Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
116
PG-A10S
PG-A10S-SL
AN-A10T
R8070 VRS-CJ1JF332JY J 3.3k 1/16W Metal Oxide AA
R8074 VRS-CJ1JF000JY J 0 1/16W Metal Oxide AA
R8076 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R8080 VRS-CY1JF680JY J 68 1/16W Metal Oxide AA
R8081 VRS-CY1JF680JY J 68 1/16W Metal Oxide AA
R8085 VRS-CY1JF680JY J 68 1/16W Metal Oxide AA
R8086 VRS-CY1JF680JY J 68 1/16W Metal Oxide AA
R8089 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R8201 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R8202 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R8203 VRS-CY1JF103FY J 10k 1/16W Metal Oxide AA
R8204 VRS-CY1JF332FY J 3.3k 1/16W Metal Oxide AA
R8205 VRS-CY1JF332JY J 3.3k 1/16W Metal Oxide AA
R8206 VRS-CJ1JF101JY J 100 1/16W Metal Oxide AA
R8208 VRS-CY1JF332JY J 3.3k 1/16W Metal Oxide AA
SWITCHES
S2002 QSW-K0099TAZZY J Service Switch AC
S2501 QSW-K0108CEZZY J Switch, KEYSTONE AD
S2502 QSW-K0108CEZZY J Switch, - AD
S2508 QSW-K0108CEZZY J Switch, + AD
S2509 QSW-K0108CEZZY J Switch, OFF AD
S2510 QSW-K0108CEZZY J Switch, AUTO SYNC AD
S2511 QSW-K0108CEZZY J Switch, INPUT AD
S2514 QSW-K0108CEZZY J Switch, ON AD
MISCELLANEOUS PARTS
FB401 RBLN-0058CEZZY J Ferrite Bead AB
FB402 RBLN-0058CEZZY J Ferrite Bead AB
FB403 RBLN-0058CEZZY J Ferrite Bead AB
FB407 RBLN-0058CEZZY J Ferrite Bead AB
FB408 RBLN-0058CEZZY J Ferrite Bead AB
FB1101 RBLN-0059CEZZY J Ferrite Bead AB
FB1102 RBLN-0059CEZZY J Ferrite Bead AB
FB1106 RBLN-0059CEZZY J Ferrite Bead AB
FB1201 RBLN-0059CEZZY J Ferrite Bead AB
FB1202 RBLN-0059CEZZY J Ferrite Bead AB
FB1206 RBLN-0059CEZZY J Ferrite Bead AB
FB1301 RBLN-0059CEZZY J Ferrite Bead AB
FB1302 RBLN-0059CEZZY J Ferrite Bead AB
FB1306 RBLN-0059CEZZY J Ferrite Bead AB
FB1701 RBLN-0064TAZZY J Ferrite Bead AB
FB1702 RBLN-0064TAZZY J Ferrite Bead AB
FB1703 RBLN-0064TAZZY J Ferrite Bead AB
FB1704 RBLN-0064TAZZY J Ferrite Bead AB
FB1705 RBLN-0064TAZZY J Ferrite Bead AB
FB1706 RBLN-0064TAZZY J Ferrite Bead AB
FB1707 RBLN-0064TAZZY J Ferrite Bead AB
FB1708 RBLN-0064TAZZY J Ferrite Bead AB
FB1709 RBLN-0064TAZZY J Ferrite Bead AB
FB1710 RBLN-0059CEZZY J Ferrite Bead AB
FB1711 RBLN-0064TAZZY J Ferrite Bead AB
FB1712 RBLN-0064TAZZY J Ferrite Bead AB
FB1713 RBLN-0095CEZZY J Ferrite Bead AD
FB1714 RBLN-0095CEZZY J Ferrite Bead AD
FB1715 RBLN-0058TAZZY J Ferrite Bead AC
FB1716 RBLN-0095CEZZY J Ferrite Bead AD
FB1717 RBLN-0095CEZZY J Ferrite Bead AD
FB2001 RBLN-0067CEZZY J Ferrite Bead AB
FB2002 RBLN-0067CEZZY J Ferrite Bead AB
FB2005 RBLN-0059CEZZY J Ferrite Bead AB
FB2006 RBLN-0059CEZZY J Ferrite Bead AB
FB2007 RBLN-0061TAZZY J Ferrite Bead AD
FB2008 RBLN-0061TAZZY J Ferrite Bead AD
FB2009 RBLN-0061TAZZY J Ferrite Bead AD
