Sharp PG-A10S User Manual

32
PG-A10S
PG-A10S-SL
AN-A10T
YES
YES
YES
YES
NO
Checking the power unit
Are the connectors CN701,
CN702 and CN751
inserted completely?
Insert the connectors
CN701, CN702 and
CN751 tightly?
Replace the bimetal
NO
Replace F701.
NO
Check Q702 for damage.
Replace as required.
NO
Is the bimetal switch off?
Is there AC voltage (100-
240V) applied across
C701?
Disconnect the CN751
connector. Is there 6V
output at pins (3) and (4)?
Check the MAIN PWB for
short-circuit.

Sharp PG-A10S Specifications

General

Brand	Sharp
Model	PG-A10S
Category	Projector
Language	English
