Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
117
PG-A10S
PG-A10S-SL
AN-A10T
RDENCA029WJZZ
POWER UNIT
INTEGRATED CIRCUITS
IC701 95CH1156AC001 J FA5501AN-TE1
IC751 95C0H1Q3A0010 J TA76431 AQ
TRANSISTORS
å Q701 95C0T643A0010 J FET, 2SK2698 AY
å Q702 95C0T645A0020 J FET, 2SK2717 AW
Q703 95C0T394A0010 J 2SC4081 AH
Q704 95C0T196A0010 J 2SA1812 AS
Q705 95C0T192A0010 J 2SA1576A AH
Q706 95C0T394A0010 J 2SC4081 AH
Q707 95C0T395A0020 J 2SC4097 AL
Q708 95C0T190A0020 J 2SA1313 AH
Q709 95C0T391A0050 J 2SC2712 AF
Q751 95C0T394A0010 J 2SC4081 AH
DIODES
D701 95C0D114A6040 J D3SBA60 AV
å D702 95CD2172AL006 J SF10L60U AR
D704 95C0D2Q1A0060 J EC21QS06 AQ
D705 95C0D491A0290 J Zener Diode, UDZ30B AM
D707 95C0D295A0080 J 1SS355 AE
D708 95C0D295A0080 J 1SS355 AE
D709 95C0D295A0080 J 1SS355 AE
D710 95C0D491A0280 J Zener Diode, UDZ27B
D711 95C0D491A0290 J Zener Diode, UDZ30B AM
D712 95C0D491A0230 J Zener Diode, UDZ16B AM
D713 95C0D491A0230 J Zener Diode, UDZ16B AM
D714 95C0D295A0080 J 1SS355 AE
D715 95C0D295A0080 J 1SS355 AE
D716 95C0D295A0080 J 1SS355 AE
D717 95C0D295A0080 J 1SS355 AE
D718 95C0D292A0020 J SC902-2 AM
D720 95C0D491A0280 J Zener Diode, UDZ27B
D751 95C0D292A0020 J SC902-2 AM
D753 95C0D219B0060 J YG811S06R AM
D756 95C0D219B0060 J YG811S06R AM
PACKAGED CIRCUITS
NTC70195C0D759A4R00 J NTC Thermistor, AK
NTH7D4R0LHT62A
NTC70295C0D759A4R00 J NTC Thermistor, AK
NTH7D4R0LHT62A
å PC701 95CH7138AS001 J Optical Isolater, PC123Y82 AH
å PC702 95CH7138AS001 J Optical Isolater, PC123Y82 AH
PTC701 95C0D802A1010 J Posistor, AP
PTH9M04BD222TS2F333
å Z701 95C0D758A4710 J Transient Voltage Surge AK
Suppressor, ENC471
COILS AND TRANSFORMER
å L701 95CL1121RL103 J Inductor, FK-050E-1030KS
L704 95CL1000AS002 J Inductor, 1A002
L705 95C0L109R1310 J Inductor, SK-08MS-67Y AQ
L706 95C0L319R0010 J Core, FSOB120RT01B
å T701 95CL2000DS110 J Transformer, 2D110
CONTROL
VR751 95C0R854E1020 J Variable Resistor,1k 1/10W AH
CAPACITORS
å C701 95C0C245Q4740 J 0.47 AC250V Film AS
å C702 95C0C245Q2240 J 0.22 AC250V Film AL
å C703 95CC1356QS222 J 2200p Ceramic
å C704 95CC1356QS222 J 2200p Ceramic
C705 95CC2110YS474 J 0.47 450V Film
C706 95CC2110YS105 J 1.0 450V Film
C707 95C0C1A9R4710 J 470p 1kV Ceramic AF
C708 95CC3127MS151 J 150 400V Electrolytic
C709 95C0C1A9R4710 J 470p 1kV Ceramic AF
C711 95C0C195E1040 J 0.1 50V Ceramic AF
C712 95C0C194E2220 J 2200p 50V Ceramic AE
C713 95C0C195E1030 J 0.01 50V Ceramic AC
C714 95C0C195E1030 J 0.01 50V Ceramic AC
C715 95C0C194E1020 J 1000p 50V Ceramic AK
C716 95C0C195B4740 J 0.47 16V Ceramic AD
C718 95C0C195E1030 J 0.01 50V Ceramic AC
C720 95C0C1Q0A1060 J 10 6.3V Ceramic AQ
C721 95C0C193A4720 J 4700p 50V Ceramic AM