FB2011 RBLN-0067CEZZY J Ferrite Bead AB
FB2012 RBLN-0067CEZZY J Ferrite Bead AB
FB2013 RBLN-0067CEZZY J Ferrite Bead AB
FB2014 RBLN-0067CEZZY J Ferrite Bead AB
FB2601 RBLN-0061TAZZY J Ferrite Bead AD
FB2602 RBLN-0061TAZZY J Ferrite Bead AD
FB2603 RBLN-0061TAZZY J Ferrite Bead AD
FB2604 RBLN-0061TAZZY J Ferrite Bead AD
FB2605 RBLN-0061TAZZY J Ferrite Bead AD
FB3101 RBLN-0059CEZZY J Ferrite Bead AB
FB3302 RBLN-0058CEZZY J Ferrite Bead AB
FB3303 RBLN-0058CEZZY J Ferrite Bead AB
FB3304 RBLN-0064TAZZY J Ferrite Bead AB
FB3305 RBLN-0064TAZZY J Ferrite Bead AB
FB3306 RBLN-0064TAZZY J Ferrite Bead AB
FB4004 RBLN-0058CEZZY J Ferrite Bead AB
FB4005 RBLN-0058CEZZY J Ferrite Bead AB
FB4006 RBLN-0058CEZZY J Ferrite Bead AB
FB4007 RBLN-0058CEZZY J Ferrite Bead AB
FB4008 RBLN-0058CEZZY J Ferrite Bead AB
FB4009 RBLN-0058CEZZY J Ferrite Bead AB
FB4010 RBLN-0058CEZZY J Ferrite Bead AB
FB5001 RBLN-0059CEZZY J Ferrite Bead AB
FB6002 RBLN-0067CEZZY J Ferrite Bead AB
FB6003 RBLN-A005WJZZY J Ferrite Bead AA
FB6004 RBLN-0081TAZZY J Ferrite Bead AA
FB6005 RBLN-0081TAZZY J Ferrite Bead AA
FB8001 RBLN-0067CEZZY J Ferrite Bead AB
FB8002 RBLN-0067CEZZY J Ferrite Bead AB
FB8003 RBLN-0067CEZZY J Ferrite Bead AB
FB8004 RBLN-0067CEZZY J Ferrite Bead AB
FB8005 RBLN-0067CEZZY J Ferrite Bead AB
FB8006 RBLN-0067CEZZY J Ferrite Bead AB
J401 QSOCD0456CEZZ J DIN Jack Socket AE
J402 QJAKEA042WJZZ J Jack (Video) AE
J3301 QJAKEA043WJZZ J Jack, Audio-In AC
P1301 QPLGN0458REZZY J Plug, 4pin(TC) AD
P1701 QPLGN0464TAZZY J Plug, 4pin(FE) AC
P1702 QPLGN0364TAZZY J Plug, 3pin(FG) AC
P1703 QPLGN0464TAZZY J Plug, 4pin(FA) AC
P1704 QPLGN0364TAZZY J Plug, 3pin(FB) AC
P1705 QPLGN0364TAZZY J Plug, 3pin(FC) AC
P1706 QPLGN0175FJZZY J Plug, 3pin(FD) AC
P1707 QPLGN0429FJZZ J Plug, 16pin(EA) AD
P1708 QPLGN0174FJZZY J Plug, 2pin(TF) AC
P2001 QPLGN0263TAZZY J Plug, 2pin(TH) AB
P2004 QPLGN0364TAZZY J Plug, 3pin(RC) AC
P2005 QPLGN0363TAZZY J Plug, 3pin(TI) AC
P2006 QPLGN0264TAZZY J Plug, 2pin(LF) AC
P3301 QPLGN0264TAZZY J Plug, 2pin(SP) AC
SC1101 QSOCN3271TAZZY J Socket, 32pin(RP) AE
SC1201 QSOCNA147WJZZY J Socket, 32pin(GP) AE
SC1301 QSOCN3271TAZZY J Socket, 32pin(BP) AE
SC4001 QSOCNA130WJZZ J Socket, 17pin AG
SC4002 QSOCD0902CEZZ J DIN Jack Socket AL
DUNTKB840FE01
MAIN UNIT (Continued)
CAPACITORS
C1501 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1502 VCEAPF1CW107MY J 100 16V Electrolytic AC
RESISTORS
R1501 VRS-CY1JF471JY J 470 1/16W Metal Oxide AA
R1502 VRS-TX2HF220JY J 22 1/2W Metal Oxide AB
MISCELLANEOUS PARTS
P1502 QPLGN0198FJZZY J Plug,3pin(RC) AD
RMC1501 RRMCU0239CEZZ J Remote Receiver AG
PSLDC3117CEFW J Shield AD
QCNW-B111WJZZ J Connecting Cord AE
DUNTKB601DE01
R/C RECEIVER UNIT
