﾞｲｵｰﾄﾞ
VHDDAN202U/-14 AB DJ B
Diode(DAN202U)
(Except MX-M282N/M362N/M452N/M502N)
[D8,D10] ﾀﾞｲｵｰﾄﾞ
6
VHDDAP202U/-14 AB DJ B
Diode(DAP202U)
[DB1,DB6,DB12,DB13,DB14] ﾀﾞｲｵｰﾄﾞ
VHDDAP202U/-14 AB DJ B
Diode(DAP202U)
[DB15,DB16,DB17,DB20,DB22] ﾀﾞｲｵｰﾄﾞ
VHDDAP202U/-14 AB DJ B
Diode(DAP202U)
[DB23,DB24,DB25,DB26,DB28,DB30,DB31,DB32] ﾀﾞｲｵｰﾄﾞ
VHDDAP202U/-14 AB DJ B
Diode(DAP202U)
[DB36,DB37,DB38,DB39,DB40,DB41] ﾀﾞｲｵｰﾄﾞ
VHDDAP202U/-14 AB DJ B
Diode(DAP202U) (MX-M363N/M453N/M503N)
[DB15,DB16] ﾀﾞｲｵｰﾄﾞ
VHDDAP202U/-14 AB DJ B
Diode(DAP202U) (Except MX-M363N/M453N/M503N)
[DB2,DB3,DB4,DB5,DB7,DB8] ﾀﾞｲｵｰﾄﾞ
VHDDAP202U/-14 AB DJ B
Diode(DAP202U) (Except MX-M363N/M453N/M503N)
[DB9,DB10,DB11,DB18,DB19,DB21] ﾀﾞｲｵｰﾄﾞ
VHDDAP202U/-14 -ABDJ B
Diode(DAP202U) [DB12,DB14] ﾀﾞｲｵｰﾄﾞ
10/03
VHDDAP202U/-14 AB DJ B
Diode(DAP202U) [DB27,DB29,DB33] ﾀﾞｲｵｰﾄﾞ
VHDDAP202U/-14 AB DJ B
Diode(DAP202U)
(Except MX-M282N/M362N/M452N/M502N)
[DB34,DB35] ﾀﾞｲｵｰﾄﾞ
7 VS2SB1197KR-17 AC DJ B
Transistor(2SB1197KT146) [Q8,Q10,Q13] ﾄﾗﾝｼﾞｽﾀｰ
8 VS2SC2412KS-14 AC DJ B
Transistor(2SC2412KT146) [Q7] ﾄﾗﾝｼﾞｽﾀｰ
9 VSDTA114EUB-1L AB ZZ B
Transistor(DTA114EUBTL) [Q1,Q2,Q3] ﾄﾗﾝｼﾞｽﾀｰ
10
VSDTC114YUB-1L AB DJ B
Transistor(DTC114YUBTL)
[Q4,Q5,Q6,Q9,Q11,Q12,Q16] ﾄﾗﾝｼﾞｽﾀｰ
VSDTC114YUB-1L AB DJ B
Transistor(DTC114YUBTL)
[Q21,Q30,Q31,Q32,Q33,Q35] ﾄﾗﾝｼﾞｽﾀｰ
VSDTC114YUB-1L -ABDJ B
Transistor(DTC114YUBTL) [Q37] ﾄﾗﾝｼﾞｽﾀｰ
09/12
VSDTC114YUB-1L AB DJ B
Transistor(DTC114YUBTL)
[Q36,Q37,Q38,Q39,Q40,Q42,Q43,Q44] ﾄﾗﾝｼﾞｽﾀｰ
VSDTC114YUB-1L -ABDJ B
Transistor(DTC114YUBTL) [Q36] ﾄﾗﾝｼﾞｽﾀｰ
10/12
VSDTC114YUB-1L AB DJ B
Transistor(DTC114YUBTL) [Q45] ﾄﾗﾝｼﾞｽﾀｰ
11 VHIBD6705EF-1L AS EQ B
IC(Driver)(BD67055EFV) [IC1] IC
12 VHIBA00DDWH-1R AG DX B
IC(Regulator)(BA00DD0WHFP-TR)
[IC15,IC16,IC17,IC18] IC
13
VRSRTP2BD000JN AA DD C
Resistor(1/8W 0Ω ±5%)
[R35,R55,R57,R65,R68,R71,R72,R93,R97] 抵抗
VRSRTP2BD000JN AA DD C
Resistor(1/8W 0Ω ±5%) [R133] 抵抗
14 VRSRTP2BD330JN -AADD C
Resistor(33J(3216)) [Missing parts code]
[R24,R25,R26,R27,R36,R37,R38,R45,R46,R47,R48] 抵抗
1st lot
15
RMPTR4000ACPZN AA DD B
Block resistor(0JX4(1005x4))
(Except MX-M363N/M453N/M503N)
[BR30,BR32,BR34,BR37] ﾌﾞﾛｯｸ抵抗
RMPTR4000ACPZN AA DD B
Block resistor(0JX4(1005x4))
(Except MX-M363N/M453N/M503N)
[BR38,BR39,BR40] ﾌﾞﾛｯｸ抵抗
RMPTR4000ACPZN AA DD B
Block resistor(0JX4(1005x4))
[BRJ1,BRJ2,BRJ3,BRJ4,BRJ5] ﾌﾞﾛｯｸ抵抗
RMPTR4000ACPZN AA DD B
Block resistor(0JX4(1005x4))
[BRJ6,BRJ7,BRJ8,BRJ9] ﾌﾞﾛｯｸ抵抗
16
RMPTR4101ACPZN AA DD B
Block resistor(100Ω×4 ±5%) [BRB16,BRB24] ﾌﾞﾛｯｸ抵抗
RMPTR4101ACPZN AA DD B
Block resistor(100Ω×4 ±5%)
(Except MX-M363N/M453N/M503N)
[BRB3,BRB4] ﾌﾞﾛｯｸ抵抗
RMPTR4101ACPZN AA DD B
Block resistor(100Ω×4 ±5%)
(Except MX-M363N/M453N/M503N)
[BRB5,BRB8] ﾌﾞﾛｯｸ抵抗
17 RMPTR4100ACPZN AA DD B
Block resistor(10JX4(1005x4))
[BR9,BR10,BR11] ﾌﾞﾛｯｸ抵抗
