Sharp MX-M363F User Manual

– 9-2 –
Update : 2010/11/30
9
SCN ｺﾝﾄﾛｰﾙ基板ﾕﾆｯﾄ (SCN control PWB unit)
NO.
PARTS CODE
Inter-
change
PRICE RANK
NEW
MARK
PART
RANK
DESCRIPTION
TR No.
Effective
time
Ex. Ja.
18
RMPTR4103ACPZN AA DD B
Block resistor(10KΩ×4 ±5%)
[BRB10,BRB11,BRB12,BRB13] ﾌﾞﾛｯｸ抵抗
RMPTR4103ACPZN AA DD B
Block resistor(10KΩ×4 ±5%)
[BRB14,BRB15,BRB17,BRB18] ﾌﾞﾛｯｸ抵抗
RMPTR4103ACPZN AA DD B
Block resistor(10KΩ×4 ±5%)
[BRB19,BRB20,BRB21,BRB22] ﾌﾞﾛｯｸ抵抗
18
RMPTR4103ACPZN AA DD B
Block resistor(10KΩ×4 ±5%)
[BRB23,BRB25,BRB27,BRB28] ﾌﾞﾛｯｸ抵抗
RMPTR4103ACPZN AA DD B
Block resistor(10KΩ×4 ±5%)
(MX-M363N/M453N/M503N)
[BRB21] ﾌﾞﾛｯｸ抵抗
RMPTR4103ACPZN AA DD B
Block resistor(10KΩ×4 ±5%)
(Except MX-M363N/M453N/M503N)
[BRB2,BRB6] ﾌﾞﾛｯｸ抵抗
RMPTR4103ACPZN AA DD B
Block resistor(10KΩ×4 ±5%)
(Except MX-M363N/M453N/M503N)
[BRB7,BRB9] ﾌﾞﾛｯｸ抵抗
19
RMPTR4102ACPZN AA DD B
Block resistor(1KΩ×4 ±5%) [BRB26,BRB29] ﾌﾞﾛｯｸ抵抗
RMPTR4102ACPZN AA DD B
Block resistor(1KΩ×4 ±5%)
(Except MX-M363N/M453N/M503N)
[BRB1] ﾌﾞﾛｯｸ抵抗
20
RMPTR4220ACPZN AA DD B
Block resistor(22Ω×4 1/16W ±5%)
(MX-M363N/M453N/M503N)
[BR46,BR47,BR48] ﾌﾞﾛｯｸ抵抗
RMPTR4220ACPZN AA DD B
Block resistor(22Ω×4 1/16W ±5%)
(MX-M363N/M453N/M503N)
[BR49,BR50,BR51] ﾌﾞﾛｯｸ抵抗
RMPTR4220ACPZN AA DD B
Block resistor(22Ω×4 1/16W ±5%)
(Except MX-M363N/M453N/M503N)
[BR28,BR29,BR31,BR33] ﾌﾞﾛｯｸ抵抗
RMPTR4220ACPZN AA DD B
Block resistor(22Ω×4 1/16W ±5%)
(Except MX-M363N/M453N/M503N)
[BR35,BR36,BR41] ﾌﾞﾛｯｸ抵抗
21
RMPTR4330ACPZN AA DD B
Block resistor(33Ω×4 ±5%)
[BR21,BR22,BR23,BR24] ﾌﾞﾛｯｸ抵抗
RMPTR4330ACPZN AA DD B
Block resistor(33Ω×4 ±5%) [BR25,BR26,BR27] ﾌﾞﾛｯｸ抵抗
RMPTR4330ACPZN AA DD B
Block resistor(33Ω×4 ±5%)
[BR42,BR43,BR44,BR45] ﾌﾞﾛｯｸ抵抗
RMPTR4330ACPZN AA DD B
Block resistor(33Ω×4 ±5%) [BR53,BR54,BR55] ﾌﾞﾛｯｸ抵抗
RMPTR4330ACPZN AA DD B
Block resistor(33Ω×4 ±5%) (MX-M283N/M363N/
M453N/M503N/M282N/M362N/M452N/M502N)
[BR13,BR14,BR16,BR17] ﾌﾞﾛｯｸ抵抗
RMPTR4330ACPZN AA DD B
Block resistor(33Ω×4 ±5%) (MX-M283N/M363N/
M453N/M503N/M282N/M362N/M452N/M502N)
[BR18,BR19,BR20] ﾌﾞﾛｯｸ抵抗
RMPTR4330ACPZN AA DD B
Block resistor(33Ω×4 ±5%) (MX-M363F/M423F/
M503F/M363U/M453U/M503U)
[BR12,BR15] ﾌﾞﾛｯｸ抵抗
22
RMPTR4680ACPZN AA DD B
Block resistor(68Ω×4 ±5%)
[BR1,BR2,BR3,BR4,BR5] ﾌﾞﾛｯｸ抵抗
RMPTR4680ACPZN AA DD B
Block resistor(68Ω×4 ±5%) [BR6,BR7,BR8] ﾌﾞﾛｯｸ抵抗
RMPTR4680ACPZN AA DD B
Block resistor(68Ω×4 ±5%)
[BR52,BR56,BR57] ﾌﾞﾛｯｸ抵抗
23
VRSRCZ1JD000JN AA DD C
Resistor(1/16W 0Ω ±5%)
[R4,R15,R17,R21,R74,R75] 抵抗
VRSRCZ1JD000JN AA DD C
Resistor(1/16W 0Ω ±5%)
[R76,R92,R101,R135,R136] 抵抗
VRSRCZ1JD000JN AA DD C
Resistor(1/16W 0Ω ±5%)
[R154,R159,R177,R197,R245,R271,R323,R327] 抵抗
VRSRCZ1JD000JN AA DD C
Resistor(1/16W 0Ω ±5%)
[R352,R358,R377,R379,R400] 抵抗
VRSRCZ1JD000JN AA DD C
Resistor(1/16W 0Ω ±5%)
[R402,R404,R405,R406] 抵抗
VRSRCZ1JD000JN AA DD C
Resistor(1/16W 0Ω ±5%) (MX-M283N/M363N/
M453N/M503N/M282N/M362N/M452N/M502N)
[R179] 抵抗
VRSRCZ1JD000JN AA DD C
Resistor(1/16W 0Ω ±5%)
(Except MX-M363N/M453N/M503N)
[R178] 抵抗
VRSRCZ1JD000JN AA DD C
Resistor(1/16W 0Ω ±5%)
[R236,R239,R240,R244,R267,R320,R376] 抵抗
VRSRCZ1JD000JN AA DD C
Resistor(1/16W 0Ω ±5%) [R383,R401,R403] 抵抗
VRSRCZ1JD000JN AA DD C
Resistor(1/16W 0Ω ±5%)
[R18,R90,R94,R96,R98] 抵抗
VRSRCZ1JD000JN -AADD C
Resistor(1/16W 0W ±5%)
[R177,R197,R327,R379,R400] 抵抗
10/04 R/C
VRSRCZ1JD000JN AA DD C
Resistor(1/16W 0Ω ±5%)
[R99,R100,R160,R234] 抵抗
VRSRCZ1JD000JN AA DD C
Resistor(1/16W 0Ω ±5%) (MX-M363F/M423F/
M503F/M363U/M453U/M503U)
[R158,R186] 抵抗