C722 95C0C195C1040 J 0.1 25V Ceramic AD
C723 95C0C194E1010 J 100p 50V Ceramic AC
C724 95C0C1B2S4700 J 47p 2kV Ceramic AE
C725 95C0C194E1020 J 1000p 50V Ceramic AK
C726 95C0C3A0D5600 J 56 35V Electrolytic AM
C727 95C0C193A4720 J 4700p 50V Ceramic AM
C730 95CC1356QS222 J 2200p Ceramic
C751 95C0C1A9R2210 J 220p 1kV Ceramic AF
C752 95C0C1A9R2210 J 220p 1kV Ceramic AF
C753 95C0C3A0D1510 J 150 35V Electrolytic AM
C754 95C0C1A9R2210 J 220p 1kV Ceramic AF
C755 95C0C3A0C6810 J 680 25V Electrolytic AS
C757 95C0C3A0A1220 J 1200 10V Electrolytic AS
C758 95C0C195C1040 J 0.1 25V Ceramic AD
C759 95C0C195E1040 J 0.1 50V Ceramic AF
C763 95C0C1A9R2210 J 220p 1kV Ceramic AF
RESISTORS
J709 95C0R3Q0V0000 J 0 1/8W 2012(J)
J710 95C0R390T0000 J 0 1/4W 3216(J) AC
J711 95C0R3Q0V0000 J 0 1/8W 2012(J)
J712 95C0R3Q0V0000 J 0 1/8W 2012(J)
å R701 95C0R390T6830 J 68k 1/4W 3216(J)
å R702 95C0R390T6830 J 68k 1/4W 3216(J)
å R703 95C0R390T6830 J 68k 1/4W 3216(J)
R704 95C0R390T4740 J 470k 1/4W 3216(J)
R705 95C0R390T4740 J 470k 1/4W 3216(J)
R706 95C0R390T3340 J 330k 1/4W 3216(J) AC
R707 95C0R390T2200 J 22 1/4W 3216(J) AH
R709 95C0R3Q0V1530 J 15k 1/8W 2012(J) AB
R710 95C0R516FR100 J 0.1 3W AN
R711 95C0R391T5140 J 510k 1/4W 3216(F) AC
R712 95C0R391T5140 J 510k 1/4W 3216(F) AC
R713 95C0R391T5140 J 510k 1/4W 3216(F) AC
R714 95C0R3Q0V2230 J 22k 1/8W 2012(J) AB
R718 95C0R3Q0V1010 J 100 1/8W 2012(J) AF
R720 95C0R3Q3V1030 J 10k 1/10W 2012(D) AC
R721 95C0R3Q0V4720 J 4.7k 1/8W 2012(J) AB
R722 95C0R3Q3V1030 J 10k 1/10W 2012(D) AC
R723 95C0R3Q0V3310 J 330 1/8W 2012(J) AB
R724 95C0R390T1040 J 100k 1/4W 3216(J) AF
R725 95C0R390T3320 J 3.3k 1/4W 3216(J) AC
R727 95C0R390T3340 J 330k 1/4W 3216(J) AC
R728 95C0R390T1000 J 10 1/4W 3216(J) AC
R729 95C0R390T1830 J 18k 1/4W 3216(J) AD
R730 95C0R390T2210 J 220 1/4W 3216(J) AF
R731 95C0R390T4710 J 470 1/4W 3216(J) AD
R732 95C0R3Q3V5620 J 5.6k 1/10W 2012(D)
R733 95C0R3Q3V3330 J 33k 1/10W 2012(D)
R734 95C0R3Q0V4710 J 470 1/8W 2012(J) AB
R735 95C0R3Q3V3340 J 330k 1/10W 2012(D) AF
R736 95C0R3Q0V1030 J 10k 1/8W 2012(J) AB
R737 95C0R3Q0V1030 J 10k 1/8W 2012(J) AB
R738 95C0R390T1830 J 18k 1/4W 3216(J) AD
R739 95C0R3Q0V3330 J 33k 1/8W 2012(J) AB
R740 95C0R390T3340 J 330k 1/4W 3216(J) AC
R741 95C0R390T3340 J 330k 1/4W 3216(J) AC
R742 95C0R3Q0V4710 J 470 1/8W 2012(J) AB
R743 95C0R3Q0V6820 J 6.8k 1/8W 2012(J) AF
R744 95C0R3Q0V6810 J 680 1/8W 2012(J) AF
R745 95C0R3Q0V1010 J 100 1/8W 2012(J) AF
R746 95C0R3Q0V8220 J 8.2k 1/8W 2012(J) AB
R747 95C0R3Q0V2220 J 2.2k 1/8W 2012(J) AB
R748 95C0R390T3320 J 3.3k 1/4W 3216(J) AC
R749 95C0R3Q0V6820 J 6.8k 1/8W 2012(J) AF
R750 95C0R390T1000 J 10 1/4W 3216(J) AC
