AC 基板ﾕﾆｯﾄ (AC PWB unit)
NO.
PARTS CODE
Inter-
change
PRICE RANK
NEW
MARK
PART
RANK
DESCRIPTION
TR No.
Effective
time
Ex. Ja.
! 1 QFS-A2700QCPZ AF DS A
Fuse(TLC 20A) (Japan)[F1,F2] ﾋｭｰｽﾞ
! 2 QFS-B3631QCPZ AH DS A
Fuse(TLC 15A N4) (100V series)[F1] ﾋｭｰｽﾞ
!
3 QFS-D1421QCPZ AE DJ A
Fuse(215 010.MXP) (200V series)
[F1,F2] ﾋｭｰｽﾞ
!
4
QFS-E1311QCPZ AD DJ A
Fuse(215 002.MXP) [F3] ﾋｭｰｽﾞ
!
QFS-E1311QCPZ AD DJ A
Fuse(215 002.MXP) (Japan,200V series)
[F4] ﾋｭｰｽﾞ
5
QFSHD0026FCZZ AC DJ C
Fuse holder(TP00335-31) (Japan,100V series)
[F1] ﾋｭｰｽﾞﾎﾙﾀﾞｰ
QFSHD0026FCZZ AC DJ C
Fuse holder(TP00335-31) (Japan)[F2] ﾋｭｰｽﾞﾎﾙﾀﾞｰ
6
QFSHB0028FCZZ+ AC DJ C
Fuse holder(TP00351-31) [F3] ﾋｭｰｽﾞﾎﾙﾀﾞｰ
QFSHB0028FCZZ+ AC DJ C
Fuse holder(TP00351-31) (Japan,200V series)
[F4] ﾋｭｰｽﾞﾎﾙﾀﾞｰ
QFSHB0028FCZZ+ AC DJ C
Fuse holder(TP00351-31) (200V series)
[F1,F2] ﾋｭｰｽﾞﾎﾙﾀﾞｰ
7 QTANP0210FCPZ+ AC DJ C
Earth terminal(TP00451-21) [FG2(FG1)] ｱｰｽ端子
8 QSPGC0001FCZZ AK DX B
Surge absorber(DA38-272MB-M) (Japan,100V series)
[A3(A1)] ｻｰｼﾞﾊﾞﾌﾞｿｰﾊﾞｰ
9 QSPGC0003FCZZ AH DX B
Surge absorber(DA38-302MB-M) (200V series)
[A3(A1)] ｻｰｼﾞﾊﾞﾌﾞｿｰﾊﾞｰ
10 VHV10V471K+-1 AD DJ B
Varistor(TNR10V471K) [VR2] ﾊﾞﾘｽﾀ
11 RC-FZ1028QCPZ AE DS C
Capacitor(LE105-M) [C1] ｺﾝﾃﾞﾝｻｰ
12 RC-KZ0017QCZZ AE DJ C
Capacitor(DE1E3KX472MA5BA01) [C2,C3] ｺﾝﾃﾞﾝｻｰ
13 RC-FZ1027QCPZ AH DX C
Capacitor(LE224-M) [C4] ｺﾝﾃﾞﾝｻｰ
14 RCILF0130FCPZ AL EB C
Common mode coi(DRC25-S041322) [L1] ｺｲﾙ
15 VRDRHT2HY474JA AA DD C
Resistor(CFS1/2CT26A474J) [R1] 抵抗
16 QCNCM0895FCPZ AF DS C
Connector(B03P-VL) [CN1] ｺﾈｸﾀｰ
17 QCNCM1234FCPZ AF DS C
Connector(B03P-VL-K) [CN2] ｺﾈｸﾀｰ
18 QCNCM0989FCPZ AF DS C
Connector(B03P-VL-R) [CN3] ｺﾈｸﾀｰ
19 QCNCM1232FCPZ AC DJ C
Connector(B2P4-VH-B(LF)) [CN4] ｺﾈｸﾀｰ
20 QCNCM1235FCPZ AF DS C
Connector(B03P-VL-E) [CN5] ｺﾈｸﾀｰ
21 QCNCM0843FCPZ AC DJ C
Connector(B2P3-VH-R(LF)) [CN6] ｺﾈｸﾀｰ
22 QCNCM0781FCZZ AD DJ C
Connector(B4P-VH-B(LF)) [CN7] ｺﾈｸﾀｰ
23 QCNCM0042ESPZ AB DJ C
Connector(B3B-PH-K-S(LF)(SN)) [CN8] ｺﾈｸﾀｰ
27 VHD10JDA10+-1T AC DJ B
Diode(10JDA10) [D2] ﾀﾞｲｵｰﾄﾞ
29 VCES4A1VN476M+ AB DD C
Capacitor(EKMG350ETC470ME11D) [C5] ｺﾝﾃﾞﾝｻｰ
30 VS2SJ494+++-1 AL EB B
FET(2SJ494-AZ) [Q1] FET
31 LSUPP0003FCZZ AC DD C
Spacer(KGTS-4T) [SP1,SP2] ｽﾍﾟｰｻｰ
