– 12-1 –
Update : 2010/11/30
H
RSPF ﾄﾞﾗｲﾊﾞｰ基板ﾕﾆｯﾄ (RSPF Driver PWB unit)Except MX-M282N/M362N/M452N/M502N
NO.
PARTS CODE
Inter-
change
PRICE RANK
NEW
MARK
PART
RANK
DESCRIPTION
TR No.
Effective
time
Ex. Ja.
1 VRSRCZ1JD103JN AA DD C
Resistor(1/16W 10KΩ ±5%)
[R3,19,20,25∼28,42,50∼53] 抵抗
2 VRSRCZ1JD101JN AA DD C
Resistor(1/16W 100Ω ±5%) [R6∼14,30∼33] 抵抗
3 VRS-CZ1JD431F- -AADD C
Resistor(430F 1/16W/1005) [Missing parts code]
[R29] 抵抗
1st lot
4 VRSRCZ1JD471FN AA DD C
Resistor(1/16W 47Ω ±1%) [R45] 抵抗
5 VRSRCZ1JD511FN -AADD C
Resistor(510F 1/16W/1005) [Missing parts code
[R36] 抵抗
1st lot
6 VRSRCZ1JD511JN AA DD C
Resistor(1/16W 510Ω ±5%) [R43,44] 抵抗
7 VRSRCZ1JD561FN AA DD C
Resistor(1/16W 6Ω ±1%) [R47] 抵抗
8 VRSRCZ1JD472FN AA DD C
Resistor(4.7KF 1/16W/1005) [R35,49] 抵抗
9 VRSRCZ1JD203JN AA DD C
Resistor(1/16W 20kΩ ±5%) [R17,18,21,22] 抵抗
10 VRSRCZ1JD473JN AA DD C
Resistor(1/16W 47KΩ ±5%) [R4,5,15] 抵抗
11 VCKYRZ1CF104ZN AA DD C
Capacitor(16V 0.1µF) [C2,5,18,30,31] ｺﾝﾃﾞﾝｻｰ
12 VCKYRZ1HB222KN AA DD C
Capacitor(50V 2200pF) [C11∼16] ｺﾝﾃﾞﾝｻｰ
13 VCKYCZ1CF473Z- AA DD C
Capacitor(16V 0.047µF) [C23,32] ｺﾝﾃﾞﾝｻｰ
14 VCKYRY1HB223KN AA DD C
Capacitor(50V 22000pF) [C26,27,35] ｺﾝﾃﾞﾝｻｰ
15 VSRT1N141C+-1L -ACDD B
Transistor(RT1N141C) [Missing parts code]
[Q1∼4] ﾄﾗﾝｼﾞｽﾀｰ
1st lot
16 VHDDAN202K/-14 AB DJ B
Diode(DAN202K) [D6,8,12] ﾀﾞｲｵｰﾄﾞ
17 VHDDAP202K/-14 AB DJ B
Diode(DAP202K) [D5,7,11] ﾀﾞｲｵｰﾄﾞ
18 VS2SK3065++-17 AE DJ B
Transistor(2SK3065) [Q5] FET
19 VHI74HC151M-17 AE DJ B
IC(MM74HC151MX) [IC1] IC
20 VHERD16FMAY-1L -AFDS B
Zener diode(RD16FM-T1-AZ) [Missing parts code]
[ZD2] ﾂｪﾅｰﾀﾞｲｵｰﾄﾞ
1st lot
21 VHDDSS133//-11 AA DJ B
Diode(1SS133) [D16] ﾀﾞｲｵｰﾄﾞ
22 VHEMTZJ20B/-11 AB DJ B
Zener diode(RD16FM-T1-AZ) [ZD3] ﾂｪﾅｰﾀﾞｲｵｰﾄﾞ
23 VRDRHT2EY104JA AA DD C
Resistor(1/4W 100kΩ ±5%) [R34] 抵抗
25 VCESGA1VW476M+ AB DD C
Capacitor(35V 47µF) [C24,25,34] ｺﾝﾃﾞﾝｻｰ
27 VHVICPN15//-1T AD DJ B
IC protector(ICP-N15) [ICP1,4,5] IC ﾌﾟﾛﾃｸﾀｰ
28 VHVICPN20//-1T AE DJ B
IC protector(ICP-N20) [ICP3] IC ﾌﾟﾛﾃｸﾀｰ
29 VHVICPN38//-12 AD DJ B
IC protector(ICP-N38) [ICP2,6] IC ﾌﾟﾛﾃｸﾀｰ
30 VRSRRE3DAR47J AC DD C
Resistor(2W 0.47Ω ±5%) [R38,39,48,54] 抵抗
31 VHISLA7066M-1S AT EZ B
IC(SLA7066M) [IC3] IC
32 VHISTA7100M-1H AN EQ B
IC(STA7100M) [IC2] IC
33 VHITD62003AP18 AE DS B
IC(TD62003AP) [IC4] IC
34 QCNCM0923FC3D8 AE DS C
Connector(B34B-PHDSS-B) [CNA] ｺﾈｸﾀｰ
35
QCNCM0923FC108 AC DJ C
Connector(B10B-PHDSS-B) [CNB] ｺﾈｸﾀｰ
QCNCM0155QSPZ 1ACDJ C
Connector(B10B-PHDSS) [CNB] ｺﾈｸﾀｰ
10/02 R/C
36 QCNCM7014SC0I AB DD C
Connector(B9B-PH-K-S) [CNC] ｺﾈｸﾀｰ
37 QCNCM7014SC0D8 AB DJ C
Connector(B4B-PH-K-S) [CND] ｺﾈｸﾀｰ
38 QCNCM7014SC0F8 AC DJ C
Connector(B6B-PH-K-S) [CNE] ｺﾈｸﾀｰ
39 QCNCM7014SC0G8 AC DJ C
Connector(B7B-PH-K-S) [CNF] ｺﾈｸﾀｰ
40 QCNCM7014SC0H8 AC DJ C
Connector(B8B-PH-K-S) [CNG] ｺﾈｸﾀｰ
41 QCNCM7014SC1B8 AD DJ C
Connector(B12B-PH-K-S) [CNH] ｺﾈｸﾀｰ
To Next Page
