– 8-2 –
Update : 2010/05/30
8
ﾏｻﾞｰ基板ﾕﾆｯﾄ (Mother PWB unit)
NO.
PARTS CODE
Inter-
change
PRICE RANK
NEW
MARK
PART
RANK
DESCRIPTION
TR No.
Effective
time
Ex. Ja.
47 VRSRCZ1JD103JN AA DD C
Resistor(1/16W 10KΩ ±5%)
(MX-M363F/M423F/M503F)[R100,R102] 抵抗
48 VRSRCZ1JD104JN AA DD C
Resistor(1/16W 100kΩ ±5%)
[R1,R2,R3,R4,R5,R42,R103] 抵抗
49 VRSRCZ1JD105JN AA DD C
Resistor(1/16W 1MΩ ±5%) [R22] 抵抗
50 VRSRCZ1JD472JN AA DD C
Resistor(1/16W 4.7kΩ ±5%) [R9] 抵抗
51
VRSRCZ1JD473JN AA DD C
Resistor(1/16W 47KΩ ±5%) [R40,R43,R68] 抵抗
VRSRCZ1JD473JN AA DD C
Resistor(1/16W 47KΩ ±5%) (North America)
[R71,R76,R78,R79,R80,R84] 抵抗
52 VRSRCZ1JD473JN AA DD C
Resistor(1/16W 47KΩ ±5%)
(MX-M363F/M423F/M503F)[R94,R96] 抵抗
53 VRSRCZ1JD121FN AA DD C
Resistor(MCR01MZSF121RC0402FR-07120RL)
(North America)[R69] 抵抗
54 VRSRCZ1JD201FN AA DD C
Resistor(1/16W 200Ω ±1%) (North America)
[R70] 抵抗
55 VRSRCZ1JD123FN AA DD C
Resistor(1/16W 12KΩ ±1%) (North America)[R82] 抵抗
56 VRSRTP2BD102JN AA DD C
Resistor(MCR18EZHJ102RC1206JR-071KL)
[R15] 抵抗
57 VRSRTP2BD472JN AA DD C
Resistor(MCR18EZPJ472RC1206JR-074K7L)
[R66] 抵抗
58 VRSRTP2BD473JN AA DD C
Resistor(MCR18EZHJ473RC1206JR-0747KL)
[R67] 抵抗
59 VHDDAP202U/-14 AB DJ B
Diode(DAP202UT106)
[D2,D4,D5,D6,D7,D10,D11] ﾀﾞｲｵｰﾄﾞ
60 VHDRLS73///-14 AC DJ B
Diode(RLS-73TE-11) [D13] ﾀﾞｲｵｰﾄﾞ
61 VSTPC8021HQ-1L AG DS B
FET(TPC8021-H(TE12L,Q)) [Q24] FET
62 VS2SK3018++-17 AC DJ B
FET(2SK3018T106) [Q8] FET
63 VS2SC4081UB0CL -ABDJ B
Transistor(2SC4081UBTL) [Missing parts code][Q17] ﾄﾗﾝｼﾞｽﾀｰ
1st lot
64 VSDTA143ZUB-1L -ABDJ B
Transistor(DTA143ZUBTL) [Missing parts code][Q10] ﾄﾗﾝｼﾞｽﾀｰ
1st lot
65
VSDTC143ZUB-1L AB DD B
Transistor(DTC143ZUBTL)
[Q1,Q4,Q7,Q9,Q14,Q15,Q18] ﾄﾗﾝｼﾞｽﾀｰ
VSDTC143ZUB-1L AB DD B
Transistor(DTC143ZUBTL) [Q19,Q20] ﾄﾗﾝｼﾞｽﾀｰ
66 VSDTC114YUB-1L AB DJ B
Transistor(DTC114YUBTL)
[Q2,Q3,Q5,Q6,Q11,Q16,Q21,Q23] ﾄﾗﾝｼﾞｽﾀｰ
67 VSDTC114YUB-1L AB DJ B
Transistor(DTC114YUBTL) (MX-M363F/M423F/M503F)
[Q26,Q27,Q28,Q29] ﾄﾗﾝｼﾞｽﾀｰ
68 RFILN0313FCPZN AA DJ C
Filter(BLM18PG121SN1D) (North America)
[L1,L2,L4,L5] ﾌｨﾙﾀｰ
69 VHQNSMDC110-1N AE DS B
PWB protector(nanoSMDC110F-2) (North America)
[R86] 回路ﾌﾟﾛﾃｸﾀｰ
70 RCRSC0113FCPZN -AHDX B
Crystal(FA-238_24M_50ppm_10pF)[Missing parts code]
(North America)[X4] ｸﾘｽﾀﾙ
1st lot
71 QCNCM1307FCPZR AH DX C
Connector(501190-3017) [CN6] ｺﾈｸﾀｰ
72 QCNCM0923FC128 AD DJ C
Connector(B12B-PHDSS-B(LF)(SN)) [CN5] ｺﾈｸﾀｰ
73 QCNCM0923FC228 AF DJ C
Connector(B22B-PHDSS-B(LF)(SN)) [CN4] ｺﾈｸﾀｰ
74 QCNCM0880FCPZ AE DS C
Connector(B26B-PHDSS-B(LF)(SN)) [CN3] ｺﾈｸﾀｰ
75 QCNCM7014SC0C8 AB DJ C
Connector(B3B-PH-K-S(LF)(SN)) [CN14] ｺﾈｸﾀｰ
76 VHDDAN202U/-14 AB DJ B
Diode(DAN202U) [D1,D3,D8,D9] ﾀﾞｲｵｰﾄﾞ
77 VCKYRZ1AB104KN AA DD C
Capacitor(10V 0.1µF) (Except North America)
[C71] ｺﾝﾃﾞﾝｻｰ
78 QCNCM7014SC1A8 AC DJ C
Connector(B11B-PH-K-S(LF)(SN)) [CN17] ｺﾈｸﾀｰ
79 VRSRCZ1JD202JN AA DD C
Resistor(1/16W 2KΩ ±5%) [R23] 抵抗
80 VCKYRV1AF106ZN AB DD C
Capacitor(10V 10µF) (MX-M363F/M423F/M503F)
[C74,C76] ｺﾝﾃﾞﾝｻｰ
To Next Page
